Intermatic Eco CI7 Manuel utilisateur

eco CI7 and CG7

EN Operating manual

This manual ensures safe and efficient use of the

“eco CI7” and “eco CG7” timers (referred to as “device”

in the following). This manual is a component of the

devices and must remain accessible at all times for

everyone who uses the devices.

Everyone who uses the devices must have read and

understood this manual before commencing any work.

The basic prerequisite for working safely is compliance

with all safety instructions and usage instructions speci-

fied in this manual. Furthermore, the local accident pre-

vention regulations and the general safety regulations in

the area in which the devices are operated apply.

2

Illustrations in this manual are intended to provide a gen-

eral understanding and may differ from the actual

design.

Copyright

This manual is copyright protected.

Handover of this manual to third parties, reproductions of

any type and form – including excerpts – and use and/or

disclosure of the content without the written permission

of Intermatic (referred to as “manufacturer” in the

following), except for internal purposes, is not permitted.

Violations will result in liability for compensation. The

manufacturer reserves the right to assert additional

claims.

EN

3

The copyright is held by the manufacturer.

©Intermatic Incorporated

1950 Innovation Way, Suite 300

Libertyville, IL 60048

USA

Declaration of conformity and download instructions

The declaration of conformity for the devices described in

this manual, a download of the manual, and the technical

data can be found at

www.

intermatic.com.

4

Overview................................................ 7

Safety................................................... 19

Installation............................................ 22

Configuration....................................... 45

Menu structure........................................... 45

Setting the time and date............................ 52

Programming....................................... 56

Selecting the predefined programmes........ 56

Changing the predefined programmes........ 59

Creating an individual switching program... 70

EN

5

Deleting a programme................................ 72

Selecting summer/winter time.................... 75

Selecting the operating mode..................... 77

Disposal............................................... 79

6

Overview

Fig. 1: Insert

1 Display of day blocks/days

2 Display of on/off times

3 Display of the current time

EN

7

Fig. 2: Rear view of “eco CI7”

1 Mounting holes

2 Flexible union fittings for cable feed-through

8

Display Function

Set the time format (24 h or 12 h)

Set summer or winter time

On/off time memory space

Switch between automatic mode, perma-

nently on, permanently off

Automatic mode

Prog. Switching programme is displayed

qLights up in automatic mode via and

when permanently ON via

EN

9

Button Function

+ Press briefly to increase value by 1

Press and hold to increase value by 5

Only in operating mode:

Switch between automatic mode, perma-

nently on, permanently off

− Press briefly to reduce value by 1

Press and hold to reduce value by 5

Menu Start/exit programming mode; return to

automatic mode

OK Confirm programming

10
