infobit iCam VB60 Manuel utilisateur
iCam VB60
USB-C to USB-A Cable
(5m/16.4ft)
Remote control
Power Adapter
User Guide
Package Contents
3
User Guide
www.infobitav.com [email protected]
Ethernet Cable(8m/26.2ft)
Optional Accessories
Screen Mount
Wall Mount Torx Key
*Optional accessories are not included in this package, they
are sold separately.
4
www.infobitav.com [email protected]
Functions
118 ° diagonal field of view, so that any participants
can be clearly visible
4K@30fps UHD video call
Speaker tracking and closeup group
High acoustic clarity, thanks to our generous
5-element omnidirectional microphone
Outstanding speaker quality tuned for both phone calls
and music
Effective pickup distance up to 5 meters, full duplex
technology brings clear and uninterrupted calls
Absolutely echo-free and fine-tuned for various
acoustic environments
Daisy chain iSpeaker M500 Speaker Mic to adapt to all
kinds of conference rooms
Plug & Play, connect to PC via USB
5
www.infobitav.com [email protected]
Product Overview
1 2
Camera LED
Status LED
1
2
3
4
5
6
3 4 5 6
USB Type-C Port
Factory Reset Pinhole
Ethernet Port For Daisy Chain
DC Power Input Jack
6
www.infobitav.com [email protected]
RC Guide
1.Camera off 2.Camera on
3.Mirror 6.Hand up
4.Power line frequency 5.Answer
7.Preset 1
9.Image up
10.Image left
13.Panorama
14.Previous mode
16.Switch AI modes
17.Switch AI submodes
11.Image right
12.Image down
15.Mute mic
18.Volume up
19.Volume down
20.Zoom in
21.Zoom out
8.Preset 2
7
www.infobitav.com [email protected]
RC Guide
NO. Button Description
1 Camera off Turn off the camera
2 Camera on Turn on the camera
3 Mirror Activate or deactivate mirror function
4 Power line frequency Switch between 50Hz and 60 Hz
5 Answer Compatible with UC software
6 Hand up Compatible with UC software
7 Preset 1 Short press to preset 1, long press to current position
8 Preset 2 Short press to preset 2, long press to current position
9 Image up Image up
10 Image left Image left
11 Image right Image right
12 Image down Image down
13 Panorama Switch to panoramic view
14 Previous mode Back to previous saved AI mode
15 Mute mic Mute or unmute microphone
16 Switch AI modes Auto framing, speaker tracking, closeup group mode switch,
Panoramic view switch
17 Switch AI submodes
1. Panoramic view
2. Speaker tracking: a. delay 1 sec, b. delay 2 sec, c. delay 3 sec,
d. delay 4 sec, e. delay 5 sec
3. Closeup Group: a. max to 2 windows b. max to 4 windows
c. max to 6 windows
18 Volume up
19 Volume down
20 Zoom in Image +
21 Zoom out Image -
Voice +
Voice -
8
www.infobitav.com [email protected]
2.Mount on a Screen
*Using the screen mount may change central gravity of the
screen. Check the stability after mounting the iCam VB60
. If not stable, the screen should be wall mounted.
10
www.infobitav.com [email protected]
