1
Content Access Point
User Guide
Ver. 1.2.24 for WRTD-303N
Ver. 2.2.15 for WAPD-235N
Update Firmware to
Content Access Point
User Guide
Contents
1Firmware Release Information………………………………………………………………………………………………..2
1.1 Introduction……………………………………………………………………………………………………………………………….2
1.2 V e r s i o n ……………………………………………………………………………………………………………………………………….2
2Firmware Update Steps…………………………………………………………………………………………………………….3
2.1 Update an operating device……………….……………………………………….………………………………….3
2.2 Update a whole new device………………….………………………………………………………………………….5
2
Content Access Point
User Guide
1Firmware Release Information
1.1 Introduction
This guide contains update instruction for newly released firmware (Please check the Table 1 for selecting the
right version.), which will improve battery life and generate better performance on Content Access Point. It is
highly recommended for all users to update firmware to the latest version immediately.
1.2 Version
Table 1: New Firmware Version
Model Name
Firmware Version
WRTD-303N v1.2.24
WAPD-235N v2.2.15
Note: Please check the button on the device to find the Model name
Figure 1: Check Model Name
Model Name
3
Content Access Point
User Guide
2Firmware Update Steps
2.1 Update an operating device
CAUTION: The device will reboot as part of the firmware update process. This will temporarily disrupt
network and content access for users.
1. Wirelessly connect to the device using its SSID.
2. Launch a browser and go to http://my.admin.
3. Go to Device Management > Firmware Update. (See Figure 2.)
4. Select the method of supplying the firmware file. (Please check Table 1 for selecting the right version.)
a. Upload the file from the local computer
b. Use a USB flash drive. For this method, format a USB flash drive (NTFS or FAT32), put the file on it,
plug it into the USB port of the device, and refresh the Device Management page. The file will appear
following “Update firmware from USB port”.
Note: The firmware update file’s extension must be “.tgz”. If the browser changed the file’s extension during
the download process, change it back to “.tgz”.
5. Click Update and wait a couple of minutes for the upgrade to complete.
Figure 2: Admin –Device Management
4
Content Access Point
User Guide
6. Verify that the upgrade was successful by logging on and checking the firmware version on the Dashboard.
Figure 3: Check Firmware Version
7. Disconnect the power supply and leave the power ON for at least 2 hours.
Note: Device can be operated within this period.
Note: If the battery runs out of power within 2 hours, go to step 8 directly.
Figure 4: Disconnect the power supply
8. Update process finished, connect the power supply back and the device can be operated as usual.
5
Content Access Point
User Guide
2.2 Update a whole new device
1. Take out the Content Access Point, connect the power supply.
Figure 5: connect the power supply
2. Power up the device by pressing and holding the power button for two seconds.
Figure 6: Power button
3. Wirelessly connect to the device using its default SSID. The default SSID is Model Name_xxxxxx (Please
see Figure 1 to find the Model Name), where “xxxxxx” is the last six digits of the Wi-Fi MAC address
(WFM), which is printed on the bottom of the device. For example, for a device with a WFM of
F835DD85457A, the wireless SSID is WRTD-303N_85457A.
4. Launch a browser and go to http://my.admin (or http://192.168.88.1:8080).
5. Enter username admin and password admin.
6. Change the admin default password when prompted.
Figure 7: Admin –Wirelessly connect to the Content Access Point
6
Content Access Point
User Guide
7. Skip or finish the setup wizard.
Figure 8: Admin –Setup wizard
8. Go to Device Management > Firmware Update. (See Figure 2.)
9. Select the method of supplying the firmware file.
c. Upload the file from the local computer
d. Use a USB flash drive. For this method, format a USB flash drive (NTFS or FAT32), put the file on it,
plug it into the USB port of the device, and refresh the Device Management page. The file will appear
following “Update firmware from USB port”.
Note: The firmware update file’s extension must be “.tgz”. If the browser changed the file’s extension during
the download process, change it back to “.tgz”.
10. Click Update and wait a couple of minutes for the upgrade to complete.
7
Content Access Point
User Guide
Figure 1: Admin –Device Management
11. Verify that the upgrade was successful by logging on and checking the firmware version on the Dashboard.
Figure 3: Check Firmware Version
12. Update process finished.
