InFocus LP 725 Manuel utilisateur

INTRODUCTION

The In Focus®LP™ 725 and 730 lightweight multimedia projec-

tors combine powerful and sophisticated features with easy-to-

use, intuitive controls. Built-in multimedia features include

audio, a palette of 16.7 million colors and active matrix liquid

crystal display (LCD) technology. The 700 series projectors are

ideal for high-performance business, training and imaging appli-

cations that demand exceptional color quality. The 725 has SVGA

800x600 graphics, the 730 has XGA 1024x768 graphics. The user

interfaces of the two products are identical; information in this

User’s Guide applies to both products.

NOTE: The 725 automatically

expands 640x480 images to

800x600. You can display these

images at 640x480 by turning off

the Auto Resize feature. See “Auto

Resize” on page 35 for more infor-

mation.

Image Resolution

LP 725

The SVGA resolution of the 725’s projected image is 800x600.

Screen resolutions between 800x600 and 1024x768 are com-

pressed to 800x600. The 725 cannot compress screen resolutions

above 1024x768. If your computer’s screen resolution is higher

than 1024x768, reset it to a lower resolution before you connect

the 725.

LP 730

NOTE: The 730 automatically

expands 640x480 and 800x600

images to 1024x768. You can dis-

play these images at their original

resolutions by turning off the Auto

Resize feature. See “Auto Resize”

on page 35 for more information.

The XGA resolution of the 730’s projected image is 1024x768.

Screen resolutions between 1024x768 and 1280x1024 are com-

pressed to 1024x768. The 730 cannot compress screen resolutions

above 1280x1024. If your computer’s screen resolution is higher

than 1280x1024, reset it to a lower resolution before you connect

the 730.

Introduction

Compatibility

The projector is compatible with a wide variety of computers and

video devices, including:

NOTE: Selected workstations are

also supported. Contact your In

Focus dealer for details.

•IBM-compatible computers, including laptops, up to 1024x768

resolution (LP 725) or 1280x1024 resolution (LP 730) at 75 Hz.

•Apple Macintosh and PowerBook computers up to 1024x768

resolution (LP 725) or 1280x1024 resolution (LP 730).

•Most standard VCRs, camcorders and laser disc players.

Unpacking the Projector

The projector comes with the items shown in Figure 1. Check to

make sure all are included. Contact your In Focus dealer immedi-

ately if anything is missing.

If you are experienced in setting up presentation systems, use the

LP 725/730 Quick Start card that was included in the shipping

box. For complete details on connecting and operating the projec-

tor, refer to this User’s Guide. User’s Guides are also available for

download from our website at www.infocus.com.

NOTE: The contents of your

shipping box may vary depending

on the configuration you’ve

ordered.

FIGURE 1

Shipping box contents

1. LP 725 or 730 projector 6. CableWizard

2. LP 725/730 User’s Guide 7. CableWizard computer cable

3. power cord 8. CableWizard mouse cable

4. remote and batteries 9. CableWizard audio cable

5. RCA audio/video (A/V) cable

Not shown: Quick Start card, online user guide CD-ROM, lens cap

Introduction

IGURE 2

Side view of projector

FIGURE 3

Front view of projector

connector panel

elevator button

speaker

power

switch power

cord

connector focus ring zoom ring

remote control

receiver

Usage Guidelines

•Do not look directly into the projection lens when the projector

is turned on. The bright light may harm your eyes.

NOTE: If the projector overheats

and turns off, you must wait about

30 seconds before you attempt to

turn it back on.

•Do not block the grills on the projector. Restricting the air flow

can cause it to overheat and turn off.

•Handle the projector as you would any product with glass

components. Be especially careful not to drop it.

•Avoid leaving the projector in direct sunlight or extreme cold

for extended periods of time. If this happens, allow it to reach

room temperature before use.

•This projector is not intended for use in a mainframe computer

room as defined in the Standard for the Protection of Electronic

Computer/Data Processing Equipment, ANSI/NFPA 75.

•Transport the projector in a vendor-approved hard or soft case.

Part numbers for these cases are listed on page 52. Call your In

Focus dealer to order.

If You Need Assistance

The first place to look for help is in this manual. Be sure to check

the guidelines in “Troubleshooting” on page 44.

If this manual doesn’t answer your question, call your In Focus

dealer. You can also call In Focus Customer Service directly at

1-800-799-9911. Customer Service is free between 5 a.m. and

5 p.m. PST, Monday through Friday. Service is available in North

America after hours and on weekends for a fee.

In Europe, call In Focus in The Netherlands at

(31) 23-5540310. In Singapore, call (65) 740-6435. Or, send us an

e-mail at techsupport@infocus.com

Our World Wide Web address is http://www.infocus.com.

Warranty

This product is backed by a limited one-year warranty. The

details of the warranty are printed at the back of this manual.

Longer term warranties can be purchased from your In Focus

dealer. Refer to page 52 for part numbers.
