1Determine a secure and suitable moun ng loca on for your monitor. The monitor can be mounted either over-

head, on the dashboard or other suitable moun ng surface.

Quality First For Performance That Lasts

CVMHDVR706

Quick Installation Guide

Included in the box:

1 - CVMHDVR706 Monitor 1 - Emergency Event Bu on

1 - Sun Shield Kit 1 - Wireless Remote Control

1 - Moun ng Bracket Set 1 - GPS Antenna

1 - Moun ng Bolt Set 1 - Microphone

1 - Power / Camera Harness 1 - WiFi Dongle

1 - 16 GB Micro SD Card (Installed) 1 - Operators CD

When rou ng the cable from the exterior to the interior

of a vehicle, care needs to be taken to seal the entry

point. Failure to do so could allow in exhaust fumes,

other toxic gases or water.

Do NOT a ach the wiring to any moving parts, across

sharp edges or close to heat sources as this may cause

shor ng of the wires and may lead to a ﬁ re or electrical

shock.

Be certain that all items are secure. Items that are not

secure or mounted in an unstable manner can come

loose and cause damage or personal injury.

Do NOT install the display in an area that will obstruct

your forward or side visibility.

Always verify the area being drilled into is of suﬃ cient

strength and is clear of all wires and other items around or

underneath so as not to cause damage.

Always conﬁ rm proper image orienta on before driving

or opera ng your vehicle. The orienta on of the image

displayed is cri cal to safe vehicle opera on. An object

on the right side of your vehicle needs to be seen on the

right side of the display screen.

Before you begin driving, be sure the display controls are

adjusted properly. This will avoid unnecessary

distrac ons while driving.

! Please include this Quick Installa on Guide and CD with the other

vehicle documenta on provided to the end user.

For more detailed installa on instruc ons or to install addi onal memory refer to you Operators Guide included on the CD or visit www.intecvideo.com/support.html

You may also call us toll free at 800-468-3254 (West) or 800-522-5989 (East) or e-mail [email protected] with any ques ons. Rev A 11/2018

3 Assemble the display to the bracket by aligning the

“T” in the slot and hand  ghtening the nut and lock nut.

4 Connect the cable harness and if desired install the

sun shield by pushing it onto the monitor un l locked.

2 Install the display bracket with the hardware

provided. Use the bracket as a template for drilling the

required holes. The recommended moun ng bolt torque

speciﬁ ca on is between 15 and 17 inch pounds.

For more detailed installa on instruc ons or to install addi onal memory refer to you Operators Guide included on the CD or visit www.intecvideo.com/support.html

You may also call us toll free at 800-468-3254 (West) or 800-522-5989 (East) or e-mail [email protected] with any ques ons. Rev A 11/2018

Wiring Diagram

HD CAM1

HD CAM2

GPS

MIC

WiFiUSB

Monitor Connec ons

Emergency

Bu on

Tach

Power
