Surround Master V3
Quick Setup - SM3-224
WARNING: To reduce the risk of re or electrical shock, do not expose the product to rain or moisture.
WARNING: The apparatus shall not be exposed to dripping or splashing, and objects lled with liquids, such
as vases, shall not be placed on the apparatus. As with any electronic products, use care not to spill liquids
into any part of the system. Liquids can cause a failure and/or a re hazard.
WARNING: No naked ame sources, such as lighted candles, should be placed on any part of the system.
These CAUTION marks are located on your Surround Master V3 enclosure:
The lightning ash with arrowhead
symbol within an equilateral triangle
alerts the user to the presence of
uninsulated, dangerous voltage within
the system enclosure that may be of
sucient magnitude to constitute a
risk of electrical shock.
PLEASE NOTE : THERE ARE NO USER SERVICEABLE COMPONENTS CONTAINED WITHIN THE SM2-224-01
The exclamation point within an
equilateral triangle, as marked
on the system, is intended to
alert the user to the presence
of important operating and
maintenance instructions in this
owner’s guide.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE THE COVER
NO USER SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE THE COVER
NO USER SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AUSTRALIAN DESIGNED
AND MANUFACTURED
Computer programs embodied in this equipment
Copyright Involve Audio 2014
U.S.Patent #: US9111528B2
Int. Patent #: WO2011/069205A1
SM3-224 Surround Master V3 Quick Setup V2.0 © 2021 Involve Audio Pty Ltd All Rights Reserved | www.involveaudio.com
SUB
R
L R
C
L
MODES
Mode Function Outputs
Stereo Pass Through FL, FR
Involve 4(.1) Involve Quad FL, FR, RL, RR, SUB
Involve 5(.1) Involve 5.1 FL, FR, RL, RR, SUB
SQ 4(.1) Involve SQ Quad FL, FR, RL, RR, SUB
SQ 5(.1) Involve SQ 5.1 FL, FR, RL, RR, SUB
TSS Two Speaker Surround FL, FR, SUB
ON/OFF
OFFON
INPUT LEVEL
Input
Clipping
No
Clipping
Log level control
- db to +6db
∞
Centre Detent
at 0db
CHANNEL LEVEL
Active Inactive
Log level control
- 12db to +12db
Centre Detent
at 0db
Full Range
Output
SUB LEVEL
Active Inactive
Log level control
- 12db to +12db
Centre Detent
at 0db
120Hz
Low Pass
Controls
FL Front Left
FR Front Right
RL Rear Left / Surround Left
RR Rear Right / Surround Right
CCentre
SUB Subwoofer (120hz Low Pass)
SM3-224 Surround Master V3 Quick Setup V2.0 © 2021 Involve Audio Pty Ltd All Rights Reserved | www.involveaudio.com
SUB
R
L R
C
L
Connections & Setup
Involve / SQ / 4.0 / 4.1
4(.1) 5(.1)
Input
Two Speaker Surround
Stereo Passthrough
RCA INPUT
4(.1) 5(.1)
Input
Two Speaker Surround
Stereo Passthrough
4(.1) 5(.1)
Input
Two Speaker Surround
Stereo Passthrough
Involve / SQ / 5.0 / 5.1
POWER - DC 9-12V 1A
C
4(.1) 5(.1)
Input
Two Speaker Surround
Stereo Passthrough
FL
SUB
R
L R
C
L
Power
Outlet
RL
FR RR
(optional)
SUB
(optional)
SUB
FL RL
FR RR
TSS (2.0 / 2.1)
4(.1) 5(.1)
Input
Two Speaker Surround
Stereo Passthrough
(optional)
SUB
STEREO
4(.1) 5(.1)
Input
Two Speaker Surround
Stereo Passthrough
LEFT
RIGHT
OUTPUT TO DSP / AMPLIFIER / PRE-AMP / ACTIVE SPEAKERS
LEFT
RIGHT
LEFT
RIGHT
OPTICAL INPUT
STEREO PCM ONLY
Remove cap before
plugging in
Many thanks for purchasing your Surround Master V3, we hope it
brings you many hours of listening enjoyment.
Happy Listening!
© 2021 Involve Audio Pty. Ltd. All Rights reserved
Involve audio and Involve are registered trademarks of Involve Audio Pty Ltd.
SM2-224 Surround Master V3 Quick Setup V2.0
