• The Record Button is also used to enter alternate modes (See the
Input Monitoring Modes,Looping & One-Shot Record Modes,
Save & Load, and Time Modes sections for more information).
Record Gate Input: Recording, overdubbing, or playback (based on the
currently selected mode) will be activated when a trigger or gate signal
is present at the Record Gate Input.
Erase Button: Any loop in the buffer will be erased when the Erase
Button is pressed.
• The Erase Button is also used to enter alternate modes (See the
Latching & Momentary Recording,Looping & One-Shot Playback
Modes and Save & Load sections for more information).
Position/Record Indicator: The position of the play head within the
loop is shown by the Position/Record Indicator.
Speed: The Speed knob sets the playback rate of the loop.
When the knob is fully clockwise,
the rate of playback will be set to
4x the original speed. When the
knob is fully anticlockwise, the rate
of playback will be set to 4x the
original speed, but playback will
be reversed. When the knob is
set to its centre position, playback
will be stalled. Because this is a vary-speed control, setting the rate of
playback to half the original speed will also lower the pitch by
one octave.
• Pressing the Retrigger/Shift Button and turning the Speed knob
will mute the knob turn to allow for immediate speed value selection
upon release of the Retrigger/Shift Button.
Stalled
4 x Speed4 x Speed
(Reversed)
Original
Speed
2 x Speed
(Octave Up)
Half Speed
(Octave down)
Half Speed
(Octave down)
2 x Speed
(Octave Up)
Original
Speed
