Operation Manual

Digital PA System

PSI-5120/5240

PSI5120_E 2009.7.31 9:33 AM 페이지 2

DIGITAL PA SYSTEM

Welcome

A personal welcome to you from the management and employees of Inter-M

All of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value,

and we are delighted you have purchased one of our products.

We sincerely trust this product will provide years of satisfactory service, but if anything is not to your complete

satisfaction, we will endeavor to make things right.

Welcome to Inter-M, and thank you for becoming part of our worldwide extended family!

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

WARNING

To prevent fire or shock hazard, do not

expose the unit to rain or moisture.

*WARNING FOR YOUR PROTECTION PLEASE READ THE FOLLOWING-WATER AND MOISTURE: Unit should not be used near water(e.g.

near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, etc). Care should be taken so than objects do

not fall and liquids are not spilled into the enclosure through openings.

*CLASS 2 WIRING (Adjacent to speaker terminal): The speaker output of this apparatus can exceed 10 Watts and could be a shock injury.

Connection to speakers should be performed by a skilled person.

*Do not install this equipment in a confined space such as a book case or similar unit.

*This apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such vases, shall be placed on the apparatus.

*This apparatus shall be connected to a mains socket outlet with a protective earthing connection.

It has heed to be easy to disconnect the device. To disconnect the device from power, separate AC input cable from inlet or unplug the AC Cord.

CAUTION

*These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing

other than that contained in the operating instructions unless you are qualified to do so.

NOTE

*This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment

generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will

be required to correct the interference at his own expense.

This symbol is intended to alert the user to the

presence of uninsulated “dangerous voltage” within

the product’s enclosure that may be of sufficient

magnitude to constitute a risk of electric shock to

persons.

This symbol is intended to alert the user to the

presence of important operation and maintenance

(servicing) instructions in the literature accompanying

the appliance.

Caution: To prevent electric shock do not use this (polarized) plug with

an extension cord, receptacle or other outlet unless the blades

can be fully inserted to prevent blade exposure.

Attentions: Pour prévenir les chocs électriques ne pas utiliser cette

fiche polarisée avec un prolongateur, une prise de courant

on une autre sortie de courant, sauf si les lames peuvent

étre insérées à fond sans en laisser aucune partie à

découvert.

PSI5120_E 2009.7.31 9:33 AM 페이지 3

DIGITAL PA SYSTEM

PSI-5120/5240

Contents

Unpacking.......................................................................................................................................2

Installation

Environment....................................................................................................................................2

Important Safety Instructions.............................................................................................................2

Features............................................................................................................................................3

Additional Descriptions.................................................................................................................4

Front Panel ......................................................................................................................................5

Rear Panel.......................................................................................................................................9

Method to Connect Speakers ........................................................................................................11

Operating Method .........................................................................................................................12

1. Before using system .....................................................................................................................12

2. Tuner Operation .........................................................................................................................12

1) Manual / Auto Tuning Method ..................................................................................................12

2) Memory / Recall the Station.......................................................................................................12

3) FM Antenna Installation.............................................................................................................12

3. 1CD/6CD/USB/DRP Operation ...................................................................................................13

1) Play/Pause..............................................................................................................................13

2) Disc Check ..............................................................................................................................14

3) REPEAT ..................................................................................................................................14

4) RANDOM ..............................................................................................................................15

5) GROUP UP/DOWN ................................................................................................................15

6) DISPLAY .................................................................................................................................15

7) COPY ....................................................................................................................................15

8) RECORDING ..........................................................................................................................18

9) DELETE ..................................................................................................................................18

10) EQ Control function ...............................................................................................................19

Additional Function........................................................................................................................20

1. BUZZER Sound ON/OFF ...........................................................................................................20

2. AUTO PLAY Function.................................................................................................................20

3. FM MUTE .................................................................................................................................20

4. Memory Initialization.................................................................................................................20

Applications ..................................................................................................................................21

Specifications................................................................................................................................22

Method to Assemble Rack Bracket............................................................................................23

Service

Procedures ................................................................................................................................24

Schematic..................................................................................................................................24

Parts List.....................................................................................................................................24

Variations and Options...............................................................................................................24

Warranty .......................................................................................................................................24

PSI5120_E 2009.7.31 9:33 AM 페이지 4

DIGITAL PA SYSTEM

2PSI-5120/5240

Unpacking

Please take a few minutes to read this manual to familiarize yourself with important information regarding

installation, product features, and operation.

As with most electronic devices, ORIGINAL PACKAGING (OR EQUAL) IS REQUIRED in the unlikely event that

the product needs to be returned for servicing.

Installation

Environment

Never place this product in an environment which could alter its performance or reduce its service life. Such

environments usually include high levels of heat, dust, moisture, and vibration.

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including

amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades

with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide

blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult

an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and

the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.

When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is

damaged, liquid has been spilled or objects have fallen into the apparatus, the

apparatus has been exposed to rain or moisture, does not operate normally, or has

been dropped. S3125A

S3125A

PSI5120_E 2009.7.31 9:33 AM 페이지 5

DIGITAL PA SYSTEM

PSI-5120/5240

Features

- DIGITAL PROCESSING & DIGITAL AMPLIFIER

Adopting the Full Digital Amplifier enables to lower overall weight, power consumption and temperature

rise during operation.

- VARIOUS SOUND SOURCES

FM tuner and 1CD/6CDC/USB/DRP (flash memory) player are mounted, and there is AUX (1, 2) and

OPTICAL (IN/OUT). You can conveniently use various source.

- SPEAKER SELECT SWITCH (10 ZONE SPEAKER OUTPUT)

It is possible to use selective broadcasting and broadcasting with 10 speaker selection switches and a ALL

switch.

- AMX / CRESTRON INTERFACE (RS-232)

You can use AMX or CRESTRON control system with this interface.

- MIC PRIORITY

You can select 3 types of MIC priority modes as your preference.

- CHIME

Convenient to use to guide broadcasting before or after broadcasting.

- CD COPY

This function is used to copy music in a CD into inner memory or USB memory. You can greatly save the

lifetime of the CD mechanism.

- ANTI SHOCK SYSTEM

Adopting Anti Shock system provides strong resistance against sound bounce by shock.

- MP3/WMA

CD-DA, MP-3, WMA can be playbacked.

- USB HOSTING

Recording contents of a CD in USB memory and playing contents of USB memory is available.

- RECORDING (REC MEDIA)

Recording of broadcasting output in built-in memory or USB memory is available. You can save the

recording file of broadcasting to a PC using USB memory.

- IR REMOTE CONTROL SENSOR (REMOTE CONTROL SEPARATELY SOLD)

Remote control is available using the remote control.

- RACK MOUNTABLE (RACK BRACKET SEPARATELY SOLD)

Separate rack bracket (BKT-PSI5120) can be assembled for rack mounting. (See page 23)

PSI5120_E 2009.7.31 9:33 AM 페이지 6

DIGITAL PA SYSTEM

4PSI-5120/5240

Additional Descriptions

�MP3 (MPEG Audio Layer-3)

MP3 is one of music file formats that can contain music with stereo sound quality as good as audio CD,

which is a type of MPEG as audio, video compression standards. Compression rate is 1Mb by 1 minute

and thus about 3~ 5 minutes are sufficient if recording songs of 3~ 5 min or so. Differently from audio CD,

a music file made of MP3 can contain over 130 songs for popular songs or folk songs and playing time is

also about 10 hours. MP3 clears frequency range for a human being not to discernable and so has

advantage to compact it to 1/12 or so while maintaining music as sound quality equivalent to CD level. For

example, deriving a song in a music CD while maintaining music as sound quality equivalent to CD level

becomes capacity of 50MB or so but if compressing and converting it to a MP3, size of the MP3 largely

reduces to 4~5MB.

�WMA (Windows Media Audio)

WMA is a multimedia compression method developed by Microsoft Corporation and is technology to

compress only music from 'Window Media Technologies', and provides same sound quality as format of

MP3 up to 128Kbps, which has lower 64Kbps format than MP3.

In other words, it has a file size of the half of the MP3 and provides same sound quality as MP3.

�Digital I/O and standards

Replaces electrical digital signal with optical signal by coaxial cables, semi-conductor laser or light emitting

diode (LED), and connect to other devices with optical fiber cables. The unit that receives optical signal

changes optical signal to electrical signal for various processing. If transmitting digital data as they are,

data errors are little since it is not less affected by electrical noise than electrical signal.

Digital interface used in this product is a form of S/PDIF(Sony/Philips Digital Interface), complying with

standards called as IEC958.

PSI5120_E 2009.7.31 9:33 AM 페이지 7

DIGITAL PA SYSTEM

PSI-5120/5240

Front Panel

1. USB TERMINAL

This is a terminal to connect USB memory. Copying a CD to USB, saving files from the internal memory to

USB or recording a broadcasting to USB or internal memory is available. Music files saved in memory can

be played directly using USB function.

2. TONE CONTROL VOLUME

This is a volume to control tone of signal. You can adjust each frequency band such as

200Hz/500Hz/1.2KHz/3KHz/8KHz. Select the relevant frequency with the tone button and control volume

with the (+/-) button. (Control range: ±8dB)

3. EQUALIZER MODE SELECT BUTTON

If pressing this button once, you can check setting status of the current EQ mode. Whenever you press the

button, the mode changes in order of USER 1 →USER 2 →USER 3 →USER 4 →USER5 →OFF. After

adjusting the tone, press the button long (about 2 seconds), then the setting is saved in the relevant mode.

4. DISPLAY

This is a window to display system information of the operation.

5. INPUT SELECT (FUNCTION) BUTTON

This is a button to select input signal and you can select one of FM TUNER, 6CD, 1CD, USB, DRP, AUX 1, AUX

2, or DIGITAL INPUT. AUX 1/2 is changed whenever pressing the AUX button.

6. DISPLAY MODE SELECT BUTTON

This button displays time for the music currently played, folder name for MP3/WMA, music name, numbers

of all music, group name or track name and playing time of the whole music of a disc.

This cannot be used in using 6CD and Hangul (Korean character) is not supported.

PSI5120_E 2009.7.31 9:33 AM 페이지 8

DIGITAL PA SYSTEM

6PSI-5120/5240

7. TUNER FUNCTION BUTTON

1) PRESET -/+: Button to select the memorized broadcasting frequency.

2) MEMO: Button to memorize the broadcasting frequency.

3) FREQUENCY ▼/▲: Button to select the broadcasting frequency to tune..

8. SPEAKER SELECT BUTTON

There are 10 speaker selection buttons and one ALL selection button. It is convenient to broadcast to some

selective areas or to all areas.

9. POWER SWITCH

This is the button to turn on or off the power. If turning on this switch, display lights on and the unit starts to

operate. If turning off the switch, the unit becomes Standby status.

10. MONITOR SPEAKER SELECT BUTTON

You can check broadcast output status through a monitor speaker. You can select the level by 2 steps (+2, +1).

Whenever pressing the button, the mode changes in order of OFF →+1 →+2 →OFF.

When you adjust the source volume, then the monitor speaker level is changed. Main volume has no effect on

the monitor speaker level.

11. MASTER VOLUME

Adjust the signal level of the speaker outputs.

12. MIC 1 INPUT

This is the balanced input.

Input Level : -60dBV ~ -16dBV

The phantom switch must be off or not the line level source may be damaged.

13. SOURCE VOLUME

This is a volume to control volume of the TUNER/CD/USB/AUX/DIGITAL input.

14. MIC VOLUME

This is a volume to control volume of MIC input CH 1 ~ 5.

15. CHIME BUTTON

This is two-step scale and it is convenient when using it for guide broadcast before broadcasting.

16. HOLD BUTTON

This is a button to protect main function from careless operation. “HOLD ON” is displayed in the display if

pressing this button and some functions are non-operable.

Relevant function is as follow:

※Power Supply Switch, Speaker Select Button, MIC/SOURCE Volume Control, Main Sound Control Volume

and CD Eject Button. If pressing the HOLD button once again, “HOLD OFF” is displayed on the display and

the relevant function is released.

17. RECORD & ERASE FUNCTION BUTTON

This is a button used for broadcasting or recording contents of lecture which are saved in the relevant memory

as MP3 file.

PSI5120_E 2009.7.31 9:33 AM 페이지 9

DIGITAL PA SYSTEM

PSI-5120/5240

1) Memory select switch

This is a switch to position to save contents of recording and is used for selecting USB or DRP(inner memory).

2) REC/PAUSE button

This is a button used to perform Recording Stop and Pause function.

3) STOP/ERASE Button

This is a button used to stop recording or delete files saved in USB and DRP memory.

18. CD / USB / DRP FUNCTION BUTTON

The button available lights depending on function selected.

1) ▶(Play) Button

This is a button to playback.

2) I

◀◀

▶▶

I (SKIP DOWN/UP) Button

This is a button to search for music before or after the music played.

3) ■(Stop) Button

This is a button to stop playing.

◀◀

▶▶

(SEARCH DOWN/UP) Button

This is a button to move forward or backward from a track during play a disc. Keep pressing this button to

find the position you want to play.

5) II (Pause) Button

This is a button to pause playback. Press the ▶(Play) button to playback continuously.

6) COPY Button

This button is used for copying a CD to USB or DRP, and file copy is also available between USB and DRP.

7) ENTER Button

This button is used for Copy or Erase operation. The relevant operation starts if pressing this button.

8) DISC ▲/▼(DISC UP/DOWN) Button

This button is used only in 6CD function. You can select and play a desired disc among 6 discs. Pressing the

▲(DISC UP) button enables to move to the next disc. Pressing the ▼(DISC DOWN) button enables to move

to the previous disc.

9) GROUP △/▽(UP/DOWN) Button

This button is used for retrieving between folders which have MP3 or WMA files.

10) RANDOM Button

This button is used when playing songs in a disc randomly.

11) REPEAT Button

This button is used to playback music in Repeat Mode.

19. 6CD MAGAZINE EJECT BUTTON

This button is used to out 6CD Magazine.

20. DISC MAGAZINE INSERT SLOT

This is an insert slot of 6CD Disc Magazine. Disc magazine is mounted if lightly pushing it into the slot for insertion.

21. 6CD DOOR

The magazine insert slot is seen if lowering the handle with light force. Always close the door when using

magazine after insertion.

PSI5120_E 2009.7.31 9:33 AM 페이지 10

DIGITAL PA SYSTEM

8PSI-5120/5240

22. DISC INSERT SLOT

This is the insert slot of a Disc.

If you put a Disc in the slot, then the disk is automatically entered into the slot.

23. 1CD DISC EJECT BUTTON

This button is used to take out a disc.

PSI5120_E 2009.7.31 9:33 AM 페이지 11

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Inter-m Système de haut-parleurs

Inter-m

Inter-m PM-6228 Manuel utilisateur

Manuels Système de haut-parleurs populaires d'autres marques

JVC

JVC CA-MXK5R Manuel utilisateur

LG NB4532B Manuel utilisateur

JVC

JVC CA-FSH100 Manuel utilisateur

5Core

5Core Pro Series Manuel utilisateur

EAW

EAW MQV1394e Manuel utilisateur

Lynx

Lynx GXR-LA10A Manuel utilisateur

iLive

iLive ITB066B Manuel utilisateur

RDX

RDX QuickStation 4 Manuel utilisateur

Electro-Voice

Electro-Voice S-122 Manuel utilisateur

Sven

Sven SPS-619 GOLD Manuel utilisateur

Pioneer

Pioneer CS-7070 Manuel utilisateur

EAW

EAW UB82e Manuel utilisateur

Sondpex

Sondpex Active Speaker System and Digital Music... Manuel utilisateur

JVC

JVC NX-PN7 Manuel utilisateur

Marshall Amplification

Marshall Amplification AR-DM61-BT Manuel utilisateur

Yamaha

Yamaha NX-A01 - Speaker Sys Manuel utilisateur

SE Audiotechnik

SE Audiotechnik I-LINE Manuel utilisateur

Gemini

Gemini WRX-843 Series Manuel utilisateur
