Intellian FB250 Manuel utilisateur

Global Leader in Marine Satellite Antenna Systems

FB250/FB500

Installation and Operation User Guide

Serial number of the product

This serial number will be required for the all troubleshooting or service inquiries.

logo are trademarks of Intellian Technologies, Inc., registered in the U.S. and

other countries. All other logos, trademarks, and registered trademarks are the

property of their respective owners. Information in this document is subject to

change without notice. Every effort has been made to ensure that the information

in this manual is accurate. Intellian is not responsible for printing or clerical

errors.

Doc. No. 2014FB-UM1222-V2_3

LIST OF CONTENT

REGULATORY INFORMATION 4

INTRODUCTION 7

Introduction 8

Overview of the Fleetbroadband 10

Main units 11

INSTALLATION 17

Installation 18

Connections 27

GETTING STARTED 31

Getting started 32

Using the primary handset 37

Using the web console 71

Using the network management 134

TROUBLESHOOTING 159

TECHNICAL SPECIFICATION 165

WARRANTY 166

FB250/500 User Manual

FCC Identier: QO4-AVIFX500BDE / QO4-AVIFX250BDE

USE CONDITIONS:

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two Conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that

may cause undesired operation.

NOTE:

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installa-

tion. This equipment generates uses and can radiate radio frequency energy and,

if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that inter-

ference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is encour-

aged to try to correct the interference by one of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

IMPORTANT NOTE: EXPOSURE TO RADIO FREQUENCY RADIATION

This Device complies with FCC & IC radiation exposure limits set forth for an un-

controlled environment. The Antenna used for this transmitter must be installed to

provide a separation distance of at least 100cm from all persons and must not be

co-located or operating in conjunction with any other antenna or transmitter.

FCC CAUTION:

Any Changes or modications not expressly approved by the manufacturer could

void the user's authority, which is granted by FCC, to operate this satellite Fleet-

Broadband System FB250 / FB500.

REGULATORY INFORMATION

FEDERAL COMMUNICATION COMMISSION NOTICE

IC: 5023B-AVIFX500BDE / IC: 5023B-AVIFX250BDE

This device complies with Radio standard specication RSS -170 of Industry Can-

ada Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that

may cause undesired operation.

IMPORTANT NOTE: Radiation Exposure Statement

This equipment complies with IC radiation exposure limits set forth for an uncon-

trolled environment. This antenna used for this transmitter must be installed to

provide a separation distance of at least 100cm from all persons and must not be

co-located or operating in conjunction with any other antenna or transmitter.

EC Declaration of Conformity:

Intellian Technologies, Inc., 348-5 Chungho-ri, Jinwi-myeon, Pyeongtaek-Si,

Gyeonggi-do, Korea 451- 862 declares

under our sole responsibility that the accessory Product, brand name as Intellian

and models:

FB250 / FB500 FleetBroadband satellite communication system, to which this

declaration relates, is in conformity with the following standards and/or other nor-

mative documents:

RoHS2 Directive 2011/65/EU

ETSI EN 301 444, ETSI EN 301 489-1, -17,-19 & -20, ETSI EN 300 328 IEC 60945

/ EN 60945,

IEC 60950-1 AND EN 60950-1, ITU-R M.1480

We hereby declare that all essential radio test suite have been carried out and

that the above named product is in conformity to all the essential requirements of

Directive 1999/5/EC.

The Conformity Assessment procedure referred to Article 10 and detailed in An-

nex [III] or [IV] of Directive 1999/5/EC has been followed with involvement of the

following notied body (ies):

TIMCO ENGINEERING Inc., P.O BOX 370, NEWBERRY, FLORIDA 32669. Iden-

tication mark: 1177 (Notied Body number)

INDUSTRY CANADA STATEMENT:

FB250/500 User Manual

INTRODUCTION

Introduction

Overview of the Fleetbroadband

Main units

FB250/500 User Manual

The Intellian FB250 / FB500 User Equipment is a dedicated compact solution

specically designed to meet the FleetBroadband ( FBB ) services for the maritime

environment providing seamless ocean coverage from 76° North to 76° South.

FBB is the marine version of the highly successful BGAN (Broadband Global Area

Network) from Inmarsat.

Through a maritime BGAN antenna, it provides constant, simultaneous access to

voice and high-speed data in a compact solution. Allowing you to run online oper-

ation systems, and still having access to email, intranet and voice calls - achieving

greater operational efciencies and signicantly reducing the cost of both busi-

ness and crew communications.

1. INTRODUCTION

• Email and webmail

• Secure communications

• Intranet and internet access

• SMS and instant messaging Videoconferencing and streaming

Phoneand fax services

• Large le transfers

1.1 Range of Service

Note: Radome dimension can be vary by different matching dome option.

1.2 Features

The FB250/500 offers the following features

The UE has built-in Web Console, allowing you to manage your phone book, mes-

sages and calls, and customize the terminal to your specic needs.

1.3 Interfaces

The FB250/500 UE has the following connecting interfaces:

• +12V / 24V DC Power Input Connector

• Antenna Connector (ADU : N-Type, BDU : N-Type)

• SIM Card Slot for FBB SIM card

• Dedicated Primary Handset port

• I/O Port

• GPS Output Port

The number of RJ45 Ethernet ports and RJ11 ports for the BDUs of the FB250

and FB500 is illustrated below:

Service FB250 FB500

Coverage Voice, fax and data are available globally except for the extreme polar regions

Voice 4kbps AMBE + 2

3.1KHz Audio (above 20° elevation)

4kbps AMBE + 2

3.1KHz Audio (above 5° elevation)

Fax Group 3 fax via 3.1KHz Audio

(above 20º elevation)

Group 3 fax via 3.1KHz Audio.

(above 5º elevation)

SMS Standard 3G (up to 160 characters) per SMS. Maximum of 4 chained SMS.

Data Standard IP : Up to 284 kbps

Streaming IP : 8, 16, 32, 64,128 kbps

Standard IP : Up to 432 kbps

Streaming IP : 8, 16, 32, 64, 128, 256 kbps

RJ45 Ethernet Ports for PC and router 4 LAN Ports (including 2 PoE)

RJ11 Phone Yes

RJ11 Fax Yes

Built-in WiFi Yes

FB250/500 User Manual

BGAN Services

The Broadband Global Area Network (BGAN) is a global Satellite Internet Network

using portable terminals. The terminals are usually connected to a laptop comput-

er to access broadband Internet in remote locations, where a line-of-sight to the

satellite exists. The user can make phone calls, access the Internet, check e-mail,

download les, or perform any other Internet activity using the terminals. The

network is provided by Inmarsat and uses three geostationary satellites called I-4

to provide almost global coverage.

The map below shows the three I-4 satellite coverage regions.

FleetBroadband coverage

Note: The above map depicts Inmarsat’s expectations of coverage, but does not

represent a guarantee of service. The availability of service at the edge of coverage

areas uctuates depending on various conditions.

2. OVERVIEW OF THE FLEETBROADBAND

This map depicts Inmarsat’s expectations of coverage, but does not represent a guarantee of service.

The availability of service at the edge of coverage areas uctuates depending on various conditions.

I-4 Americas I-4 EMEA I-4 Asia-Pacifc
