Chapter I General Description
1.1 Description
The V2403 series Video Distribution Amplifier provides a
cost-effective means of maintaining CCTV video quality for
long-distance transmission and for video signal distribution.
In most CCTV surveillance/security applications, live video images
from a site camera may require to be transmitted over a long
distance or be viewed at different control sites. In each case, the
video transmission may be hampered by signal attenuation and
undesirable noises.
The V2403 series Video Distribution Amplifier is designed as an
easy-to-use solution for these conditions. It amplifies a set of 4
video signals, and distributes them into 8 sets of video outputs (4 for
each), or it amplifies a set of 8 video signals, and distributes them
into 4 sets of video outputs (8 for each), or it amplifies a set of 16
video signals, and distributes them into 2 sets of video outputs (16
for each),. Each video output has the same quality as the original
input signal, ensuring non-degrading transmission over a long
distance or to different sites.
The distribution amplifier is compatible with standard B&W and
color video systems, and features a wide frequency response.
The V2403 series Video Distribution Amplifier is a plug-and-play
device that requires no manual adjustment.
Rack or desktop mount options are available for different
configurations.
1.2 Features
zDistribute a set of 4 video signals into 8 sets of video outputs(4
for each);
zDistribute a set of 8 video signals into 4 sets of video outputs(8
for each);
zDistribute a set of 16 video signals into 2 sets of video outputs(16
for each);
zCompact design and easy installation
zB&W or color video compatible
zWide frequency response
zNo manual adjustment required
zDesktop or rack mounting optional
Chapter II Installation and Operation
2.1 Installation
The V2403 series Video Distribution Amplifier is 1.7 inches in
height by 19 inches in width and 10.2 inches in depth. It can be
configured for either rack or desktop mounting. Please refer to the
following dimension diagram for installation.
1.7 in.
44mm
19 in.
483mm
10.2 in.
260mm
VIDEO DISTRIBUTION AMPLIFIER
POWER
Figure 2-1. V2403 Dimensions
Note: Please ensure adequate ventilation around the V2403-16 unit
to prevent overheat.
2.2 Panels
2.2.1 Front Panel View
VIDEO DISTRIBUTION AMPLIFIER
POWER
Infinova ®
Figure 2-2. V2403 Front Panel
2.2.2 Rear Panel View
V2403-4 Rear Panel
12345678
VIDEO
INPUT
1234567812345678
VIDEO
OUTPUT
1234567812345678
100~240VAC
50/60H z
V2403-8 Rear Panel
12345678
VIDEO
INPUT
9 101112 14151613
12345678
12345678
VIDEO
OUTPUT 9101112 14151613
9101112 14151613
100~240VAC
50/60H z
V2403-16 Rear Panel
Figure 2-3. V2403 Rear Panel（with no ear）
2.3 Hardware Connections
2.3.1 Video Input Connections
The V2403-4 provides a group of 4 BNC connectors, labeled as
"VIDEO INPUT”. The V2403-8 provides a group of 8 BNC
connectors, labeled as "VIDEO INPUT". The V2403-16 provides a
group of 16 BNC connectors, labeled as "VIDEO INPUT". Each
