Inter-m V2-1000 Manuel utilisateur
V2 SERIES
Professional Power Amplifier
V2-1000 / 2000
Professional Power Amplifier
V2 Series amplifier is Inter-M power amplifier line up for professional audio market with stable
SMPS (Switch Mode Power Supply) applied for low power consumption and light weight, also provides
powerful and high quality sound based on high damping factor.
features
• Stable SMPS(Switch Mode Power Supply) applied for low power consumption and light weight
• Compact 2U size and light weight
• Includes protection circuit to prevent a damage of over heat, short and over voltage
• High Damping Factor and low T.H.D (0.05%)
• 2Ω-load stable per channel, 4Ω-load stable in bridged mono
• S / N - Better than 106dB
• Front panel indicators for output signal, clip, protect and power
• Voltage gain selectable
• 30Hz or 50Hz HPF to protect speaker from low-frequency & Clip Limiter
*Specifications and design subject to change without notice for improvements.
specification
V2-1000 V2-2000
STEREO
8Ω (1kHz, THD 1%) 170W 280W
4Ω (1kHz, THD 1%) 300W 500W
2Ω (1kHz, THD 1%) 550W 850W
BRIDGED
8Ω (1kHz, THD 1%) 650W 1000W
4Ω (1kHz, THD 1%) 1100W 1700W
DAMPING FACTOR ≥380 ≥400
POWER SOURCE AC 220V, 60Hz AC 220V, 60Hz
POWER CONSUMPTION
1/8 power @4Ω 3A 4A
S/N (@8Ω) 106dB 106dB
Weight 10.7kg 10.9kg
Dimensions 482 (W) x 88 (H) x 407 (D) mm 482 (W) x 88 (H) x 407 (D) mm
V2-3000 / 4000
Professional Power Amplifier
V2 Series amplifier has efficient circuit design and great view of front panel for the professional audio
market, also provides powerful and high quality sound based on 2U slim rack size.
features
*Specifications and design subject to change without notice for improvements.
• Stable SMPS(Switch Mode Power Supply) applied for low power consumption and light weight
• Compact 2U size and light weight
• For better efficiency, 2-step of H-class AMP accepted
• Includes protection circuit to prevent a damage of over heat, short and over voltage
• High Damping Factor and low T.H.D(0.05%)
• 2Ω-load stable per channel, 4Ω-load stable in bridged mono
• S / N - Better than 106dB
• Front panel indicators for output signal, clip, protect and power
• Voltage gain selectable
• 30Hz or 50Hz HPF to protect speaker from low-frequency & Clip Limiter
specification
V2-3000 V2-4000
STEREO
8Ω (1kHz, THD 1%) 500W 700W
4Ω (1kHz, THD 1%) 900W 1200W
2Ω (1kHz, THD 1%) 1500W 1900W
BRIDGED
8Ω (1kHz, THD 1%) 1800W 2400W
4Ω (1kHz, THD 1%) 3000W 3800W
DAMPING FACTOR ≥400 ≥400
POWER SOURCE AC 220V, 60Hz AC 220V, 60Hz
POWER CONSUMPTION
1/8 power @4Ω 6A 7A
S/N (@8Ω) 106dB 106dB
Weight 12kg 12.1kg
Dimensions 482 (W) x 88 (H) x 407 (D) mm 482 (W) x 88 (H) x 407 (D) mm
V2-5000
Professional Power Amplifier
V2 Series amplifier has efficient circuit design and great view of front panel for the professional audio
market with stable SMPS (Switch Mode Power Supply) applied for low power consumption and light
weight, also provides Clip limiter, HPF to protect speaker from low-frequency.
features
• Stable SMPS(Switch Mode Power Supply) applied for low power consumption and light weight
• For better efficiency, 2-step of H-class AMP accepted
• Compact 2U size and light weight
• Includes protection circuit to prevent a damage of over heat, short and over voltage
• High Damping Factor and low T.H.D
• 2Ω-load stable per channel, 4Ω-load stable in bridged mono
• S / N - Better than 106dB
• Has 30Hz or 50Hz HPF to protect speaker from low-frequency
• Front panel indicators for output signal, clip, protect and power
• Voltage gain available
specification
V2-5000
STEREO
8Ω (1kHz, THD 1%) 1000W
4Ω (1kHz, THD 1%) 1700W
2Ω (1kHz, THD 1%) 2500W
BRIDGED
8Ω (1kHz, THD 1%) 3400W
4Ω (1kHz, THD 1%) 5000W
Frequency Response ±0.5 dB (20 Hz~20 kHz)
Input Sensitivity 1.4V
Voltage Gain(@ 8Ω) 36dB
T.H.D(@ 1/3 Power) < 0.1% (20 Hz~20 kHz)
S/N (@8Ω) > 106dB
Weight 12.5kg
Dimensions 482 (W) x 88 (H) x 407 (D) mm
*Specifications and design subject to change without notice for improvements.
Inter-M Corporation (IMK)
653-5 Banghak-Dong, Dobong-Ku, Seoul, Korea
Overseas Sales Team
Tel : +82-2-2289-8141~7 / Fax : +82-2-2289-8149 / E-mail : [email protected]
♣Specifications and design subject to change without notice.
www.inter-m.com
2011. 03
