Insignia IS-TV040928 Manuel utilisateur

27” HD-Ready TV

IS-TV040928

User Guide | Guide de l’utilisateur | Guía del Usuario

TV de 27 po compatible HD | TV de 27" listo para alta definición

CMY

IS_27-inch HD-Ready TV_FrontCvr.pdf 8/22/2005 10:10:30 PMIS_27-inch HD-Ready TV_FrontCvr.pdf 8/22/2005 10:10:30 PM

www.insignia-products.com 1

Welcome

Congratulations on your purchase of a high-quality Insignia product.

Your IS-TV040928 27-inch HD-Ready TV represents the state of the

art in HD-Ready TVs, and is designed for reliable and trouble-free

performance.

Contents

Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Setting up your HD-Ready TV . . . . . . . . . . . . . . . . . . . . . . . . 11

Using your HD-Ready TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Español. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Safety information

READ INSTRUCTIONS

Read all safety and operating instructions before operating your

HD-Ready TV.

RETAIN INSTRUCTIONS

Keep the safety and operating instructions for future reference.

HEED WARNINGS

Follow to all warnings on your HD-Ready TV and in the operating

instructions.

FOLLOW INSTRUCTIONS

Follow all operating and use instructions.

CLEANING

Unplug your HD-Ready TV from the wall outlet before cleaning. Do

not use liquid cleaners or aerosol cleaners. Use a damp cloth for

cleaning the exterior cabinet only.

Warning To reduce the risk of fire or electric shock, do not expose your

HD-Ready TV to rain or moisture.

Warning To reduce the risk of electric shock, do not remove the cover (or

back). No user serviceable parts inside. Refer servicing to qualified

service personnel.

27-inch HD Ready TV.book Page 1 Monday, August 22, 2005 9:58 PM

IS-TV040928 27” HD-Ready TV

www.insignia-products.com

ATTACHMENTS

The manufacturer of your HD-Ready TV does not make any

recommendations for attachments as they may cause hazards.

WATER AND MOISTURE

Do not use your HD-Ready TV near water, for example, near a

bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or

near a swimming pool.

ACCESSORIES

Do not place your HD-Ready TV on an unstable cart, stand, tripod,

bracket, or table. The TV may fall, causing serious bodily injury and

serious damage to your TV.

Make sure that you move an HD-Ready TV and cart combination with

care. Quick stops, excessive force, and uneven surfaces may cause

your TV and cart combination to overturn.

VENTILATION

Slots and openings in the cabinet back or bottom are provided for

ventilation, to ensure reliable operation of your HD-Ready TV, and to

protect it from overheating. These openings must not be blocked or

covered. Do not place your HD-Ready TV on a bed, sofa, rug, or

other similar surface. Do not place your HD-Ready TV near or over a

radiator or heat source. Do not place your HD-Ready TV in a built-in

installation such as a bookcase or rack unless you provide adequate

ventilation or follow the manufacturer's instructions.

POWER SOURCE

Operate your HD-Ready TV only from the type of power source

indicated on the rating plate.

If you are not sure of the type of power supply to your home, consult

your HD-Ready TV dealer or local power company.

GROUNDING AND POLARIZATION

Your HD-Ready TV is equipped with a polarized alternating-current

line plug (a plug having one blade wider than the other). This plug will

fit into the power outlet only one way. This is a safety feature. If you

are unable to insert the plug fully into the outlet, try reversing the plug.

If the plug should still fail to fit, contact your electrician to replace your

obsolete outlet. Instead of the polarized alternating-current line plug,

your HD-Ready TV may be equipped with a 3-wire grounding-type

plug (a plug having a third grounding pin). This plug will only fit into a

grounding-type power outlet. This, too, is a safety feature. If you are

unable to insert the plug into the outlet, contact your electrician to

replace your obsolete outlet. Do not defeat the safety purpose of the

grounding-type plug.

27-inch HD Ready TV.book Page 2 Monday, August 22, 2005 9:58 PM

IS-TV040928 27” HD-Ready TV

www.insignia-products.com

POWER CORD PROTECTION

Route power supply cords so they are not likely to be walked on or

pinched by items placed on or against them. Pay particular attention

to cords at plugs, wall outlet, and the point where they exit from your

HD-Ready TV.

LIGHTNING

To protect your HD-Ready TV from a lightning storm, or when it is left

unattended and unused for long periods of time, unplug it from the

wall outlet and disconnect the antenna or cable system.

This will prevent damage to your HD-Ready TV from lightning and

power line surges.

POWER LINES

Do not locate an outside antenna system in the vicinity of overhead

power lines or other electric light or power circuits, or where it can fall

onto or against such power lines or circuits. When installing an

outside antenna system, take extreme care to keep from touching

such power lines or circuits because contact with them might be fatal.

OVERLOADING

Do not overload wall outlets and extension cords because this can

result in a risk of fire or electric shock.

OUTDOOR ANTENNA GROUNDING

If an outside antenna or cable system is connected to your

HD-Ready TV, make sure that the antenna or cable system is

grounded to provide some protection against voltage surges and

built-up static charges, Section 810 of the National Electrical Code

(NEC), ANSI/NFPA 70, provides information with respect to correct

grounding of the mast and supporting structure, grounding of the

lead-in wire to an antenna discharge unit, size of grounding

conductors, location of antenna discharge unit, connection to

grounding electrodes, and requirements for the grounding electrode.

1 Electric service equipment

2 Power service grounding electrode system

27-inch HD Ready TV.book Page 3 Monday, August 22, 2005 9:58 PM

IS-TV040928 27” HD-Ready TV

www.insignia-products.com

OBJECT AND LIQUID ENTRY

Do not push objects through any openings in your HD-Ready TV

because they may touch dangerous voltage points or short out parts

that could result in fire or electric shock. Never spill or spray any type

of liquid into your HD-Ready TV.

SERVICING

Do not attempt to service your HD-Ready TV yourself because

opening or removing covers may expose you to dangerous voltage or

other hazards. Refer all servicing to qualified service personnel.

DAMAGE REQUIRING SERVICE

Unplug your HD-Ready TV from the wall outlet and refer servicing to

qualified service personnel under the following conditions:

• When the power-supply cord or plug is damaged.

• If liquid has been spilled, or objects have fallen, into your

HD-Ready TV.

• If your HD-Ready TV has been exposed to rain or water.

• If your HD-Ready TV does not operate normally by following

the operating instructions. Adjust only those controls that are

covered by the operating instructions because an incorrect

adjustment of other controls may result in damage and will

often require extensive work by a qualified technician to restore

your HD-Ready TV to its normal operation.

• If your HD-Ready TV has been dropped or the cabinet has

been damaged.

• If your HD-Ready TV exhibits a distinct change in performance,

this indicates a need for service.

REPLACEMENT PARTS

When replacement parts are required, make sure that the service

technician uses replacement parts specified by the manufacturer or

those that have the same characteristics as the original part.

Unauthorized substitutions may result in fire, electric shock, or other

hazards.

3 Ground clamps

4 Grounding conductors

5 Antenna discharge unit

6 Grounding clamp

7 Antenna lead in wire

27-inch HD Ready TV.book Page 4 Monday, August 22, 2005 9:58 PM

IS-TV040928 27” HD-Ready TV

www.insignia-products.com

SAFETY CHECK

Upon completion of any service or repairs to your HD-Ready TV, ask

the service technician to perform safety checks to determine that your

HD-Ready TV is in correct operating condition.

HEAT

Locate your HD-Ready TV away from heat sources such as radiators,

heat registers, stoves, or other products (including amplifiers) that

produce heat.

CONNECTING

When you connect your HD-Ready TV to other equipment, turn off

the power and unplug all of the equipment from the wall outlets.

Failure to do so may cause an electric shock and serious personal

injury. Read the owner's manual of the other equipment carefully and

follow the instructions when making any connections.

SOUND VOLUME

Reduce the volume to the minimum level before you turn on your

HD-Ready TV. Otherwise, sudden high volume sound may cause

hearing loss or speaker damage.

SOUND DISTORTION

If your HD-Ready TV outputs distorted sound for a long time, the

speakers may overheat and cause a fire.

HEADPHONES

When you use the headphones, keep the volume at a moderate level.

If you use the headphones continuously with high volume sound, it

may cause hearing damage.

NOTE TO CABLE SYSTEM TV INSTALLER

This reminder is provided to call the cable TV system installer's

attention to Article 820-40 of the NEC that provides guidelines for

correct grounding and, in particular, specifies that the cable ground

shall be connected to the grounding system of the building, as close

to the point of cable entry as practical.

27-inch HD Ready TV.book Page 5 Monday, August 22, 2005 9:58 PM

IS-TV040928 27” HD-Ready TV

www.insignia-products.com

Features

Front

Component Description

1 Power button Press the power button to turn your HD-Ready

TV on and off.

2 Remote sensor Receives signals from the remote control. Do

not block.

3 Power indicator When your HD-Ready TV is turned on, the

power indicator lights.

4 TV/AV button Press to change the video source.

5 MENU button Press to open the on-screen menu.

6 VOL – and VOL + Press to decrease or increase the volume.

7 CH – and CH + Press to change channels.

4567

27-inch HD Ready TV.book Page 6 Monday, August 22, 2005 9:58 PM

IS-TV040928 27” HD-Ready TV

www.insignia-products.com

Back

Connection Description

1 COMPONENT1 Plug a component video device into these

jacks.

2 AV (output) Plug an external device such as a VCR or

stereo into these AV output jacks.

3 AV1 (input) Plug an external device such as a VCR into

these jacks.

4 AV2 (input) Plug an external device such as a video

camcorder into these jacks.

27-inch HD Ready TV.book Page 7 Monday, August 22, 2005 9:58 PM

IS-TV040928 27” HD-Ready TV

www.insignia-products.com

5 COMPONENT2 Plug a component video device into these

jacks.

6 RF Plug your antenna, cable TV, or satellite dish

into this jack.

Connection Description

27-inch HD Ready TV.book Page 8 Monday, August 22, 2005 9:58 PM

IS-TV040928 27” HD-Ready TV

www.insignia-products.com

Remote control

Button Description

1 Power Press to turn your HD-Ready TV on and off.

27-inch HD Ready TV.book Page 9 Monday, August 22, 2005 9:58 PM

Table des matières

Langues :

Autres manuels Insignia TV

Insignia

Insignia NS-39L400NA14 Manuel d'utilisation

Insignia

Insignia NS-32D311MX15 Manuel utilisateur

Insignia

Insignia ns-ltdvd26 Manuel du propriétaire

Insignia

Insignia NS-50L240A13 Guide de démarrage rapide

Insignia

Insignia NS-46E790A12 Manuel utilisateur

Insignia

Insignia NS-40D40SNA14 Manuel d'utilisation

Insignia

Insignia NS-46D40SNA14 Manuel d'utilisation

Insignia

Insignia NS-F27C Manuel utilisateur

Insignia

Insignia NS-46E440NA14 Manuel utilisateur

Insignia

Insignia NS-LTDVD19 - 19" LCD TV Manuel utilisateur

Insignia

Insignia NS-65D260A13 Manuel utilisateur

Insignia

Insignia NS-39D40SNA14 Manuel utilisateur

Insignia

Insignia NS-37D20SNA14 Manuel d'utilisation

Insignia

Insignia NS-42D240A13 Guide de démarrage rapide

Insignia

Insignia NS-55L780A12 Manuel utilisateur

Insignia

Insignia NS-39L240A13 Manuel utilisateur

Insignia

Insignia NS-32D201NA14 Manuel utilisateur

Insignia

Insignia NS-24E40SNA14 Manuel utilisateur

Insignia

Insignia NS-19E450A11 Manuel utilisateur

Insignia

Insignia NS-55L780A12 Guide de démarrage rapide

Insignia

Insignia NS-32D201NA14 Manuel utilisateur

Insignia

Insignia NS-LTDVD19 - 19" LCD TV Manuel utilisateur

Insignia

Insignia NS-20FTV Manuel utilisateur

Insignia

Insignia NS-32D420NA16 Manuel utilisateur

Manuels TV populaires d'autres marques

Philips

Philips Colour Television Manuel utilisateur

Toshiba

Toshiba 27A10 Manuel utilisateur

Philips

Philips 42PF9630A/37 Manuel utilisateur

Hitachi

Hitachi 32FX48B Manuel utilisateur

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manuel utilisateur

Changhong Electric

Changhong Electric uhd55b6000is Manuel utilisateur

Philips

Philips Matchline 21CE7551 Manuel utilisateur

Panasonic

Panasonic Genus TX-G10 Manuel utilisateur

Toshiba

Toshiba 19A20 Manuel utilisateur

Philips

Philips 25PT4523-16 Manuel utilisateur

Sony

Sony XBR-100Z9D Manuel utilisateur

Philips

Philips PR0930X3 Manuel utilisateur

Philips

Philips Brilliance 231P4QPY Manuel utilisateur

Samsung

Samsung 55S9 B Series Manuel utilisateur

Philips

Philips 32HF9385D Guide de dépannage

Sharp

Sharp LC-40FI5012E Manuel utilisateur

Loewe

Loewe Table Stand Reference 55 Manuel utilisateur

Philips

Philips 32PFH5300 Manuel utilisateur
