IVR-6123
Handheld OTDR Test Set
User Guide
IVR-6123 series is interVRE’s handheld
OTDR test set. It provides comprehensive
opcal test for metro, access/FTTx,
and LAN network. Also IVR-6123 is
designed for indoor and outdoor test
with lightweight, exible and rugged
features. It is the best test set for service
providers validang at installing phase or
troubleshoong at running phase.
IVR-6123 Handheld OTDR Test Set
2
Revision History
The following tables shows the revision for this document.
The product and the user guide could be upgraded or modied without noce. Please visit the website of
InterVRE (www.intervre.com) or contact us for the further informaon.
Date Version Revision
18/04/2011 1.0 Inial Release
26/06/2015 2.0 •Revised the whole document;
•Add Auto zoom bre span, and Span start funcons in the
General
seng;
•Add Port funcon in the OTDR seng;
•Add Reect threshold funcon in Threshold seng;
•Edit File content of iOTA File seng;
•Add Predene Link funcon in iOTA seng;
•Modify default value of Splice loss in Element seng;
•Add Splier loss funcon in Element seng.
IVR-6123 Handheld OTDR Test Set
3
Contents
1. Introduction 8
1.1 Overview 8
1.2 MainFeatures 8
2. Description 9
2.1 FrontPanel 9
2.1.1 Front Panel Diagram 9
2.1.2 LED Indicators 9
2.1.3 Buons 10
2.2 RightPanel 11
2.2.1 Right Panel Diagram 11
2.2.2 Interfaces 11
2.3 TopPanel 12
2.4 BoomPanel 12
3. Specications 13
3.1 EnvironmentalGuidelines 13
3.2 AdapterandBaery 13
3.2.1 AC/DC Adapter 13
3.2.2 Rechargeable Lithium-Ion Baery 13
3.3 OtherPhysicalSpecicaons 14
4. Safety Information 15
4.1 GeneralSafetyInformaon 15
4.2 LaserSafetyInformaon 15
4.3 ElectricalSafetyInformaon 15
5. Installation of the Device 17
5.1 TurntheDeviceOnorO 17
5.2 InstallingorUpgradingtheApplicaons 17
5.3 InstallingaUSBKeyboardorMouse 18
5.4 InstallingOpcalFibre 18
6. Main Interface 20
6.1 FunconSelect 20
6.2 OTDRInterface 20
6.2.1 Status Bar 21
6.2.2 Curve Window 21
6.2.3 Event Informaon Bar 21
6.2.4 OTDR Main Menu 21
6.3 iOTAInterface 24
6.3.1 Status Bar 24
6.3.2 Result Display Window 24
6.3.3 iOTA Main Menu 24
7. Test under OTDR Interface 27
7.1 ParametersSeng 27
7.1.1 General 27
7.1.2 OTDR 28
7.1.3 Scale 30
7.1.4 Threshold 30
7.1.5 Pass/No Pass 31
7.1.6 Synchronisaon 32
7.1.7 Storage 32
7.1.8 Factory Seng 33
7.2 ExaminaonModes 33
7.2.1 Auto Test Mode 33
7.2.2 Manual Test Mode 34
7.2.3 Real-me Test Mode 34
7.3 CurveandEventAnalysis 34
Content
IVR-6123 Handheld OTDR Test Set
4
7.3.1 View Event Informaon 34
7.3.2 Zoom Curves 35
7.3.3 Use A&B Lines 35
7.3.4 Add, Edit and Delete Event and Event Types
35
7.3.5 Obtain Test Result 38
7.4 Result 40
7.5 Tool 42
7.5.1 Light Source 42
7.5.2 VFL 42
7.6 SystemSeng 43
8. Test under iOTA 49
8.1 ParametersSeng 49
8.1.1 Predene Link 49
8.1.2 iOTA 50
8.1.3 Link Threshold 50
8.1.4 Element Threshold 51
8.1.5 Synchronisaon 52
8.1.6 Storage 52
8.1.7 Factory Seng 52
8.2 TestResult 52
9. Maintenance 53
9.1 GeneralMaintenanceInstrucon 53
9.2 Transportaon 53
10. Troubleshooting 54
10.1CommonProblemsSoluons 54
10.2TechnicalSupportContact 55
10.3Transportaon 55
11. Warranty 56
11.1WarrantyStatement 56
11.2Disclaimer 56
11.3ServiceandRepairs 57
Content
IVR-6123 Handheld OTDR Test Set
5
Table 2.1 LED Indicator Denions 9
Table 2.2 Buons Descripon 10
Table 2.3 Interfaces Descripon 11
Table 3.1 Environmental Ranges 13
Table 3.2 Input and Output Requirement 13
Table 3.3 Other Physical Specicaons 14
Table 5.1 Turn On or O Instrucon 17
Table 5.2 Applicaon Installing or Upgrading Hardware Requirements 17
Table 6.1 OTDR Main Menu Funcons List 22
Table 6.2 iOTA Main Menu Funcon List 25
Table 7.1 Add, Edit, and Delete an Event 36
Table 7.3 Test Result Descripons and Operaon Methods 38
Table 7.4 Descripon of Event List, Trace Informaon, Trace Overview 40
Table 7.5 System Seng 43
Table 10.1 Common Problems and Soluons 54
Contents of Tables
Content
IVR-6123 Handheld OTDR Test Set
6
Figure 2.1 Handheld OTDR Test Set Front Pan-
el View 9
Figure 2.2 Handheld OTDR Test Set Right
Panel View 11
Figure 2.3 Handheld OTDR Test Set Top Panel
View 12
Figure 2.4 Handheld OTDR Test Set Top Panel
View (PON) 12
Figure 2.5 Handheld OTDR Test Set Boom
Panel View 12
Figure 5.1 Explore 18
Figure 6.1 Funcon Select 20
Figure 6.2 OTDR Interface 20
Figure 6.3 Status Bar 21
Figure 6.4 Curve Window Diagram 21
Figure 6.5 Event Informaon 21
Figure 6.6 File 22
Figure 6.7 Sengs 22
Figure 6.8 Begin 22
Figure 6.9 iOTA 22
Figure 6.10 Operaon 22
Figure 6.11 Result 23
Figure 6.12 Tool 23
Figure 6.13 System 23
Contents of Figures
Figure 6.14 Help 23
Figure 6.15 iOTA Interface 24
Figure 6.16 Result Display Window Diagram 24
Figure 6.17 File 25
Figure 6.18 Seng 25
Figure 6.19 Begin 25
Figure 6.20 OTDR 25
Figure 6.21 Operaon 25
Figure 6.22 Tool 25
Figure 6.23 System 26
Figure 6.24 Help 26
Figure 7.1 General Seng 27
Figure 7.2 Seng Resoluon 28
Figure 7.3 Analysis Seng 28
Figure 7.4 Scale 30
Figure 7.5 Threshold 30
Figure 7.6 Pass/No Pass 31
Figure 7.7 Synchronisaon 32
Figure 7.8 Storage 32
Figure 7.9 Factory Seng 33
Figure 7.10 Event List 35
Content
IVR-6123 Handheld OTDR Test Set
7
Figure 7.11 Add an Event 36
Figure 7.12 Edit an Event 36
Figure 7.13 Delete an Event 37
Figure 7.14 Event List 40
Figure 7.15 Curve Informaon 40
Figure 7.16 Curve Overview 41
Figure 7.17 State Informaon 41
Figure 7.18 Light Source 42
Figure 7.19 VFL 43
Figure 7.20 District 43
Figure 7.21 Back Light 44
Figure 7.23 Explorer 44
Figure 7.24 Network Seng 45
Figure 7.25 Network Tool 45
Figure 7.26 Ping 45
Figure 7.27 Trace Route 46
Figure 7.28 Capture 46
Figure 7.29 FTP 46
Figure 7.30 HTTP 47
Figure 7.31 Remote Desktop 47
Figure 7.32 Power 47
Figure 7.33 System Informaon 48
Figure 8.1 Predene Link 49
Figure 8.2 iOTA 50
Figure 8.3 Link Threshold 50
Figure 8.4 Element Threshold 51
Figure 8.5 Test Result 52
Content
IVR-6123 Handheld OTDR Test Set
8
1.1 Overview
IVR-6123 Handheld OTDR Test Set is one of OTDR product of INTERVRE. This product is specialised
designed for engineers to examine and detect opcal bres or cables in MAN (Metropolitan Area
Network); AN (Access Network); and FTTx mullayer network with high exibility, high eciency,
and convenience.
1.2 Main Features
IVR-6123 Handheld OTDR Test Set has the following features:
• Interface user-friendly, operaon simply, and durable;
• High resoluon LCD colour touchable screen;
• Support all OTDR funcons, and various wavelengths;
• Support PON funcon, can do online PON test;
• Can pass 1:128 opcal splier;
• Rapid start technology;
• Baery life: more than 8 hours.
1. Introduction
Introduction
IVR-6123 Handheld OTDR Test Set
9
2.1 Front Panel
2.1.1 FrontPanelDiagram
Figure 2.1 IVR-6123 Handheld OTDR Test Set Front Panel View
2.1.2 LEDIndicators
LED locaons for all LEDs on IVR-6123 has been shown in Figure 2.1. Table 2.1 describes the
LEDs placed on IVR-6123 as indicators.
Table2.1LEDIndicatorDefinitions
2. Description
LED STATUS DESCRIPTION
Green On
O O, and unplugged in
Green Plugged in and baery is fully charged
Green (ashing) Baery is on charge
Red (ashing) Unplugged in, and baery is weak
Red Baery error
O • O
• Unplugged in, and baery level is above the ‘crical threshold’
Green Result status: success ( Current result of the applicaon does not exceed the
predened threshold)
Red Result status: failure (Current result of the applicaon exceeds the predened
threshold)
Green (ashing) Laser status LED, at least one module is transming an opcal signal
O No module is transming signal
Description
LED Indicators
Funcon Key
On/O Buon
Number Key
Direcon Key
Colour Touch Screen
IVR-6123 Handheld OTDR Test Set
10
2.1.3 Buttons
Table 2.2 describes the funcons of IVR-6123 Handheld OTDR Test Set’s buons.
Table2.2ButtonsDescription
Button Description
F1, F2, and F3 Funcon keys: Select the one sub menu from main menu displayed on the screen
Funcon keys: Switch the main menu
CANCEL X Cancel/Exit
OK √ OK/Conrm
• AB lines:
• Move AB lines right or le
• Move AB lines up or down
• Zoom:
• Zoom the curve horizontally
• Zoom the curve vercally
• Move:
• Move the screen right or le
• Move the screen up or down
AUTO Click to run the test automacally
• Switch mode:
• AB lines
• Zoom
• Move
Menu Back to main menu
Test • Long press: Switch the test mode
• Manual
• Real-me
• Short press: Start/Stop test
[1] Number key: Event list
?[3] Number key: Help informaon
INFO [4] Number key: Curve informaon
VFL [6] Number key: Open/Close VFL funcon
Open le
Save le
Restore the curve
On/O (Specic operaon informaon can be seen in Secon 5.1)
Description
