Invacare®Delta™

1General

1.1Aboutthismanual

ThisUserManualcontainsimportantinformationaboutyour

product.Inordertoensuresafetywhenusingtheproduct,readthe

UserManualcarefullyandfollowthesafetyinstructions.

Thepersonwhoprescribestheproductorwhoisotherwise

responsiblefortheusermustensurethattheproductissuitablefor

theuser.Theusershallbeinstructedhowtousetheproduct.This

includestheuseofthefeaturesandtherestrictionsinuse.Theuser

shallalsobenotifiedofthewarningsforusegivenintheusermanual.

Symbolsinthismanual

InthisUserManualwarningsareindicatedbysymbols.Thewarning

symbolsareaccompaniedbyaheadingthatindicatestheseverity

ofthedanger.

WARNING

Indicatesahazardoussituationthatcouldresultin

seriousinjuryordeathifitisnotavoided.

CAUTION

Indicatesahazardoussituationthatcouldresultin

minororslightinjuryifitisnotavoided.

IMPORTANT

Indicatesahazardoussituationthatcouldresultin

damagetopropertyifitisnotavoided.

TipsandRecommendations

Givesusefultips,recommendationsandinformation

forefficient,trouble-freeuse.

ThisproductcomplieswithDirective93/42/EEC

concerningmedicaldevices.Thelaunchdateofthis

productisstatedintheCEdeclarationofconformity.

1.2Intendeduse

Indications

Therollatorisintendedforsupportandimprovementofarestricted

walkingability.Theuser’sremainingwalkingabilityneedstobe

sufficientforleavingthehome,forusualdailyactivitiesandfor

participatinginsociallifewithoutendangeringthemselvesorothers.

Therollatorisintendedtosupportapersonduringwalking.

Furthermoretherollatorisintendedtocarryaloadeitherina

speciallydesignedbasket,onatrayorinabag.

Themax.userweightis135kg.Thisweightlimitationincludesthe

weightoftheuserandthecontentofthebasket.

1.3ServiceLife

Theexpectedservicelifeofthisproductisfiveyearswhenused

inaccordancewithsafetyinstructions,maintenanceintervalsand

correctuse,statedinthismanual.Theeffectiveproductlifecyclecan

varyaccordingtofrequencyandintensityofuse.

41542458-C

General

1.4Scopeofdelivery

•Rollator,partlyassembled

•Basket,trayandbag

•Usermanual

1.5Warranty

Wesupplyatwoyearwarrantyfromthedateofdelivery.Deviations

mayoccurduetolocalagreements.Damagecausedbynormalwear

toe.g.wheels,handlesandbrakesordamagecausedbyabnormal

use(e.g.exceededmax.userweight)isnotcoveredbythewarranty.

Maintenanceandoperatinginstructionsmustbefollowedforthe

warrantytobevalid.

1542458-C5

Invacare®Delta™

2Safety

2.1Generalwarnings

WARNING!

Riskoffalling

–Exercisecautionwhenwalkingonsloping/slippery

groundandonunevensurfaces.

–Becarefulwhenwalkingrearwardsoverobstacles.

–Donotgoupordownstairswiththerollator.

–Donotusetherollatoronescalators.

–Donotunderanycircumstancesstandontherollator.

–Loadsmustonlybetransportedinthebasket,onthe

trayorinthebag.Becarefulwhenthereisaheavy

loadinthebasket(forthemax.loadinthebasket

refertochapter“TechnicalData”).

WARNING!

Riskofinjury

–Donotletchildrenplaywiththerollator.

–Ifthepushhandlesareexposedtoextreme

temperature(above41°C)theremightberiskforfirst

degreeburns.

IMPORTANT!

Riskofcorrosion

–Therollatormustnotbestoredoutsideinwetclimate

orinhumidenvironmentsforalongperiodoftime.

2.2Labelsandsymbolsontheproduct

XXX KG XXcm

INVACARE XXXXXX

XXXXXXX

X XXXXXX XXXXXX

XXXXXXXX

xxxx - xx

FBG

EHI

Thelabelcontainsallimportanttechnicalinformationregardingyour

walkingaid.

AArticlenumber

BProductname

CSerialnumber

DDateofmanufacture

EMax.userweight

FRefertousermanual

GIn-andoutdoorwalkingaid

HMax.widthofwalkingaid

IManufacturer’sname.

61542458-C

Usage

3Usage

3.1Beforeuse

Wedonotrecommendthattheproductisissuedtoanyonewithout

firstcarryingoutafullassessmentoftheirspecificneeds.Itis

importantthattheuserisgiventhenecessarysupportbytheproduct

asprescribedbyaqualifiedprofessional.Thisisbothforthesafety

oftheuserandalsotheirrecoverypattern.

3.2Operatingposition

WARNING!

Riskoffalling

–Makesurethatthesafetylatchisinalockedposition

beforeusingtherollator.

Difficulttoadjustlever

–Thelockingleverandwashermustbemountedon

theoutsideofthetube.

RemovetheplasticcapsAandopentherollator.

2.AttachtheboltBandthewasherC.

Ensurethattheboltslotsintotherecessofthefitting.

1542458-C7

Invacare®Delta™

3.AttachthelockingleverDontheboltB.

4.FitthehandleEtothetube.

5.TightenthelockingleverD.

Thelockingleversmustbepointingdownwardsduring

use.

6.Repeattheprocedureontheoppositeside.

3.3Foldingandunfoldingtherollator

Foldingtherollator

1.PullthesafetycatchAupwards-backwards.

2.Pushthehandlesinwardstofoldtherollator.

WARNING!

Riskofpinching

–Beawareoftheriskofpinchingbodyparts

betweenthepartsoftheframewhenfoldingthe

rollator.

Unfoldingtherollator

WARNING!

Riskoffalling

–Makesurethatthesafetylatchisinalockedposition

beforeusingtherollator.

1.Pushthehandlesoutwardstounfoldtherollator.

2.PullthesafetycatchAdownwards-forwardstolockthe

rollatorinanunfoldedposition.

81542458-C

Usage

3.4Mountingthebag,basketandtray

Bag

1.MountthebagAbetweentheframetubes.

2.FoldtheattachmentflapsBoverthetubesandsecurethe

buttons.

3.Repeattheprocedureontheoppositeside.

Basket

AttachthebasketContheattachmenthooksD.

Tray

PlacethetrayEonthetopofthebasketC.

3.5Usingthehandbrakes

1.2.

1.ApplytherunningbrakesbypullingbothbrakehandlesA

upwards.

2.Toapplytheparkingbrakes,pressthebrakehandlesA

completelydownwards.

Anaudiblesoundindicatesthatthebrakeisinthe

correctposition.

1542458-C9

Invacare®Delta™

Itisimportantthatbothbrakesareputintoparkingposition.

3.Toreleasetheparkingbrakes,pullthebrakehandlesupwards.

Adjustingthebrakeeffect

WARNING!

Riskofpoorbrakeeffect

–Theadjustmentofthebrakemustbedonebyqualified

personnel.

ThebrakecanbeadjustedbothbythehandleAorbelowbythe

wheelB.

Spanner8mmand10mm(notincluded)

3.6Adjustingthehandleheight/angle

1.Standbehindtherollatorwithflatshoulders.

2.LoosentheleverA.

3.Adjustthehandletosuitableheightand/orangle.

Thehandlesshouldusuallybepositionedatwristheight.

Therapistmaysuggestdifferentheightsdependingon

specificneedsoftheclient.

4.Re-tightenthelever.

5.Repeattheprocedureontheotherside.

101542458-C
