6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 1 of 12

Intel®Server Systems

SR4850HW4S and SR6850HW4S

Configuration Guide

Rev 3.03

A reference guide to assist customers in ordering components to configure

SAS 3.5” Harwich 800T-based server systems - RoHS compliance w/ server exemption.

SR4850HW4S = Harwich 800T 4U Server SAS 3.5

SR6850HW4S = Harwich 800T 6U Server SAS 3.5

Revisions/Additions in blue font

6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 2 of 12

1. Table of Contents

1. Table of Contents..................................................................................................................2

2. Revision History....................................................................................................................3

3. Important Notes ....................................................................................................................3

4. System Configuration Options............................................................................................4

5. 4U System Part Configurator: SR4850HW4S.....................................................................5

6. 6U System Part Configurator: SR6850HW4S.....................................................................6

7. Base System SKU Configuration Contents........................................................................7

7.1 Table 1: Base System Product Code Contents........................................................7

8. Complete Product Ordering Code Listings........................................................................8

8.1 Table 2: Base System Codes...................................................................................8

8.2 Table 3: Common System Accessory Codes...........................................................9

8.2.1 Table 4: 4U Unique Accessory Codes for SHW4URM3SA...................................10

8.2.2 Table 5: 6U Unique Accessory Codes for SHW6URM3SA...................................10

8.3 Table 6: Common System Spare Part Codes........................................................10

8.3.1 Table 7: 4U 3.5“ SAS Unique Spare Part Codes for SHW4URM3SA....................11

8.3.2 Table 8: 6U 3.5” SAS Unique Spare Part Codes for SHW6URM3SA....................11

8.4 Table 9: Boxed Processor Codes Reference (Heatsink Included).........................11

8.5 Table 9: Trayed Processor Codes Reference (Requires Heatsink- AHWPROCHS)12

6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 3 of 12

2. Revision History

Date Rev Modification

Mar 23, 2005 1.1 Corrected system DVD from a DVD/CDRW to a DVD-ROM.

Sept 27, 2005 2.0 Harwich 800T revisions.

Apr 24, 2006 2.7 Harwich 800T MM#s revised, DVD spare

Apr 25, 2006 3.0 Harwich 800T SAS MM#s added

Sept 25, 2006 3.01 Updated Boxed and Tray Processor Reference Codes

Oct 25, 2006 3.02 Updated BHWBASEM MM#

Apr 3,2007 3.02 Updated SHW4URM3SA and SHW6URM3SA MM#

3. Important Notes

1. The SRx850HW4S boardset is ordered and shipped as two separate boards. The two boards are the baseboard and the

memory board. Each system can accommodate up to four memory boards. System SKUs include one memory board in

the base configuration.

2. The 6U server platform SR6850HW4S (product code SHW6URM3SA) comes preconfigured with 1 power supply and an

empty second power supply bay. The second power supply bay must be filled with either a second power supply

(AHW6UPWR) or a power bay fan (AHW6UPWRFAN).

3. Systems will not ship with processors, hard drives, or memory. These parts must be obtained separately from the system.

4. VRMs are not included with the platform.

5. Heat sinks are not included with the platform.

6. Processor thermal blanks must be ordered separately (if no processor is installed).

7. Either a Button Control Panel or Intel®Local Control Panel must be ordered for installation in the system.

8. Intel®Server Management Professional or Advanced modules must be ordered for installation in the system.

9. The SRx850HW4S memory board supports DDR2 400 SDRAM registered DIMMs.

10. The Intel factory will package board orders into single order packaging and ship to fill customer orders. Each board MM is a

self-contained shipping package of one board.

11. Power cords are not shipped with the system and must be obtained from local suppliers. Please review the power cord

enabling documents on support.intel.com, they cover all the countries that we intend to sell the product and have how to

order the correct cable:

http://support.intel.com/support/motherboards/server/sr6850hw4/sb/cs-020878.htm

http://support.intel.com/support/motherboards/server/sr4850hw4/sb/cs-020879.htm

12. All parts listed below are RoHS compliant with server exemption.

4. System Configuration Options

Mandatory Accessories

Optional Accessories

IMM

Professional IMM

Advanced

Bezels

SR4850HW4S

4U Platform SR6850HW4S

6U Platform

Fibre Channel

Module Up to 3 additional

memory boards.

LCD Control

Panel

Button Control

Panel

Pedestal Kit (6U)

Rack Rails and

CMA

2nd Power

Supply

6U Only

Active Fan

Blank

ROMB Key and

Battery

6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 4 of 12

6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 5 of 12

5. 4U System Part Configurator: SR4850HW4S

Mandatory Accessories

Feature Product

IMM Professional

AHWIMMPRO2

Intel Management Module

(Choose one per System) IMM Advanced

AHWIMMADV2

Button control panel

AXXBCPMOD2

Control Panel

(Choose one per System) LCD control panel

AXXLCPMOD2

Processor heat sink

AHWPROCHS

NOTE: Boxed processors include this heat sink.

Processor

Heat Sinks and Blanks

(All 4 sockets must have Processor + Heatsink

Processor Blank) Processor blank

AHWPROCBLANK

Processor VRM

(Use with 3 and 4 processors)

Processor core 10.2 VRM

AHWVRMPM

(one required for each processor used in socket 3 and 4)

Processor cache 9DO VRM

AHWVRMCM

(one per system required for iL3 processor used in socket 3

and 4)

Optional Accessories

Feature Product

Intel® SAS RAID Activation Key

AXXRAK18E

RAID Solutions Intel® RAID Smart Battery

AXXRSBBU3

(only used with Activation Key above)

Fibre Channel Module Fibre channel module

AHWFCMOD

Rack rails

AXXRAIL3U7U

Rack Mount Solutions Cable Management Arm

AXXCMA3U7U

Memory board 4 DIMM memory board

BHW4DIMMM

Front Bezel 4U Front bezel for rack mount

AHW4URBEZEL

6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 6 of 12

6. 6U System Part Configurator: SR6850HW4S

Mandatory Accessories

Feature Product

IMM Professional

AHWIMMPRO2

Intel Management Module

(Choose one per System) IMM Advanced

AHWIMMADV2

Button control panel

AXXBCPMOD2

Control Panel

(Choose one per System) LCD control panel

AXXLCPMOD2

Processor heat sink

AHWPROCHS

NOTE: Boxed processors include this heat sink.

Processor

Heat Sinks and Blanks

(All 4 sockets must have Processor + Heatsink

Processor Blank) Processor blank

AHWPROCBLANK

Processor VRM

(Use with 3 and 4 processors)

Processor core 10.2 VRM

AHWVRMPM

(one required for each processor used in socket 3 and 4)

Processor cache 9DO VRM

AHWVRMCM

(one per system required for iL3 processor used in socket 3

and 4)

Power supply module. 6U. 15Amp, 110v/220v.

AHW6UPWR

6U Power Supply #2

Second power supply or a power fan.

(Choose one per System) Power bay fan. 6U.

AHW6UPWRFAN

Optional Accessories

Feature Product

Intel® SAS RAID Activation Key

AXXRAK18E

RAID Solutions Intel® RAID Smart Battery

AXXRSBBU3

(only used with Activation Key above)

Fibre Channel Module Fibre channel module

AHWFCMOD

Rack rails

AXXRAIL3U7U

Rack Mount Solutions Cable Management Arm

AXXCMA3U7U

Memory board 4 DIMM memory board

BHW4DIMMM

Front bezel for rack mount

AHW6URBEZEL

Front Bezel Front bezel for pedestal mount

AHW6UPBEZEL

6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 7 of 12

7. Base System SKU Configuration Contents

7.1 Table 1: Base System Product Code Contents

Product Code Description

SHW4URM3S

Intel® Server System SR4850HW4S (Harwich 800T SAS) 4U Rack.

•1x Baseboard

•1x Front Panel IO board

•1x Memory Board (1X4) plus bracket

•3x Memory Board Filler Baffles

•0x Intel Management Module (Professional IMM)

•2x Power Supply Module (15Amp, 208)

•1x 1/2" DVD-ROM Drive

•0x Button Control Panel

•1x SAS 4U Backplane Board

•1x Rack Faceplate (Granby)

•5x HDD Carrier (Black)

•1x Base Chassis (Granby)

•0x Power Supply Filler Panel

•0x Processor Thermal Dummy

•2x Fan Module

•1x SATA Cable (Base board to SATA/IDE conversion board)

•1x Front Panel Cable

•1x Drive Power Cable (Tape Backup and DVD-ROM)

•1x Fan Power Cable

•1x Internal SAS Cable (Base board to SAS Backplane)

•1x Internal SAS ROMB Module

•1x Sample Safety Label

•1x System Serial # Label

•1x System Packaging

•1x Rack Handles (Pair)

SHW6URM3S

Intel® Server Platform SR6850HW4S (Harwich 800T SAS) 6U Rack.

•1x Baseboard

•1x Front Panel IO board

•1x Memory Board (1X4) plus bracket

•3x Memory filler baffles

•0x Intel Management Module (Professional IMM)

•1x Power Supply Module (15Amp, 110/208)

•1x 1/2" DVD-ROM Drive

•0x Button Control Panel Board

•1x SAS 6U Backplane Board

•1x Rack Faceplate (Gilbert)

•10x HDD Carrier (Black)

•1x Base Chassis (Gilbert)

•0x Processor Thermal Dummy

•6x Fan Module

•1x SATA Cable (Base board to STAT/IDC conversion board)

•1x Front Panel Cable (SCSI to Front Panel)

•1x Drive Power Cable (Tape Backup and DVD-ROM)

•1x Fan Power Cable

•1x Internal SAS Cable (Base board to SAS Backplane)

•1x Internal SAS ROMB Module

•1x Front Connect Cable (100-pin) (Base board to front panel IO board)

•1x Sample Safety Label

•1x System Serial # Label

•1x System Packaging

•1x Rack Handles (Pair)

8. Complete Product Ordering Code Listings

The following table lists all of the product codes applicable to the Harwich platform (sorted by category). Following

the table are individual document sections which provide additional product descriptions for each product code.

8.1 Table 2: Base System Codes

Image Product Code MM /

UPC Description Qty

Per Min

Order

SHW4URM3SA 886995

Intel® Server System SR4850HW4S. 4

Socket, 4U, SAS 3.5" 1 1

SHW6URM3SA 887385

Intel® Server System SR6850HW4S. 4

Socket, 6U, SAS 3.5" 1 1

6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 8 of 12

8.2 Table 3: Common System Accessory Codes

Image Product Code MM /

UPC Description Qty

Per Min

Order

AXXRAK18E 877661

Intel® SAS RAID Activation Key. 1 5

BHW4DIMMM 876163 Memory board. 4 DIMM DDR2-400. 1 Pack.

1 1

BHW4DIMMMBULK 877532 Memory board. 4 DIMM. 8 Pack.

1 8

AHWPROCHS 869848 Intel CEK processor heat sink.

1 1

AHWPROCBLANK 881378 Intel CEK processor blank. One required for every

empty processor slot to maintain proper airflow for

cooling.

1 1

AHWVRMCM 883663 Processor cache VRM 9DO for Intel® Xeon™

processor MP with iL3 cache. One VRM 9DO supports

both processors three and four. No VRM is required

for processors one and two.

1 1

AHWVRMPM 881372 Processor core VRM 10.2 for Intel® Xeon™ processor

MP. A VRM 10.2 is required for each processor three

and four.

1 1

AXXBCPMOD2 881379 Button Control Panel Module. 1 1

AXXLCPMOD2 879578 Intel® Local Control Panel. (LCP) 1 1

AHWIMMPRO2 878718 Intel® Server Management Module Professional. Only

for Intel® Server Platforms SR4850HW4 &

SR6850HW4.

1 1

AHWIMMADV2 878719 Intel® Server Management Module Advanced. Only for

Intel® Server Platforms SR4850HW4 & SR6850HW4.

1 1

AXXRAIL3U7U 877762 Rack rails for 3U-7U chassis. Does not include the

cable management arm. Tooless J-hook design.

Supports both the SR4850HW4 and SR6850HW4.

1 1

AXXCMA3U7U 862119 Rack cable management arm. 3U-7U chassis. Does

not include the rack rails. Supports both the

SR4850HW4 and SR6850HW4.

1 1

AXXRSBBU3 883471 Intel® RAID Smart Battery. 1 1

AHWFCMOD 881842 Intel® Fibre Channel Module (HWFCM). 1 1

Cable AHWEXTSCSI 869985 Cable: Internal cable for External SCSI port. 1 1

Cable AHWINTSCSI 869424 Cable: Internal cable for 5.25" peripheral bay. 1 1

6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 9 of 12

8.2.1 Table 4: 4U Unique Accessory Codes for SHW4URM3SA

Image Product Code MM /

UPC Description Qty

Per Min

Order

AHW4UPWR 881373 Power supply module. 4U. 15Amp, 208V. 1 1

AHW4URBEZEL 861922 Rack bezel for SR4850HW4. 1 1

AHW4U3SASKIT 882972

SAS 3.5" Conversion kit for SR4850HW4M (SCSI

conversion to SAS) - Contains Cable, Backplane,

and SAS Module (FHW4UINTSAS,

FHW4U3SASBP, FXXSROMBSAS18E)

1 1

8.2.2 Table 5: 6U Unique Accessory Codes for SHW6URM3SA

Image Product Code MM /

UPC Description Qty

Per Min

Order

AHW6UPEDKIT 881375 SR6850HW4 pedestal conversion kit. 1 1

AHW6UPWR 881376 Power supply module. 6U. 15Amp, 110V/220V. 1 1

AHW6UPWRFAN 881377 Power bay fan. Mandatory when a second power

supply is not installed in the SR6850HW4. 1 1

AHW6URBEZEL 861924 Rack bezel for SR6850HW4. 1 1

AHW6UPBEZEL 881839 Pedestal bezel for SR6850HW4. 1 1

AHW6U3SASKIT 882993

SAS 3.5" Conversion kit for SR6850HW4M (SCSI

conversion to SAS) - Contains Cable, Backplane,

and SAS Module(FHW6UINTSAS,

FHW6U3SASBP, FXXSROMBSAS18E)

1 1

8.3 Table 6: Common System Spare Part Codes

Image Product Code MM /

UPC Description Qty

Per Min

Order

FXXSROMBSAS18E 878038 Intel® SAS ROMB Module. 1 5

BHWBASEM 885977 Intel® Server Board SE8501HW4. 1 1

Board FHWSATAIDE 870273 SATA to IDE conversion board. 1 1

Cable FHWINTRU 871387

Cable: Intrusion switch for SR4850HW4 and

SR6850HW4. 1 1

Plastic FHWPCIDIVIDER 871912 PCI Divider assembly. 1 1

SBCEDVD 865263 Optical Drive, DVD-ROM, single pack. 1 1

6/13/2007 SR4850HW4S / SR6850HW4S Configuration Guide Page 10 of 12

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Intel Serveur

Intel

Intel NSW1U - IP Network Server Guide de référence

Intel

Intel M20NTP1UR Guide de configuration rapide

Intel

Intel 320014-003US Manuel utilisateur

Intel

Intel SR1500 - AXXMINIDIMM DDR-2 RAID Controller Cache... Manuel utilisateur

Intel

Intel M50FCP2UR Manuel utilisateur

Intel

Intel R1000BB Family Manuel utilisateur

Intel

Intel SR1500AL - Server System - 0 MB RAM Manuel utilisateur

Intel

Intel SR1670HV - Server System - 0 MB RAM Manuel utilisateur

Intel

Intel R2000BB series Manuel utilisateur

Intel

Intel SSR212MC2 - Storage Server Hard Drive Array Mode d’emploi

Intel

Intel SR2612UR - Server System - 0 MB RAM Manuel du propriétaire

Intel

Intel M50CYP2UR Series Guide de configuration rapide

Intel

Intel SC5300 Manuel utilisateur

Intel

Intel SC450NX - Server Platform - 0 MB RAM Manuel utilisateur

Intel

Intel SR1630BC - Server System - 0 MB RAM Manuel utilisateur

Intel

Intel SR1530CLR - Server System - 0 MB RAM Manuel utilisateur

Intel

Intel SPSH4 - Server Platform - 0 MB RAM Guide de configuration

Intel

Intel SR1530AHLX - Server System - 0 MB RAM Manuel utilisateur

Intel

Intel R2000WF series Manuel utilisateur

Intel

Intel H2000WP Manuel utilisateur

Intel

Intel SR870BH2 - Server Platform - 0 MB RAM Manuel utilisateur

Intel

Intel M70KLP Series Guide de configuration

Intel

Intel GS-SR195V Guide de l'utilisateur

Intel

Intel R2000WF series Manuel utilisateur

Manuels Serveur populaires d'autres marques

HP AlphaServer ES47 Manuel utilisateur

Dell

Dell PowerEdge R410 Manuel utilisateur

PowerNAS

PowerNAS CMA Manuel utilisateur

Supero

Supero FatTwin F617R3-FT Manuel utilisateur

MSI

MSI P1-109N-L70 Manuel utilisateur

Dell

Dell PowerEdge XE9640 Manuel

Dell

Dell PS4100 Instructions de montage

EtroVISION

EtroVISION EV3151 Manuel utilisateur

NEC

NEC Express5800/T110j Manuel utilisateur

HP ProLiant Gen9 Manuel utilisateur

Compaq

Compaq ProLiant 3000 Manuel

Dell

Dell PowerEdge 3YPMN Manuel utilisateur

iRobo

iRobo IPC2U Manuel utilisateur

Nortel

Nortel 1000 Con?guration guide Manuel utilisateur

Asus

Asus AP7500 Manuel d'utilisation et d'entretien

Avid Technology

Avid Technology AirSpeed 5000 Manuel utilisateur

HP Integrity rx2600 Guide d'installation

Milestone

Milestone Husky IVO 350T Manuel utilisateur
