FlashPoint® 128 User’s Guide

July 1998

Information in this document is subject to change without notice.

FlashPoint 128 and Integral Technologies are trademarks of Integral Technologies, Inc. Other

trademarks and trade names may be used in this document to refer to either the entities claiming

the marks and names or their products. Integral Technologies, Inc., disclaims any proprietary

interest in trademarks and trade names other than its own.

Integral Technologies makes no warranty of any kind with regard to this material, including, but not

limited to, the implied warranties of merchantability and fitness for a particular purpose. Integral

Technologies shall not be liable for errors contained herein or for incidental or consequential

damages in connection with the furnishing, performance, or use of this manual.

Contents

Introduction ......................................................................................................... 7

What’s included with FlashPoint 128 ...........................................................................8

System Requirements.................................................................................................8

OptionalEquipment.....................................................................................................9

Hardware Installation........................................................................................ 11

Before Installation......................................................................................................12

Installing the FlashPoint 128 Board ...........................................................................12

Software Installation......................................................................................... 17

Quick Start for Windows 95/98 ..................................................................................18

Quick Start for Windows NT 4.0 ................................................................................19

Windows 95 Display Driver Installation......................................................................20

Windows 95 OSR2 Display Driver Installation ...........................................................22

Windows NT Display Driver Installation.....................................................................23

Windows 98 Display Driver Installation......................................................................27

FlashPoint FPG Setup forWindows 3.1, 95, 98, NT .................................................29

FlashPoint FPG Setup for MS DOS...........................................................................37

FlashPoint FPG Setup for OS/2.................................................................................38

FlashPoint 128 Cables ......................................................................................39

Basic Cable ...............................................................................................................40

Expanded Cable........................................................................................................41

Dual Composite Cable ..............................................................................................42

RGB Cable ................................................................................................................43

Composite Cable.......................................................................................................44

S-video Cable............................................................................................................44

Flash Sync Cable ......................................................................................................44

FlashPoint FPG Application............................................................................. 45

System Requirements for FlashPoint FPG ................................................................46

Installation.................................................................................................................46

Starting FlashPoint FPG............................................................................................46

FPG Features ...........................................................................................................47

FPG Main Window ..............................................................................................47

File Menu............................................................................................................48

Edit Menu ...........................................................................................................52

Tools Menu .........................................................................................................53

ConfigurationSetup ............................................................................................54

Advanced Configuration Setup ...........................................................................55

Setup Menu ........................................................................................................57

Video Setup Menu ..............................................................................................57

Grab Setup Menu ...............................................................................................58

Examples of using ScaleVideo .................................................................................59

Examples of using Keep Aspect................................................................................60

Special Drivers .................................................................................................. 61

FlashPoint 128 TWAIN Driver....................................................................................62

FlashPoint 128 MCI Overlay Driver ...........................................................................63

MCI Commands and Syntax ...............................................................................66

FlashPoint 128 ImagePro Plus™ Driver ....................................................................72

Installation for ImagePro 3.0 ...............................................................................72

Installation for ImagePro 2.0 ...............................................................................73

Installation for ImagePro 1.3 ...............................................................................74

FlashPoint 128Video for WindowsVidCap Driver .....................................................75

Troubleshooting ................................................................................................ 77

Verifying Hardware and Software Setup....................................................................78

How to Contact IntegralTechnologies’Customer Support .........................................80

Appendix A ........................................................................................................ 81

FlashPoint 128 and FlashPoint 128 CPCI Specifications...........................................82

FlashPoint 128 and FlashPoint 128 CPCI Jumper Settings .......................................83

FlashPoint 128 and FlashPoint 128 CPCI Output Connector.....................................84

FlashPoint 128 Lite Specifications.............................................................................85

FlashPoint 128 Lite Jumper Settings .........................................................................86

FlashPoint 128 Lite Output Connector.......................................................................87

LTE with the Cohu 4910 ............................................................................................88

LTE with the Sony DXC-930 or DXC-950 ..................................................................89

LTE with the Dage DC-330 in Index Mode.................................................................90

LTE with the Dage Single Line Gating Cameras........................................................91

Appendix B ........................................................................................................ 93

FCC Radio Frequency Interference Statement..........................................................94

CE Notice..................................................................................................................95

OneYear Limited Warranty ........................................................................................96

Introduction

Chapter 1

Congratulations! You have just purchased one of the most advanced, single-slot, VGA/frame

grabbing videographics cards available on the market today - one of the members of the FlashPoint

128 family.

FlashPoint 128, FlashPoint 128 Lite and FlashPoint 128 CPCI provide a variety of multiple video

inputs including composite, S-video, RGB and Betacam (this option must be requested at order time,)

plus a range of output color resolutions up to 16.7 million colors. The FlashPoint 128 CPCI is

essentially the FlashPoint 128 in CompactCPCI format.

FlashPoint 128 enables you to capture video images while triggering an external strobe flash for the

highest quality results. All FlashPoint 128 models allow you to capture true-color images from either

an NTSC or PAL source. All of this functionality is available through FlashPoint FPG, an easy-to-use

image capture application which is included with this product.

In keeping with Integrals character, this manual is designed to be user friendly. Each page features

margins wide enough for your personal notations. If you have any suggestions on improving the

manual, feel free to contact Integral with your ideas.

Thank you for choosing an Integral Technologies product. We are confident that the FlashPoint 128 -

- whichever version you have purchased -- will meet your stringent requirements.

What’s included with FlashPoint 128

Your FlashPoint 128 card comes with the following:

· FlashPoint 128 Setup installation disk(s) with FPG software and

display drivers

· FlashPoint 128 Users Manual

· FlashPoint 128 Product Registration Card

System Requirements

The minimum computer configuration needed to properly run the

FlashPoint 128 frame grabber:

· At least one available PCI 32-bit expansion slot

· Intel Pentium computer or greater

· 8 MB RAM (ideally, it should have 16 MB or more)

· MS DOS 3.3 or greater

· Microsoft Windows 3.1, NT, 95 or OS/2 Warp 4

FlashPoint 128,

FlashPoint 128 CPCI and

FlashPoint Lite 128 are

compatible with the newest

Pentium II processor-based

PCs.

Optional Equipment

To fully utilize the capabilities of your FlashPoint 128 board, you may

wish to use some or all of the following optional components:

Inputs and Outputs

· Video input device (camera, VCR, etc.)

· Photographic Flash Unit (Vivitar 283 or 285 are preferred models)

Cables available from Integral Technologies

· Standard Cable (part #3620)

· Expanded Cable (part #3610)

· RGB Cable (part #3615)

· Dual Composite Cable (part #3625)

· Composite Video Cable (part #3651)

· S-video Cable (part #3652)

· Flash Sync Cable (part #3653)

· 9 Composite Input Cable (part #3660)

· 4 Composite Input with Triggers Cable (part #3661)

Software

· FlashPoint 128 Software Developers Kit (part #3410)

There are any number of

packages with optional

equipment available.

Some cables are not

compatible with the

FlashPoint 128 Lite board.

Contact Integral or your

Integral representative.

Hardware Installation

Chapter 2

This chapter covers the installation of the FlashPoint 128 boards into the PCI bus of a computer.

Though the installation is simple, it is recommended that the steps outlined in this chapter be followed

precisely. This will ensure the units proper working condition.

Static electricity can damage sensitive electronic components. Thats why the FlashPoint 128 board is

shipped in a static-free container. Before you perform a hardware installation procedure, make sure

you discharge any static electricity by touching any non-painted metal area of the chassis.

Integral Technologies assumes no liability for any damage, caused directly or indirectly, by improper

installation of any components by unauthorized service personnel. If you do not feel comfortable

performing the installation, consult a qualified computer technician.

Before Installation

1. Register your FlashPoint 128 board - First, before you proceed,

please ensure your access to Integral Technologies Customer Support.

Become a registered user by completing and returning the product

registration card.

2. Make Backup Disks - Please make backup copies of your FlashPoint

128 setup disks. You should then store the original disks and use the

backups for the software installation.

Installing the FlashPoint 128 Board

Step 1 - Set the FlashPoint 128 Jumper Switches (only if necessary)

There are jumpers on the various FlashPoint 128 boards that may need to

be changed from the factory default setting, depending on your particular

situation. Most of the time, you will not need to make any changes.

Changes from the factory default settings are only needed for special

features. Always try the default settings first.

More information on jumper settings can be found in Appendix A.

The installation of

FlashPoint 128 is simple

and straightforward. The

areas of which you must be

aware are (1) whether you

have a VGA or other video

device already active in

your PC and (2) whether

you need to set any of the

FlashPoint 128 jumpers

(applicable only in rare

instances).

The FlashPoint 128

operates as your system’s

VGA. Therefore, any other

VGA device must be

removed from your system

in order for Intrigue to

function.

The default refresh

resolution for the

FlashPoint 128 boards is

75Hz, 640x480.

Ce manuel convient aux modèles suivants

Table des matières

Manuels Carte vidéo populaires d'autres marques

Gainward

Gainward GeForce GTX 690 4GB Manuel utilisateur

ATI Technologies

ATI Technologies RADEON 137-40225-20 Manuel utilisateur

MSI

MSI N220GT series Manuel utilisateur

ATI Technologies

ATI Technologies RADEON 7000 MAC EDITION Manuel utilisateur

SIIG

SIIG aurora Manuel utilisateur

ClearSpeed

ClearSpeed ClearSpeed Advance e720 Manuel utilisateur

MSI

MSI R7850 series Manuel utilisateur

DVS

DVS Atomix HDMI Manuel utilisateur

Aztech

Aztech VGS3D-AGP Manuel utilisateur

Advoli

Advoli TB4 Standard Manuel utilisateur

ELSA

ELSA ERAZOR III LT Manuel utilisateur

Gigabyte

Gigabyte GV-R7500L Manuel utilisateur

Themis

Themis TGA-7000 PMC Manuel utilisateur

EMS

EMS XtremeRGB-Ex1 Manuel utilisateur

Nvidia

Nvidia Quadro Workstation Manuel utilisateur

Pioneer

Pioneer PDA-5003 Manuel utilisateur

QDI

QDI N2 Manuel utilisateur

NEC

NEC N8116-48 Manuel utilisateur
