MODEL HA07 - MASTER CONTROLLER INSTRUCTIONS

Page 1 of 35 158HA11645

Thank you for purchasing Intermatic’s Home Settings

devices. With these products you can reliably and remotely

control lighting and appliances. The outstanding features of

the Home Settings program include:

ØFeedback that will allow you to see whether your

device has received the ON/OFF/DIM signal.

ØEase of installation

ØManual override

ØRF signal reliability – each Home Settings product

has a special repeater feature that virtually

guarantees that RF signals are received.

The HA07 Controller also includes the following features:

Ø12 Channels - each channel can control up to 16 devices

to create scenes or timed events.

ØAstronomic Feature – this option allows your time settings

to match the daily changes in sunrise and/or sunset. Set

it once and never have to set it again for these types of

time changes.

ØWall mountable or place on a tabletop.

ØDaylight Saving Time – this option automatically adjusts

your timer for daylight saving time.

ØProgramming flexibility – timing options can be every day

of the week, Mon- Fri, Sat-Sun, or individual days.

ØALL ON/ALL OFF Feature – Turn all devices ON or OFF

with the push of one button.

ØIf required, more than one controller can be used for the

same system.

ØTimed control

Z-Wave™ Introduction

The HA07 Master Remote Controller is a Z-Wave™ enabled

device and is fully compatible with any Home Settings network

and any Z-Wave™ enabled network. Z-Wave™ enabled devices

displaying the Z-Wave™ logo can also be used with Home

Settings modules and controllers regardless of the manufacturer,

and Home Settings modules and controllers can also be used in

other manufacturer’s Z-Wave™ enabled networks. Each module

in a Home Settings network is designed to act as a repeater.

Repeaters can re-transmit the RF signal to ensure that the signal

is received by its intended destination by routing the signal around

obstacles and radio dead spots.

Page 2 of 35

Table of Contents

Glossary of Terms………………………………………….……….. 4

Installing Batteries…………………………………………………… 6

Module Installation and Set-up Recommendations……………… 7

Programming Instructions…………………………………………... 8

Setting the Clock……………………………………...…………. 8

Setting the Calendar……………………………………….……. 9

Setting Daylight Saving Time & Zone………………..……..…. 11

Setting Astronomic Function…………….……………………… 13

Creating a Network………………………………………………….. 14

INCLUDE Modules to a Network………………………………. 14

Associating Modules to Channels….……………………….…. 16

EXCLUDE from Network………………………………….…….. 18

EXCLUDE from Channel……………………..…………………. 18

Remote ON/OFF/DIM Operation…………………………………... 19

Adding Modules to ALL ON/ALL OFF Feature……………….….. 20

INCLUDE Modules to ALL ON/ALL OFF Feature……...…..... 20

EXCLUDE Modules to ALL ON/ALL OFF Feature…..………. 22

Programming the Controller………………………………………… 23

Automatic, Automatic Random, and Manual Mode……………… 27

Additional Features………………………………………………….. 28

Controller Replication…………………………………...………. 28

Replicating the Network and Channel Settings….…………... 28

Replicating the Network only…………...……………….……… 30

Resetting the Controller…………………………………………….. 31

Resetting the NETWORK only……………………..…………... 31

Resetting the CHANNELS only…………………..…………….. 31

Resetting the NETWORK and CHANNELS…..……….……… 31

Troubleshooting……………………………………..………………. 32

Federal Communications Commission Statement………………. 34

Specification Information……………………………………………. 34

Warranty Information…………………………………………….….. 35

Page 3 of 35

Master Remote Controller _

Fig 1. LCD display and button configuration.

Glossary of Terms

Astronomic Function – Allows a device to follow sunrise and

sunset times. The unit will automatically adjust as daylight

time increases or decreases without the need to be

reprogrammed.

Channel – Achannel will control up to 16 modules, allowing

them to be programmed to turn on/off with the same time

settings. HA07 has 12 channels.

Device – Any item that is connected to a module (for

example, lamps).

Page 4 of 35

Event - A program in the controller that will instruct the

controller to control various modules at a set day and time.

The HA07 can accommodate up to 28 events.

Module – Any Intermatic Home Settings product that is

controlled with a remote controller.

Network – All Intermatic Home Settings devices controlled

by the Master Controller and duplicate remote controls

operating on the same system. Each network has its own

unique identification code so that no one else can control the

system.

Primary Controller – The first controller used to set up your

modules and network.

NOTE: Only the Primary Controller can be used to include or

delete modules from a network.

Scene – Lighting modules assigned to the various channels can

be set at different levels, thus creating desired light levels

throughout your house called scenes. Scenes can be set during

the “Associating Modules To Channels” step (see page 16) by

choosing ON, OFF and/or DIM settings.

Secondary Controller – A controller containing network information

about other modules within the network, and is created from the

primary controller. Secondary controllers cannot include or delete

modules to the network.

Page 5 of 35

Battery Installation

1. Open the battery compartment door located on the

back of the remote control by pressing down on the

battery compartment tab and pulling the door outward.

2. Insert 4 size “AA” alkaline batteries (not included),

placing the batteries as shown in the battery

compartment. (See Fig 2)

3. Replace the battery compartment door by first inserting

the 2 tabs at the bottom of the door, then pressing the

door in until the door clicks shut. Fig 2. Battery compartment

Page 6 of 35

Module Installation and Set-Up Recommendations

1. Modules should be plugged-in or hardwired into the

location where they will be used.

2. For best results, do not move or relocate modules after

they have been included into the network. If you wish to

re-locate or move a module from a particular location,

first delete it from the network, then include it back to

the network after you have re-located it.

3. Devices should be plugged into modules before adding

modules to the network. Devices (for example, lamps)

should be turned to the ON position.

Module Installation and Set-Up Recommendations

4. Controllers must be brought within 6 ft. of modules

during set-up. This is because during set-up, the

controller communicates with the modules using low

radio transmission power. This helps provide additional

security when setting up your network.

5. HA06 Dimmer Switches have a 40-Watt minimum lamp

requirement.

Page 7 of 35

Programming Instruction

_______________Setting the CLOCK_________________

1. (See Fig 3a) Press MODE until CLK mode is shown.

Fig 3a

2. (See Fig 3b) Press ENTER and the hour will flash. Press +

or - to set the hour. Press ENTER to accept the hour.

Fig 3b

Page 8 of 35

3. (See Fig 3c) The minutes will flash. Press + or - to set

minutes. Press ENTER to accept the minutes.

Fig 3c

Setting the CALENDAR

NOTE: The day of the week will be automatically calculated

when the CALENDAR setting is completed.

1. (See Fig 4a) Press MODE until the CAL mode is shown.

2. (See Fig 4b) Press + or - to set the month. Press

ENTER to accept the changes.

3. (See Fig 4c) The day of the month will flash.

Press + or - to set the day. Press ENTER to accept

the changes.

4. (See Fig 4d) The year will flash. Press + or - to set the

year. Press ENTER to accept the year.

Page 9 of 35

Setting the CALENDAR (continued)

Fig 4a – CAL mode Fig 4b – Set Month Fig 4c – Set Day Fig 4d – Set Ye
