Installation Guide

MXSO1700 Sauna

Should you require additional assistance with the

installation of your product,

please call 01908 317512

or email

customerservices@insigniashowers.com.

www.insigniashowers.com Last Modied: 29/06/2022

INSTALLATION MANUAL

MXOS1700

Outdoor Sauna Series

ATTENTION INSTALLERS:

These instrucons must be

le with the customer

30 Day Technical Support:

Call 01908 317512 and request technical support for aiding your

installaon.

Replacements Parts: Inside of your warranty period visit:

hps://www.insigniashowers.com, click support and make a

warranty claim.

Spares/Replacements Parts: Outside of your warranty period visit

hps://www.insigniashowers.com/replacement-parts.html

CHECK ALL CONTENTS BEFORE BUILD COMMENCES. NO RETURNS CAN BE MADE

ONCE THE BUILD HAS STARTED AS IT IS DEEMED ACCEPTANCE OF PRODUCT!

www.insigniashowers.com Last Modied: 29/06/2022

Contents

Thank you for your purchase 3

Electrical & Tool requirements 4

Box contents 5

Creang the base 6

Installing the back right upright 7

Installing the back panel 8

Installing the back le upright 9

Installing the right side panel 10

Installing the right front upright 11

Installing the le side panel 12

Installing the front le upright 13

Electric box install 14

Installing the top frame 15

Floor placement 16

Placing the bench front 17

Under seat support frame install 18

Bench seat install 19

Back rest install 20

Installing the xed glass panel 21

Installing the inner roof 22

Installing the big roof 23

Installing the heater and heater guard 24

Installing the door handle 25

Installing the door 26

Installing the accessories 27

Control Panel Instrucons/Operaon 28

Before First Use—IMPORTANT 31

Sauna Room Safety Guide 32

WEEE Compliance Statement 33

www.insigniashowers.com Last Modied: 29/06/2022

Thank you for your recent purchase of an Insignia Sauna. Please read this booklet with

great care to ensure you get the best out of your build and have a Sauna that will last

for many years to come! Like everything, in order to obtain a rst class product that

will serve you well for many years, the eort and correctness put into the assembly

will reect in the quality of your nish.

Please note: Like all timber products, such as garden sheds and fencing, garden

saunas require full exterior wood weatherproofing treatment after installation to

ensure long life and prevention of water ingress.

www.insigniashowers.com Last Modied: 29/06/2022

•Scissors

•Knife

•Spirit Level

•Tape Measure

•Philips Screwdriver

•Electric Drill

•Safety Gloves

•Safety Glasses

Tools Required

Power Rating 4.5KW

Always consult a qualied Electrician before connecon as to suitability

Your electrical contractor will understand ALL legal requirements of connecon before

undertaking any work or installaon.

UNDER NO CIRCUMSTANCES UNDERTAKE THIS YOURSELF WITHOUT CONSULTATION

The MXOS 1700 is 240 volt compliant. Due the nature of use and current UK legislaon,

connecon from the house to sauna must always be completed by a qualied electrical

contractor. In all circumstances our recommendaon is direct supply your house service board.

On compleon always request a copy of a Minor Works Cercate showing completed required

connecon and circuit tests. In many cases this will be a legal requirement.

Electrics

www.insigniashowers.com Last Modied: 29/06/2022

What’s in the Boxes?

Contents Quanty

Back Panel

Le Panel

Right Panel

Fixed Glass

Door

Inner Roof

Big Roof

Sauna Heater

Heater Guard

[ ]

VERY IMPORTANT

Have you got everything? If not please contact the Insignia directly on 01908 317 512.

Remember NEVER book your tradesman unl everything has arrived, been checked and is

present. No replacement/missing parts can be obtained free of charge during or aer the

build. Any claims can only be within the mescale permied (48 hours aer delivery) and

always BEFORE build.

Contents Quanty

Light

Door Handle

Sauna Rocks

Backrest

Bench Top

Bench Vercal Supports

Under Bench Support

Screw Pack

[ ]

www.insigniashowers.com Last Modied: 29/06/2022

Step 1 — Creang the base

Create a square using the 4 boom struts.

Note: The front strut has a groove cut out

for the front xed glass panel. Make sure

this strut is at the front of the square.

www.insigniashowers.com Last Modied: 29/06/2022

Step 2 — Installing rear right upright

There will be 3 screw connecons on two faces of

the upright. They should face towards the back

boom strut and right boom strut.

www.insigniashowers.com Last Modied: 29/06/2022

Step 3 — Installing the back panel

Li the back panel and slide the brackets over the

screw xings and lock into posion. Also ensure you

push the panel down onto the back boom strut and

ensure they lock together.

www.insigniashowers.com Last Modied: 29/06/2022

Step 4 — Installing the back le upright

Tilt the back panel up in order to get the back le upright to slot

into the brackets. Connect and push the right back upright down

and secure into posion.

There will be 3 screw connecons on two faces of the upright. They

should face towards the back boom strut and le boom strut.
