TD30
USER’S GUIDE
1
Table of Contents
Notes -------------------------------------------------------------------------------------1
Maintenance, Storage and Proper Placing
TV System Integration----------------------------------------------------------------5
Introduction of Front Panel Functions --------------------------------------------6
Introduction of Connection in the back -------------------------------------------7
Miscellaneous Function Adjustment -------------------------------------------- 10
1. PICTURE ------------------------------------------------------------------------ 10
1-1 Brightness---------------------------------------------------------------- 10
1-2 Contrast ------------------------------------------------------------------ 10
1-3 Auto Picture ------------------------------------------------------------- 10
1-4 Manual Picture---------------------------------------------------------- 11
1-4-1 V Position -------------------------------------------------------- 11
1-4-2 H Size ------------------------------------------------------------- 11
1-4-3 H Position -------------------------------------------------------- 11
1-4-4 Fine Tune--------------------------------------------------------- 11
1-5 Sharpness --------------------------------------------------------------- 12
1-6 Color Temp--------------------------------------------------------------- 12
2. VIDEO ---------------------------------------------------------------------------- 13
2-1 Brightness---------------------------------------------------------------- 13
2-2 Picture -------------------------------------------------------------------- 13
2-3 Color----------------------------------------------------------------------- 13
2-4 TINT ----------------------------------------------------------------------- 13
2-5 Sharpness --------------------------------------------------------------- 13
2-6 Color Temp--------------------------------------------------------------- 14
2-7 Video Enhance---------------------------------------------------------- 14
2-8 NR(Noise Reduction)-------------------------------------------------- 14
3. AUDIO---------------------------------------------------------------------------- 15
3-1 Volume-------------------------------------------------------------------- 15
3-2 Treble --------------------------------------------------------------------- 15
3-3 Bass ----------------------------------------------------------------------- 15
3-4 SRS------------------------------------------------------------------------ 15
3-5 SRS Level---------------------------------------------------------------- 15
3-6 MTS(TV Mode) --------------------------------------------------------- 15
4. SETUP --------------------------------------------------------------------------- 16
4-1 Language ---------------------------------------------------------------- 16
4-2 Gamma ------------------------------------------------------------------- 16
4-3 Aspect--------------------------------------------------------------------- 16
2
4-4 PIP ------------------------------------------------------------------------- 16
4-4-1 Size ---------------------------------------------------------------- 16
4-4-2 Pos----------------------------------------------------------------- 17
4-4-3 Source ------------------------------------------------------------ 17
4-4-4 PIP TV Channel------------------------------------------------- 17
4-5 OSD Style ---------------------------------------------------------------- 17
4-6 Factory Reset ----------------------------------------------------------- 17
Other TV Signal setting ------------------------------------------------------------ 18
Specifications ------------------------------------------------------------------------- 19
The Remote Control Unit ---------------------------------------------------------- 20
Specifications of TV Tuner--------------------------------------------------------- 22
Accessories --------------------------------------------------------------------------- 22
3
Notes
1. Due to the high-voltage power within this LCD, do not expose it to rain or
water. To avoid electric shock or fire, please do not open the LCD back
cover, perform adjustment or clean on it.
2. Please read the manual and notes carefully before operating it.
Maintenance, Storage and Proper Placing
Do not open the LCD case, only an
authorized technician can perform
services on it.
For ventilation, do not place you
r
LCD monitor on a cluttered stack o
r
in a closet.
Do not pull the cable while you are
disconnecting LCD monitor power.
Please hold the plug and then
disconnect the power cable.
To avoid fire or electric shock, do no
t
expose your LCD monitor to rain o
r
water.
4
Do not operate your LCD monito
r
when liquids or solids spill or drop
into the monitor, call an authorized
technician immediately.
When it’s raining with thunder or you
will leave for a period of time, unplug
power.
Do not place your monitor in a high
temperature, moist or dusty place.
Clean your monitor with a slightl
y
damp rag. Do not use a chemical
cleanin
g
solution.
Do not plug the monitor into a
heavily used outlet.
5
TV System Integration
TD30 with professional TV tuner can receive 181 channels (2-69 channels for
wireless TV, 1-125 channels for cable TV), and has the MTS decoding function
to play Stereo or SAP. The parental control prevents views from watching
programs that are not age-appropriate, such as programs containing violence
or adult language; the closed captions includes CC1, CC2, text1 and text2,
show the text under a picture, caption on video are text located somewhere on
the picture.
Function Integration System
6
Introduction of Front Panel Functions
button You can turn on/off the LCD with this button. The LED indicator
is blue when the LCD is on, and is orange when the LCD is off.
SOURCE
button
Press this button to change and display TV signals such as
RGB/DVI/HDTV YPbPr/Component/S-Video/AV-Video1/
AV-Video 2/TV.
MENU button Press this button to open the OSD, and continuously press this
button to select the main function to use.
(please see page 9; OSD operation)
PROG▲▼
button
Press ▲button to select channel forward and ▼button
to select channel backward
If you use this button with the MENU button, you can select
the desired item after opening the OSD.
VOL+/-
Button
Press + button to increase the audio volume and – button
to decrease the audio volume.
With the MENU button, you can use this button to adjust
functions.
AUTO button Press this button to perform automatic adjustment.
Remote
receiver
LED indicator:
Blue when On,
and Orange
when Off.
7
Introduction of Connection in the back
This high-resolution LCD monitor can be substituted for your domestic TV or
small CRT monitor. it can receive signals from UHF/VHF/CATV/HDTV and
VCD/DVD.
AC Input This terminal is for the connection of 110~264VAC power
supply.
RS-232C Input This terminal is especially for the manufacturer and after
sales service, not for customers.
DIGITAL Input This 24-pin DVI-D terminal is for the digital RGB input
signal from the computer.
ANALOG Input This 15-pin mini D-sub terminal is for the analog RGB
input signal from the computer.
AUDIO Input This 3.5ψMini jack is for the audio input signal from the
computer.
8
9
HDTV (Y/Pb/Pr) Input It can receive 480i/480p/720p/1080i AV signal to
provide a better image.
COMPONENT
(Y,Pb/Cb,Pr/Cr) Input
It can receive general DVD-level 480i/480p AV signal
to provide Hi-fi image.
4V1L1R1 AV Input It is provided for AV equipment such as
VCR/VCD/DVD.
Note: If you want to connect to a mono video player, plug
the yellow and white connectors to their corresponding
jacks.
S-VIDEO/V2L2R2
AV Input
It is provided for AV equipment such as
VCR/VCD/DVD.
When S-Video and AV inputs simultaneously receive
signals, the S-Video input will receive signals first.
VIDEO Output You can connect it to the video player to record TV
programs.
LR Audio Output You can connect it to AUX or a family amplifier to
enhance sound effects.
RF Input This terminal is for general antennas and CATV.
Tip: TD30 has 4 types of standard video connections. You should use the
best connection available to get the best display.
For example, Ypbpr (HDTV) > Ycbcr (Component) > S-video > AV (Composite)
> Coaxial (RF)
