Insignia MXOS2000 Manuel utilisateur

www.insigniashowers.com Last Modied: 12/01/2022

INSTALLATION MANUAL

MXOS2000

Outdoor Sauna Series

ATTENTION INSTALLERS:

These instrucons must be

le with the customer

30 Day Technical Support:

Call 01908 317512 and request technical support for aiding

your installaon.

Replacements Parts: Inside of your warranty period visit:

hps://www.insigniashowers.com, click support and make a

warranty claim.

Spares/Replacements Parts: Outside of your warranty period

visit

CHECK ALL CONTENTS BEFORE BUILD COMMENCES. NO RETURNS CAN BE MADE

ONCE THE BUILD HAS STARTED AS IT IS DEEMED ACCEPTANCE OF PRODUCT!

www.insigniashowers.com Last Modied: 12/01/2022

Contents

Thank you for your purchase 3

Electrical & Tool requirements 4

Box contents 5

Creang the base 6

Installing the back le upright 7

Installing the back panel 8

Installing the back right upright 9

Installing the right side panel 10

Installing the backrest panels 11

Installing the front right upright 12

Installing the le side panel 13

Installing the front le upright 14

Electric box install 15

Floor placement 16

Installing the bench side 17

Installing the back upper bench support 18

Installing the right upper bench support 19

Installing the back lower bench support 20

Installing the right lower bench support 21

Installing under seat support frames 22

Installing benches 23

Installing top framework 24

Installing the xed glass panel 25

Installing the inner roof 26

Installing the big roof 27

Installing the door 28

Installing the heater guard 29

Installing the accessories 30

Control Panel Instrucons/Operon 31

Sauna Room Safety Guide 34

WEEE Compliance Statement 35

www.insigniashowers.com Last Modied: 12/01/2022

Thank you for your recent purchase of an Insignia Sauna. Please read this booklet with

great care to ensure you get the best out of your build and have a Sauna that will last

for many years to come! Like everything, in order to obtain a rst class product that

will serve you well for many years, the eort and correctness put into the assembly

will reect in the quality of your nish.

www.insigniashowers.com Last Modied: 12/01/2022

• Scissors

• Knife

• Spirit Level

• Tape Measure

• Philips Screwdriver

• Electric Drill

• Safety Gloves

• Safety Glasses

Tools Required

Voltage Rang 220-240AC

Frequency Rang 50Hz

Power Rang 15.2 kW

Always consult a qualied Electrician before connecon as to suitability

Your electrical contractor will understand ALL legal requirements of connecon before

undertaking any work or installaon.

UNDER NO CIRCUMSTANCES UNDERTAKE THIS YOURSELF WITHOUT CONSULTATION

All connecons MUST be carried out by an approved part P electrician and a minor works

cercate must be issued upon compleon. This product is NOT designed for DIY install and

improper installaon could be fatal.

Please use correct size and type to meet electrical codes. Leave 2 feet of slack wire at generator

locaon for nish hook-up. Connect the generator to a dedicated circuit breaker.

Electrics

www.insigniashowers.com Last Modied: 12/01/2022

What’s in the Boxes?

Contents Quanty

Back Panel

Le Panel

Side Panel

Fixed Glass

Door

Inner Roof (Halves)

Big Roof

Sauna Heater

Heater Stand

Heater Guard

[ ]

VERY IMPORTANT

Have you got everything? If not please contact the Insignia directly on 01908 317 512.

Remember NEVER book your tradesman unl everything has arrived, been checked and is

present. No replacement/missing parts can be obtained free of charge during or aer the

build. Any claims can only be within the mescale permied (48 hours aer delivery) and

always BEFORE build.

Contents Quanty

Light

Door Handle

Sauna Rocks

Backrests

Bench Top

Bench Vercal Supports

Under Bench Support

Screw Pack

[ ]

www.insigniashowers.com Last Modied: 12/01/2022

Step 1 — Creang the base

Create a square using the 4 boom struts.

Note: The front strut has a groove cut out

for the front xed glass panel. Make sure

this strut is at the front of the square.

www.insigniashowers.com Last Modied: 12/01/2022

Step 2 — Installing rear le upright

There will be 3 screw connecons on two

faces of the upright. They should face towards

the back boom strut and le boom strut.

www.insigniashowers.com Last Modied: 12/01/2022

Step 3 — Installing the back panel

Li the back panel and slide the brackets over the

screw xings and lock into posion. Also ensure you

push the panel down onto the back boom strut and

ensure they lock together.

www.insigniashowers.com Last Modied: 12/01/2022

Step 4 — Installing the back right upright

Tilt the back panel up in order to get the back right upright to

slot into the brackets. Connect and push the right back

upright down and secure into posion.

There will be 3 screw connecons on two faces of the

upright. They should face towards the back boom strut and

right boom strut.

www.insigniashowers.com Last Modied: 12/01/2022

Step 5 — Installing the right side panel

Li the side panel and slide the brackets over the

screw xings and lock into posion. Also ensure you

push the panel down onto the right boom strut and

ensure they lock together.
