InnoMedia MTA6328 Manuel utilisateur
InnoMedia 6328 Quick Reference Guide
1
Copyright © 2016 InnoMedia. All rights reserved.
InnoMedia MTA6328 Quick Configuration Guide
V2.1 November 2017
InnoMedia 6328 Quick Reference Guide
2
Copyright © 2016 InnoMedia. All rights reserved.
Table of Contents
1
MTA6328 GENERAL ....................................................................................................................................... 3
2
ADMIN WEB CONSOLE .................................................................................................................................. 3
2.1
M
AIN
P
AGE
..................................................................................................................................................... 3
2.2
P
ORT
S
TATUS
S
CREEN
: ...................................................................................................................................... 4
2.3
VOIP
P
ROFILE
C
ONFIGURATION
.......................................................................................................................... 4
2.4
C
ONFIGURING
IP
A
DDRESS
................................................................................................................................. 6
2.5
E
NABLING
P
ROVISIONING
................................................................................................................................... 7
3
TELNET CONSOLE ........................................................................................................................................... 7
3.1
V
IEW
V
ERSION
I
NFO
......................................................................................................................................... 7
3.2
B
ASIC
D
EVICE
&
SIP
C
ONFIGURATION
I
NFO
........................................................................................................... 8
3.3
E
NABLE
D
EBUG
T
RACE TO BE SENT TO
S
YSLOG
S
ERVER
............................................................................................. 9
3.4
R
EBOOT THE
MTA
SYSTEM
................................................................................................................................ 9
3.5
F
ORCE
SIP
A
CCOUNT
R
EGISTRATION
.................................................................................................................. 10
3.6
E
NABLE
EMS ................................................................................................................................................ 10
3.7
E
NABLE
E
ND OF
C
ALL
S
TATISTICS
....................................................................................................................... 10
3.8
S
HOW
A
LL
CLI
COMMANDS
.............................................................................................................................. 10
4
RESTORE TO FACTORY DEFAULT .................................................................................................................. 12
4.1
CLI .............................................................................................................................................................. 12
4.2
W
EB
GUI ..................................................................................................................................................... 12
4.3
R
ESTORE
B
UTTON ON BACK OF
MTA ................................................................................................................. 13
5
APPENDIX B. DIGITMAP USAGE RULES ........................................................................................................ 14
InnoMedia 6328 Quick Reference Guide
3
Copyright © 2016 InnoMedia. All rights reserved.
1 MTA6328 General
This Quick Reference Guide provides easy steps to login the unit and perform basic configuration quickly
to make a first call, and discusses some debug utilities in the CLI. It does not cover auto-provisioning.
2 Admin WEB Console
Access the MTA from its WAN Interface. By default, the MTA WAN interface is configured as DHCP
client. Dial ***1 from the phone to check WAN IP assigned by the router.
Access the MTA from its LAN interface. The default IP address of the MTA LAN interface is
192.168.99.1. Configure the NIC which connects to the MTA LAN interface with a fixed IP in the
same subnet of 192.168.99.X/24, e.g., 192.168.99.2.
Enter the IP address of the MTA to your web browser, and you will get the pop-up screen to input “User
Name” and “Password”. Default User Name and Password is “Admin” and “password” respectively.
2.1 Main Page
The Main page contains details of the “Firmware Version” and time since last successful provisioning. It
also gives the “System Up Time” which shows how long the device is running since it last rebooted or
powered-up.
InnoMedia 6328 Quick Reference Guide
4
Copyright © 2016 InnoMedia. All rights reserved.
2.2 Port Status Screen:
1. User Account/Phone Number registration status can be seen in the Port Status menu. In
addition to each port’s registration status, it gives real-time off-hook or talk state status.
2.3 VOIP Profile Configuration
1. The SIP Proxy, Domain, digit map, packetization time, and codec information can be
configured on the Profile Config Menu.
2. You may select the Port Config menu to see other details for each FXS port or line of the
device
Note: Whatever is configured on the “Port Config” will override what is configured in “Profile Config”.
InnoMedia 6328 Quick Reference Guide
5
Copyright © 2016 InnoMedia. All rights reserved.
3. The default of the Digimap is ***1|X.T|X.# and won’t show on the GUI. If there is at least
one digit map rule configured, then the MTA will only apply the configured rules and ignore
the default. You will need to configure these three default if you are using them. (Please
refer to 5 for descriptions of digitmap configuration rules.)
InnoMedia 6328 Quick Reference Guide
6
Copyright © 2016 InnoMedia. All rights reserved.
2.4 Configuring IP Address
IP address configuration can be done on Interface Setting menu. By default, the device is configured as
a DHCP client.
InnoMedia 6328 Quick Reference Guide
7
Copyright © 2016 InnoMedia. All rights reserved.
2.5 Enabling Provisioning
This screen allows to enable and configure basic provisioning parameters.
Note: Details for Provisioning - Provisioning method selection, encryption type etc must be done from CLI.
Please refer to the MTA6328 Admin Guide document for detailed description.
3 Telnet Console
Access the MTA CLI console via Telnet requires the input the same ID and Password as those of the WEB
console.
Command H displays all available commands.
3.1 View Version Info
Command: V <Cr>
V
The Image Version is: 4.2.68
Control Code Version = 4.2.68 6328-2Re Sat Oct 16 22:41:48 2010
DSP Code Version = 2.5.22 10/16 18:56 2010
InnoMedia 6328 Quick Reference Guide
8
Copyright © 2016 InnoMedia. All rights reserved.
BBS Version=7.3.38
SIP Stack Version=2.15.1
Hardware version = 10.0.0.6
Layout Version = A4-2
System Up Time:00 hours, 00 minutes, 57 seconds ago
3.2 Basic Device & SIP Configuration Info
Check the current IP, Provisioning Server, SIP Proxy and Domain information.
Command: Cf <Cr>
Cf
Your current configuration:
Your MTA Name= 6328-2Re
System Enable Provisioning Process = TRUE;
SYSLOG Server = 255.255.255.255;
SIP Proxy Server:
(Profile 1) sbc.abc.net
Current Local SIP Signaling Port:
(Profile 1) 5060
SIP Domain:
(Profile 1) metaswitch.abc.net
STUN Disabled
CODECs
channel 1: ptime:40 ms; G729 G729A
channel 2: ptime:40 ms; G729 G729A
RTP port: 10000
Current Silence Suppression settings:
(Channel 1) Yes, send RFC3389 SID frame:No
(Channel 2) Yes, send RFC3389 SID frame:No
Current Echo Cancellation Settings:
(Channel 1) Yes
(Channel 2) Yes
DSCP for signal: 160,0xa0
DSCP for voice: 0,0x0
DSCP for other: 0,0x0
DSCP for LAN traffic: 0,0x0
Prov_Server_Name: device.abc.com
DHCP Check Option 43 disable
Ether Address = 00:10:99:02:8b:92;
You are using DHCP.
Local IP = 172.16.0.135;
Local IP Mask = 255.255.0.0;
Local Default GW IP = 172.16.0.1;
Local Default GW Mask = 255.255.0.0;
Primary Domain Name Server = 4.2.2.1;
Secondary Domain Name Server = 172.16.0.2;
InnoMedia 6328 Quick Reference Guide
9
Copyright © 2016 InnoMedia. All rights reserved.
System Up Time:00 hours, 00 minutes, 51 seconds ago
4. Ping from CLI
From the CLI you can ping to see if your network connection is up and able to get to a remote IP. You
can ping by Domain or IP.
ping www.google.com <Cr>
or
ping 74.125.224.52 <Cr>
5. Enable and Disable Debug Information
To capture debug information.
Command sequence:
D1 <Cr> (to enable debug)
Tl <Cr> (l is lower case L)
D1
Debugging is enabled.
Tl – (L lower Case L)
Please enter the level you want to trace: 50
Traces less than or equal to trace level 50 will be printed out.
D0 <Cr> (D Zero, to disable debug)
Note: Tl level 50 for signaling; 80 for signaling and dsp; 101 for provisioning
3.3 Enable Debug Trace to be sent to Syslog Server
Command: Mq <Cr>
Enter the syslog server IP address.
Note that if there is no syslog server configured, the MTA display the messages to the console screen.
3.4 Reboot the MTA system
Command: R
InnoMedia 6328 Quick Reference Guide
10
Copyright © 2016 InnoMedia. All rights reserved.
3.5 Force SIP Account Registration
Command: Sn <Cr>
Sn
1 - sign on channel 1
2 - sign on channel 2
all - sign on ALL channels
Type 1, or 2, or all
3.6 Enable EMS
Command: Cx <Cr>
EMS Config
Config EMS Setting
p: Display Current Setting
1: Set EMS Enable/Disable
2: Set EMS Device Type
3: Set EMS Region ID
4: Set EMS Server
5: Set EMS Local Port
6: Set EMS Heartbeat type
7: Set EMS Heartbeat Interval
8: Set EMS Encrpytion Key
w: Write update to Flash
q: Exit EMS config
3.7 Enable End of Call Statistics
Command: Cg <Cr>
RTCP-XR is Disabled
Please enter "Y" to Enable it or "Q" to quit: y
3.8 Show All CLI commands
Command: H <Cr>
C: Configuration: Operation Database
Cd: Configuring DigitMap
Cj: Configuring Jitter Buffer Size
Ct: Configure FXS Setting Parameters
Cs: Configuring SIP Settings
