INSTEON 2476D Manuel utilisateur

Quick-Start Guide

SWITCHLINC DIMMER

For Models: SwitchLinc V2 Dimmer (#2476D) - 600 Watt

SwitchLinc V2 Dimmer (#2476DH) - 1000 Watt

SET Button

PPrreeppaarraattiioonn

IInnssttaallllaattiioonnsshhoouullddbbeeppeerrffoorrmmeeddoonnllyybbyyaaqquuaalliiffiieeddeelleeccttrriicciiaannoorrbbyyaahhoommeeoowwnneerrwwhhooiissffaammiilliiaarraannddccoommffoorrttaabblleewwiitthheelleeccttrriiccaallcciirr--

ccuuiittrryy..IIfftthheerreeaarreeaannyyqquueessttiioonnss,,ccoonnssuullttaanneelleeccttrriicciiaann..FFoorrs

seettuuppqquueessttiioonnssccoonnttaaccttTTeecchhSSuuppppoorrttaattSSmmaarrttLLaabbssffoorrgguuiiddaannccee..

TToooollssyyoouuwwiillllnneeeedd::

•A standard screwdriver

•A Phillips screwdriver

•A wire cutter/stripper

NNeeeeddHHeellpp??FFoorraassssiissttaanncceeccaallllyyoouurrffrriieennddllyy

ssuuppppoorrttppeerrssoonn@@886666--224433--88001188

LED Bar

Brightness

Indicator

Installing Your SwitchLinc Dimmer

Step 1. Be sure you have properly installed two AccessPoints (#2443).

Step 2. At the circuit breaker or fuse panel, disconnect the power for all of the circuits in the switch junction box.

Step 3. Remove the faceplate from the switch junction box, then unscrew the switch and pull it out from the junction box.

Step 4. Disconnect the wires from the switch you are replacing and ensure you have 1/2” of bare wire on the ends.

Step 5. If you are installing SwitchLinc into a ttwwoo--wwaayycciirrccuuiitt(where one switch controls the load), follow the diagram below to

identify and connect the LINE, LOAD, NEUTRAL, and GROUND wires. If the colors of the wires do not match the

diagram, be sure you have identified the wires correctly before connecting them.

Step 6. If you are installing into a mmuullttii--wwaayycciirrccuuiitt(where more than one switch controls the load), consult the User’s Guide.

Step 7. Ensure that all wire connectors are firmly attached and that there is no exposed copper except for the GROUND wire.

Step 8. Orient SwitchLinc Dimmer with the LED bar at the left, gently place it into the junction box, then screw it into place.

Step 9. Turn the circuit breaker back on or re-install the fuse.

Step 10. Test that SwitchLinc Dimmer is working properly by turning the light on and off.

Step 11. Reinstall the faceplate.

NNOOTTEE

The NEUTRAL wire will not normally

be connected to the switch you are

replacing. If there is no NEUTRAL

wire in the junction box, please con-

sult an electrician or call

SSmmaarrttLLaabbssTTeecchhSSuuppppoorrtt

886666--224433--88001188

TTMM

•Optional: A #1 Phillips screwdriver to change the paddle color (sold separately)

•A voltage tester to identify wires inside the junction box

SSmmaarrttLLaabbssLLiimmiitteeddWWaarrrraannttyy

SmartLabs warrants to the original consumer of this product that, for a period of two years from the date of purchase, this product will be free from defects in material and workmanship and will per-

form in substantial conformity to the description of the product in the owner's manual. This warranty shall not apply to defects or errors caused by misuse or neglect.

©©CCooppyyrriigghhtt22000077SSmmaarrttLLaabbss,,1166554422MMiilllliikkaannAAvvee..,,IIrrvviinnee,,CCAA9922660066--55002

277

886666--224433--88001188wwwwww..ssmmaarrttllaabbssiinncc..ccoomm

SwitchLinc V2 Dimmer (#2476D & #2476DH)

Quick-Start Guide

SWITCHLINC DIMMER

NNeeeeddHHeellpp??FFoorraassssiissttaanncceeccaallllyyoouurrffrriieennddllyy

ssuuppppoorrttppeerrssoonn@@886666--224433--88001188

In a virtual multi-way circuit, only one SwitchLinc Dimmer, called the SwitchLinc Primary, actually controls the LOAD in the multi-way

circuit. Any additional SwitchLinc Dimmers, called SwitchLinc Secondaries, are not connected to the LOAD, but only to the powerline

(by being wired to the LINE and NEUTRAL). All of the SwitchLinc Dimmers can communicate with one another using INSTEON net-

working on the powerline. After wiring in the SwitchLinc Dimmers, you create the virtual multi-way circuit by setting up all of the

SwitchLinc Dimmers to control each other.

The diagram below shows how you convert a wired-in three-way circuit into a virtual three-way circuit using two SwitchLinc Dimmers.

Notice that one of the TRAVELER wires (number 1, the red one) is not used, so you will cap it off at both ends with a wire nut. The

other TRAVELER (number 2, the black one) you will convert to a LINE wire. In the junction box where the SwitchLinc Secondary is,

connect TRAVELER 2 to the existing LINE and also to the SwitchLinc Secondary's LINE wire. In the other junction box at the other end,

you will connect TRAVELER 2 to the SwitchLinc Primary's LINE wire.

The SwitchLinc Primary's LOAD wire gets connected to the actual lights that are being controlled. The LOAD wire for any SwitchLinc

Secondaries that you will be installing will not be connected to anything, so cap those LOAD wires off with a wire nut.

All SwitchLinc Dimmers, whether they are Primaries or Secondaries, must be connected to the NEUTRAL and to the GROUND wires.

Note that the switches you are replacing will not normally have a connection to the NEUTRAL wire. If there is no NEUTRAL wire in the

junction box, please consult an electrician or call SmartLabs Tech Support, 866-243-8018.

UUssiinnggSSwwiittcchhLLiinnccDDiimmmmeerrssiinnVViirrttuuaallMMuullttii--WWaayyCCiirrccuuiittss

Your new SwitchLinc Dimmer allows you to dim and remotely control any light in

your home at the touch of a button.

rev. 062507

SwitchLinc V2 Dimmer (#2476D & #2476DH)

Quick-Start Guide

SWITCHLINC DIMMER

NNeeeeddHHeellpp??FFoorraassssiissttaanncceeccaallllyyoouurrffrriieennddllyy

ssuuppppoorrttppeerrssoonn@@886666--224433--88001188

Quick-Start Guide

SWITCHLINC DIMMER

Setting Up Your SwitchLinc Dimmer to Control an INSTEON Device Remotely

SStteepp33..Test that the SwitchLinc Dimmer is working properly by turning the light on and off.

DDeevviicceeSSeettuuppIInnssttrruuccttiioonnss

SwitchLinc Dimmer ••PPrreessssaannddhhoollddthe second SwitchLinc Dimmer’s Paddle Top for 10 seconds until the

light it controls flashes —then release.

The first SwitchLinc Dimmer will exit Linking Mode, and its LED will stop blinking.

Lamp Dimmer ••PPrreessssaannddhhoollddthe Lamp Dimmer’s SET button for 3 seconds until the lamp it con-

trols flashes —then release.

The SwitchLinc Dimmer will exit Linking Mode, and its LED will stop blinking.

Appliance Module ••PPrreessssaannddhhoollddthe Appliance Module’s SET button for 3 seconds until its Status LED

blinks —then release.

The SwitchLinc Dimmer will exit Linking Mode, and its LED will stop blinking.

Other INSTEON-

Enabled Devices

See device’s Quick-Start Guide or User’s Guide

SStteepp11..PPrreessssaannddhhoollddthe SwitchLinc Dimmer’s Paddle Top for 10 seconds until its LED starts blinking and the light flashes --

then release.

Your SwitchLinc Dimmer is now in Linking Mode. You have 4 minutes to complete Step 2.

SStteepp22..Select the device you would like to control and follow the setup instructions from the table below:

•TTaappthe Paddle Top to turn your light on

•TTaappthe Paddle Bottom to turn your light off

•PPrreessssaannddhhoollddthe Paddle Top to brighten your light

•PPrreessssaannddhhoollddthe Paddle Bottom to dim your light

••DDoouubblleettaappthe Paddle Top to turn your light on quickly

••DDoouubblleettaappthe Paddle Bottom to turn your light off quickly

Using Your SwitchLinc Dimmer

SStteepp11..On your INSTEON controller pprreessssaannddhhoollddthe ON button of your choice for 10 seconds until the LED begins

blinking slowly -- then release.

Your INSTEON Controller is now in Linking Mode. You have 4 minutes to complete step 2.

SStteepp22..PPrreessssaannddhhoollddthe SwitchLinc Dimmer’s Paddle Top for 10 seconds until the light flashes -- then release.

Your INSTEON Controller’s LED will stop blinking to indicate successful linking.

SStteepp33..On your INSTEON Controller press the ON and OFF buttons several times to make sure everything is working properly.

Setting Up an INSTEON Controller to Control a SwitchLinc Dimmer Remotely

SwitchLinc V2 Dimmer (#2476D & #2476DH)

Quick-Start Guide

SWITCHLINC DIMMER

NNeeeeddHHeellpp??FFoorraassssiissttaanncceeccaallllyyoouurrffrriieennddllyy

ssuuppppoorrttppeerrssoonn@@886666--224433--88001188

TToouunnlliinnkkaaddeevviicceeffrroommyyoouurrSSwwiittcchhLLiinnccDDiimmmmeerr

1. Press and hold the PPaaddddlleeTTooppfor 10 seconds until the light flashes - then release.

2. Press and hold the PPaaddddlleeTTooppaaggaaiinnfor 10 seconds until the light flashes again - then release.

3. On the INSTEON device you wish to unlink, press and hold the OONNBBuuttttoonnfor 10 seconds or the SSEETTBBuuttt

toonnfor 3 seconds.

TToocchhaannggeetthheeSSwwiittcchhLLiinnccDDiimmmmeerr''ssLLooccaallOOnn--LLeevveelloorrRRaammppRRaattee

1. Dim or brighten to the desired RRaammppRRaattee(dimmer = slower Ramp Rate).

2. Press the SSEETTBBuuttttoonnTTWWIICCEE. The light will flash once. Test by tapping the paddle.

3. Dim or brighten to the desired OOn

n--LLeevveellbrightness.

4. Press the SSEETTBBuuttttoonnOONNCCEE. The light will flash once. Test by tapping the paddle.

5. Don't link SwitchLinc Dimmer for 4 minutes.

TToocchhaannggeetthheeSSwwiittcchhLLiinnccDDiimmmmeerr''ssRReemmoottee--CCoonnttrroolllleeddOOnn--LLeevveelloorrRRaammppRRaatte

1. Dim or brighten to the desired OOnn--LLeevveellbrightness.

2. Press the SSEETTBBuuttttoonnOONNCCEE. The light will flash once.

3. Dim or brighten to the desired RRaammppRRaattee(dimmer = slower Ramp Rate).

4. Press the SSEETTBBuuttttoonnTTWWIICCEE. The light will flash once.

5. Go into LLiinnkkiinnggMMooddeeon the INSTEON Controller that will control this SwitchLinc.

6. Press and hold this SwitchLinc's PPaaddddlleeTTooppfor 10 seconds until the light flashes - then release.

7. The Local Ramp Rate and On-Level will be unchanged.

TTooffaaccttoor

ryyrreesseettyyoouurrSSwwiittcchhLLiinnccDDiimmmmeerr

1. Pull the SSEETTBBuuttttoonnaalllltthheewwaayyoouuttand wait 10 seconds.

2. Push the SSEETTBBuuttttoonnaalllltthheewwaayyiinnand hold for 3 seconds - then release.

3. After 3 seconds, the light will turn on fully.

NNootteess

• Pressing the SET Button after going into Linking Mode will change Linking Mode to Scene Setup (Multi-Link) Mode

• Any paddle press will exit Linking Mode early

• Please consult User’s Guide for power derating information

For detailed instructions on how to operate all the features of your SwitchLinc Dimmer,

please refer to the User's Guide at http://www.smarthome.com/2476d.html

Using Your SwitchLinc Dimmer’s Advanced Features

Optional for X10 Users

To give the SwitchLinc Dimmer an X10 Primary Address

1. Press and hold the PPaaddddlleeTTooppfor 10 seconds until the light flashes - then release.

2. SSeennddtthheeddeessiirreeddXX1100PPrriimmaarryyAAddddrreessssTTHHRREEEEttiimmeess..The light will flash again.

3. The X10 On-Level and Ramp Rate will be the same as the Local On-Level and Ramp Rate.

To remove an X10 Primary Address from the SwitchLinc Dimmer

1. Press and hold the PPaaddddlleeTTooppfor 10 seconds until the light flashes - then release.

2. Press and hold the PPaaddddlleeTTooppaaggaaiinnfor 10 seconds until the light flashes again - then release.

3. SSeennddaannyyXX1100aaddddrreessssTTHHRREEEEttiimmeess..The light will flash again.
