Invicta VD53 Manuel utilisateur

Movement Caliber : VD53

Presentation

Display Elements

Minutes Hand

Hour Hand

Stopwatch

Minutes Hand

(Move in second

increments)

Second Hand

Stopwatch

Minutes Hand

(Move in second

increments)

24-Hour Hand

(Indicates the time on

a 24-Hour basis)

Date Window

1 2

Crown Positions

1: Date setting

2: Time setting

Push Button B

In stopwatch function:

Split / Split release / Reset

Control Buttons

Push Button A

In stopwatch function:

Start / Stop

· The measurement time indicated by the stopwatch hands move independently of the

center hands.

·Chrono1/10sec:Thestopwatch1/10secondhandmovesforarstminute.Afterone

minute, it indicates the measurement time when it is stopped.

INFO

Movement Caliber

VD53

Movement Caliber : VD53

Setting

Adjusting the Stopwatch Hand Position

Before setting the time, check if all the chronograph hands - second,

minute - are at the “0”(12 o’clock) position.

•If the stopwatch is in use, press the buttons in the following order to

reset it, and then, check if the hands return to “0” position.

 (Fordetails,see“HOWTOUSETHESTOPWATCH”)

•If the chronograph is counting : A > B

•If the stopwatch is stopped : B

•If the split time is displayed: B > A > B

If either of the stopwatch hands are not in the “0” position , reset them

following the procedure below

Pull the crown out to position 2. Push the crown back to the normal position.

PressbuttonAorBtoresetallstopwatch

hands to “0” position.

·

The stopwatch minute hand moves

correspondingly with the stopwatch

second hand.

·The hands move quickly if the respective

buttons are kept pressed.

1.2

1.1 1.3

2.3

2.1

2.4

2.2

Movement Caliber : VD53

Setting

Time Setting

•Before setting the time, check that the chronograph measurement

isstopped.

•Donotsetthedatebetween9:00P.M.and1:00A.M,otherwisethe

day may not change properly. If it is necessary to set the date during

 thetimeperiod,rstlychangethetimetoanytimeoutsideit,setthe

date and then reset the correct time.

2.1 Pull out the crown to the position 1

2.2 Turn the crown clockwise until the preview day’s date appears.

2.3 Pull out the crown to the position 2 when the second hand is at the 12 o’clock position.

  Itwillstoponthespot.Setthehandstothedesiredtimeoftheday(makesureAM/PMis

set correctly) by turning the crown.

 •

When the crown is at the second click position, do not press any button. Otherwise the

chronograph hands will move.

2.4 Push the crown back in the normal position in accordance with a time signal.

Movement Caliber : VD53

Functions

Standard Measurement

E.g.100mrace(PressthebuttonsinthefollowingorderA>A>B)

How to Use the Stopwatch

•The measurement time is indicated by the stopwatch hands that

move independently of the center hands (and 24-hour hand where

applicable).

•The stopwatch can measure up to 60 minutes.

3.1

3.2 3.3

Start

Stop (Finish) 10 Seconds Reset (Reset to "0'00")

4.3

4.1

4.4

4.2

Movement Caliber : VD53

Functions

Accumulated Elapsed Time Measurement

E.g. basketball game

(PressthebuttonsinthefollowingorderA>A/A····>A>B)

Restart and stop of the stopwatch can be repeated as many times as

necessarybypressingbuttonA.

4.1 Start>Stop(Startofgame)(Timeout)

4.2 Restart (Restart of game), 5 Seconds 10 Seconds

4.3 Stop (Game Over), 20 Seconds 00 Seconds

4.4 Reset

5.3

5.1

5.4

5.2

Movement Caliber : VD53

Functions

Split Time Measurement

E.g. 5,000m race

(PressthebuttonsinthefollowingorderA>B/B····>A>B)

Measurement and release of the split time can be repeated as many

times as necessary by pressing button B.

5.1 Start

5.2 Split / Split release, 5 Minutes 50 Seconds

5.3 Stop, 15 Minutes 10 Seconds

5.4 Reset
