Intellisystem IT-IMC-102B Manuel utilisateur

IT-IMC-102B

Industrial fast Ethernet

Media converter

User manual

【Introduction】

IT-IMC-102B is an industrial fiber optic transceiver which

supports 1 port 10/100Base-TX Ethernet and 1 port 100Base-FX

optic fiber. LED light system status display can help the system

maintain monitor the connection status of the network. IMC101B

meet the FCC and CE standard. -40~75℃operating temperature

range can adapt to poor working condition. Guide rail installation

characteristics, to meet the demand of the industrial field, can

provide users to connect the Ethernet device with reliable and fast

solution.

【Packing List】

Please check the packaging is intact and the attachment is

complete when you first use the product.

Intellisystem Industrial fiber optic transceiver

IT-IMC-102B ×1

Manual×1

Warranty Card×1

The equipment built-in precision devices, please note gently,

avoiding excessive vibration to avoid affecting device

performance. If you find the equipment was damaged in transit or

any parts are missing, please inform our company or the dealer,

we will give you proper solution as soon as possible.

【Features】

1. Support 1 port 10/100Base-TX Ethernet and

1 port 100Base-FX optic fiber.

2. Support IEEE802.3/802.3u/802.3x, store and forward.

3. Support 10/100M, F/H duplex, MDI/MDI-X

auto negotiation.

4. DC12~48V power input, opposite connection protection.

5. IP30 protection, corrugated type-high strength metal shell,

DIN-Rail installation.

【Panel Design 】

Vertical view

Main view Vertical view

Back view Right view

1. 10Base-T/100Base-TX Ethernet port.

2. Company name, products name.

3. 100Base-FX fiber port.

4. Ethernet/fiber port indicator.

5. PWR indicator.

6. Power supply input (3-bit terminal block).

7. DIN-Rail.

8. Ground screw.

【Dimensions】

Units（mm）

【Communication Interface】

10Base-T/100Base-TX Ethernet Interface

10Base-T/100Base-TX Ethernet interface is located in the front

panel of the equipment. Interface type is RJ45, the PIN define of

RJ45 port display as flow, connect by UTP or STP. The connect

distance is no more than 100m. 100Mbps is used 100Ω of UTP 5,

10Mbps is used 100Ω of UTP 3, 4, 5.

RJ45 port support automatic MDI/MDI-X operation can connect

the PC, Server, Converter and HUB. Pin 1,2,3,6 corresponding

connection in MDI.1→3, 2→6, 3→1, 6→2 are used as cross

wiring in the MDI-X port of Converter and

HUB.10Base-T/100Base-TX are used in MDI/MDI-X, the define

of PIN in the table as below.

MDI

signal

MDI-X

signal

TX+

RX+

TX-

RX-

RX+

TX+

RX-

TX-

4, 5, 7, 8

—

Note：“TX±”transmit data±，“RX±”receive data±，“—”not use。

MDI (straight-through cable):

MDI-X (cross over cable)

1 8

MDI/MDI-X auto negotiation user-friendly IT-IMC-102B’s

10/100Base-TX Ethernet interface regardless of the type of

Ethernet cable can be directly via crossover cable or straight lines

to achieve IT-IMC-102B fiber optic transceivers and connection

between devices.

100Base-FX Fiber port

100Base-FX full-duplex SM or MM port. SC/SF/FC type. The

optical fiber connection supports the line to instruct enhance the

reliability of network effectively.

Suppose: If you make your own cable, we suggest labeling the

two sides of the same line with the same letter (A-to-A and

B-to-B, shown as below, orA1-to-A2 and B1-to-B2).

【LED Indicator】

LED indicator light on the front panel of IT-IMC-102B. The

function of each LED is described in the table as below:

System status LED

LED

Indicate

Description

PWR

（Green）

Connect power supply

OFF

Disconnect power supply or

unwonted

1~3

（LINK/ACT）

Establish effective network

connect

Glitter

In activity status

OFF

No-establish effective

network connect

【Specifications】

Technology:

Standard: IEEE802.3, IEEE802.3u, IEEE802.3x

Flow control: IEEE802.3x control, back pressure control

Ports:

Ethernet ports:

10Base-T/100Base-TX, RJ45, automatic flow control,

F/H duplex and MDI/MDI-X auto connection

Fiber ports: 100Base-FX ports (SC/ST optional)

Exchange Properties:

100M forwarding rate: 148810pps

Transmit type: store and forward

System switching bandwidth: 400M

Cache size: 64Kbits

MAC address: 2K

LED Indicator:

Interface light: 1~3 (LINK/ACT)

Power light: PWR

Transmission distance:

Twisted-pair: 100M (normal CAT5/CAT5e cable)

Multi-mode fiber: 2Km

Single-mode fiber: 20-120Km

Power:

Input Voltage: 24VDC (12～48VDC)

Access terminal: 3 cores 7.62mm distance between terminals

No-load power: 1.2W@24VDC

Full-load power: 1.536W@24VDC

Support opposite connection protection

Working Environment:

Working Temperature: -40~75℃

Storage Temperature: -40~85℃

Ambient Relative Humidity: 5~95 %( non-condensing)

Mechanical Properties:

Shell: IP30 protection, corrugated, high strength metal case

Installation: DIN-Rail

Weight: 346g

Dimensions (D×W×H): 95 mm×35mm×110mm

Industrial Standard:

EMI: FCC Part 15, CISPR (EN55022) class A

EMS: EN61000-4-2 (ESD), Level 4

EN61000-4-3(RS), Level 3

EN61000-4-4 (EFT), Level 4

EN61000-4-5 (Surge), Level 4

EN61000-4-6(CS), Level 3

EN61000-4-8(PFM), Level 5

Shock: IEC 60068-2-27

Free Fall: IEC60068-2-23

Vibration: IES 60068-2-6

Warranty:

Warranty time: 5 years

Approvals:

CE, FCC, RoHS, UL508 (Pending)
