1. Press the UP button or the DOWN button until the LCD shows “ON”, now the
first setting of ON can be made.
2. Press the SET button once and then release. Then “SET”will be display on the
LCD and will also flash; the “WEEK DAY” at same time.
3. Press the UP button or the DOWN button to set the desired “WEEK DAY.”
4. Press the SET button once and release, the “HOUR” will begin to flash and the
“WEEK DAY” will stop flashing and will keep it displayed.
5. Press the UP button or the DOWN button to set the “HOUR.”
6. Press the SET button once and release. Then the “MINUTE” will begin to flash.
The “HOUR” will stop flashing and will keep it displayed.
7. Press the UP button or the DOWN button to set the “MINUTE.”
(EXAMPLE: Timer ON at 17:15 and OFF at 22:30 every day.)
8. Press the UP button or the DOWN button until the LCD shows ON_1.
9. Press the SET button once and release, then “SET”will be displayed on the
LCD and will flash “WEEKDAY” at same time.
10. Press the UP button or the DOWN button until the LCD displays
“MO, TU, WE, TH, FR, SA, SU.”
11. Press the SET button once and release, the “HOUR” will flash and the
“WEEK DAY” will stop flashing and will keep it displayed.
12. Press the UP button or the DOWN button until the LCD displays 5:00PM or 17:00.
13. Press the SET button once and release. The “MINUTE” will flash and the
“HOUR” will stop flashing and will keep it displayed.
14. Press the UP button or the DOWN button until the LCD displays
5:15PM or 17:15. Then press the SET button to confirm.
15. Press the UP button once and release. The LCD will display OFF_1.
16. Repeat the above B, C, D, E, F, and G until the LCD displays 10:30PM or 22:30.
17. Press the MANUAL button until the LCD displays AUTO.
How to Program Manual ON/AUTO/OFF Settings
▪
Operating modes can’t be changed during the program settings.
▪
Press the
MANUAL
button to revert the three modes in turn.
▪
The programs can only be executed in
AUTO
mode. When
AUTO
is selected, the timer operates as the programs. In
MANUAL
ON
or
MANUAL
OFF
mode all programs are ignored and the timer will not operate.
When
MANUAL
ON
mode is selected, the power output is always
ON
. When
MANUAL
OFF
mode is selected, the power output is permanently off. When the
mode is turned from
MANUAL
ON
to
AUTO
, the timer will keep
the setting of
MANUAL ON
until to the next timer setting.
Random (RND) Function
▪By pressing the RANDOM button, “R” will be displayed on the LCD as indication that the RANDOM
function has been activated.
Once RANDOM is activated, the timer will be in the on position randomly for 10-31
minutes during the time gap-from 6:00 PM to 6:00 AM.
▪Press the RANDOM button once again to cancel this function. The RANDOM function
can’t be set during PROGRAM and CD setting(s)
▪The RANDOM function can only be executed in AUTO mode between 6:00 PM and 6:00 AM.
CD (Count Down) Function
1. Press the UP button or the DOWN button until the LCD displays CD, then you can set
the CD time.
2. Press the SET button once and release, then “SET”will be displayed on the LCD, and at
the same time it will flash “ON” or “OFF”
3. Press the UP button or the DOWN button set “ON” or “OFF.”
4. Press the SET button once and release, you will see “HOUR” flashing and the “ON
or “OFF” will have stopped flashing and will keep it displayed.
5. Press the UP button or the DOWN button to set the “HOUR.”
6. Press the SET button once and release, you will see “MINUTE” flashing, while
“HOUR” will stop flashing and will keep it displayed.
7. Press the UP button or the DOWN button to set the “MINUTE”.
8. Press the SET button once and release, then “SECOND” will begin flashing while
“MINUTE” will stop flashing and will keep it displayed.
9. Press the UP button or the DOWN button to set the “SECOND,” then press the SET
button and the “SECOND” will stop flashing and will keep it displayed.
10. Press the CD button, then the COUNT DOWN time will be reduced with one second
if the current operation mode is in AUTO mode.
11. Press the CD button once again, then the COUNT DOWN time will stop and will come
back to the primary COUNT DOWN time.
12. Maximum COUNT DOWN time is 99 hours 59 minutes 59 seconds.
13. The CD function can only be executed in AUTO mode and the RANDOM function must
be canceled.
14. The CD will flash on the LCD when you press the CD button in clock mode which
means the CD function has been executed.
12/24 Hour Mode
▪Press the CD button and the SET button simultaneously to turn the time display between 12
and 24-hour mode.
Summertime Function
▪Press the MANUAL button and the SET or (RANDOM) button simultaneously. The LCD will
display “S”for (Summer Time) which the Clock advances 1 hour.
▪To revert to winter settings, press the two buttons again. The clock will move backwards 1
hour. The “S” will disappear from the LCD.
Operation Gradation
Please notice the operation gradation when you set the timer, it will operate as follows
gradation: 1. MANUAL ON or MANUAL OFF2. RANDOM3. CD4. PROGRAM.
It executes the MANUAL ON or MANUAL OFF setting first, the RANDOM setting second,
the CD setting third and the PROGRAM setting last when the timer runs. Please set the right
operation mode.
WARNINGS
▪Do not plug two or more timers together.
▪Don't plug in an appliance where the load exceeds 15 Amp.
▪Always ensure the plug of any appliance is fully inserted into the timer outlet.
▪If cleaning of the timer is required, remove from mains power and wipe timer with a dry
cloth.
▪Do not immerse timer in water or any other liquid.
▪Heaters and similar appliances should never be left unattended during operation. The
manufacturer recommends such appliances not to be connected with timers.
