CV60 SDRAM
Upgrade Instructions
1 CV60 SDRAM Upgrade Instructions
Packing List
Check to make sure the items shown on the next page were
included in your shipment. If any item appears to be missing or
damaged, contact your Intermec representative.
You must follow standard ESD guidelines to avoid
damaging the equipment you are servicing.
The memory module is a sensitive piece of equipment, so be
careful when handling the module - especially for ESD (Electro-
static Discharge), make sure that you are properly grounded.
Note: Use of unapproved SDRAM modules may void
your warranty.
Note: It is recommended that if you are using the Win-
dows XP Embedded operating system, that you have an
IDE drive, either solid state or rotating media, with at
least 1GB of capacity. Some older systems do not have
sufficient swap space to support memory upgrades.
Introduction
These instructions outline the SDRAM upgrade procedures for
the CV60 Vehicle Mount Computer.
Make sure that the power is fully off and the CV60 Computer is
unplugged from the power source.
SDRAM Connector Slot
2 CV60 SDRAM Upgrade Instructions
Procedure
1Place the CV60 Computer face down on a cushioned anti-
static mat.
2Using a Philips screwdriver, remove the eight screws securing
the CV60 rear bracket, then remove the rear bracket.
3Touch something metallic to dissipate any ESD (Electric Static
Discharge) from you.
4Remove the SDRAM module from its static bag.
5Make sure that the notches on the memory modules are
aligned with the keys of the CV60 memory socket.
6If replacing or upgrading an existing memory module, remove
the memory module by spreading the module clips and gently
lifting the edge of the module to a 45-degree angle and then
pulling the module out of the slot.
7Insert the SDRAM module into the connector, align it, and
gently lower it and snap into place.
8Replace the rear bracket and eight (8) Philips screws.
Hardware List - SDRAM Upgrade
Part Number Quantity Description
203-806-001 1 256MB RAM Option
Key
Clip
Clip
Worldwide Headquarters
6001 36th Avenue West
Everett, Washington 98203
U.S.A.
tel 425.348.2600
fax 425.355.9551
www.intermec.com
CV60 SDRAM Upgrade Instructions
*931-021-001*
P/N 931-021-001
