Infinity C205 Manuel utilisateur

INFINITY CLASSIA™SPEAKERS

OWNER’SGUIDE

C205

C336

CC225

ENGLISH

01-INFP2010Classia-OM_EN.qxp:Primus II OM 14/02/08 17:39 Side 1

INFINITY CLASSIA™SERIES

The Infinity Classia™series of loudspeakers continues the longstanding

Infinity®commitment to accurate sound reproduction. Our patented Ceramic

Metal Matrix Diaphragm (CMMD®) drivers, precision dividing networks

and rigid, well-braced enclosures combine to deliver uncompromised

performance in any stereo or multichannel home theater system.

In addition, Infinity Classia speakers are magnetically shielded for

safe placement adjacent to a television.

UNPACKING THE SPEAKERS

If you suspect damage from transit, report it immediately to your dealer.

Keep the shipping carton and packing materials for future use.

WHAT’SINCLUDED

PLACEMENT

Stereo

Before deciding where to place your speakers, survey your room and

think about placement, keeping the following points in mind, using

Figure 1 as a guide:

• For best results, place the speakers 6'– 8' apart.

• Position each speaker so that the tweeter is approximately at ear level.

• Generally, bass output will increase as the speaker is moved closer to

a wall or corner.

• Refer to the“Home Theater”section if you also plan to use the speakers

for home theater reproduction.

Figure 1. Experiment with speaker placement to obtain the best

bass level and stereo imaging in your room.

HOME THEATER

For front-channel use, place one speaker on the left and another on the

right, along either side of the television monitor. Since the speakers are

magnetically shielded, you can place them without worrying about the

field distorting the TV picture.

For surround use, place speakers alongside the listening position.

Final placement depends on room acoustics, availability of space

and your listening preference (Figures 2 and 3).

The CC225 center channel speaker should be placed on top of or directly

below the television and aimed toward the listening area.The CC225

speaker may also be wall-mounted. See page 3.

NOTE: An Infinity powered subwoofer will add impact and realism to both

music and film soundtracks. Contact your Infinity dealer for recommenda-

tions on subwoofer models for your application.

Figure 2.This overhead view shows a typical

home theater plan.

Figure 3.This figure shows an alternate layout,

which may be more suitable for some rooms.

Cleats

Rubber Bumpers (Four for Bottom

of Speaker, One for Rear of Speaker

if Wall-Mounting). See Page 3.

Spike Kit

C205

C336

CC225

1/4"-20 Screws

Wall

Bracket

Rubber Bumpers

(For Bottom of Speaker)

x 4

x 5

Couch

Left

Front

Channel

Left

Surround

Channel

Right

Surround

Channel

Right

Front

Channel

Center

Channel

Infinity Subwoofer

(optional)

Couch

Left

Front

Channel

Left

Surround

Channel

Right

Surround

Channel

Right

Front

Channel

Center

Channel

Infinity

Subwoofer

(optional)

Listening Position

Left

Channel

Right

Channel

2 INFINITY CLASSIA

01-INFP2010Classia-OM_EN.qxp:Primus II OM 14/02/08 17:39 Side 2

INFINITY CLASSIA 3

Figure 4.

Step 1.

Mark the positions on the wall where you would like to place the

mounting screws.

Step 2.

Fasten two 1-1/2," #8 wood screws to the wall using the markings placed

in Step 1 as your guide. Leave an 11/16" space between the wall and

screwhead. If a wall stud is not available, use an appropriate anchor.

Step 3.

Place the speaker on the wall by aligning the keyholes on the back of

the speaker to the screwheads on the wall. Once positioned properly,

the speaker should slide down slightly and become secure.

INSTALLING SPIKED FEET

C336

Four metal spikes are supplied for use when using the outboard feet and

the speaker is to be placed on a carpeted surface to decouple the speaker

from the floor and prevent unwanted damping.To insert the spikes, gently

lay the speaker on its back (not its front or side) on a soft, nonabrasive

surface, unscrew the four rubber-tipped feet and store in a safe place.

Each spike then screws into the threaded insert. Make sure all four spikes

are screwed in completely for stability.

NEVER drag the speaker to move it, as this will damage the spikes, the feet, the

wood cabinet itself, and/or the floor. Always lift the speaker and carry it to its

new location.

WALL-MOUNTING THE C205

The C205 is designed to be mounted directly to a wall. Each speaker has

two keyholes on the back, and will require (2) 1-1/2,"#8 wood screws

with a .33" (8.4mm) screwhead fastened to a wall stud. If a wall stud is

unavailable, install an anchor appropriate for a 1-1/2," #8 screw.

NOTE: The customer is responsible for the correct selection and use of

mounting hardware (available through hardware stores) that will ensure

the proper and safe wall-mounting of the speakers.

Keyhole mounts

Attach rubber bumper

WALL-MOUNTING THE CC225

The CC225 is designed to be mounted directly to a wall.The bracket has

four holes on the back, and will require (4) 1-1/2," #8 wood screws with

a .33" (8.4mm) screwhead fastened to wall studs. If wall studs are unavail-

able, install anchors appropriate for a 1-1/2,"#8 screw.

NOTE: The customer is responsible for the correct selection and use

of mounting hardware (available through hardware stores) that will

ensure the proper and safe wall-mounting of the speakers.

Step 1.

Attach the wall bracket to the wall at the desired location.

Step 2.

Securely fasten the two cleats to the rear of the speaker,

using two included 1/4"-20 panhead screws per cleat.

Step 3.

Carefully slide the cleats on the rear of the speakers over the tabs

of the wall bracket.

Top view

ENGLISH

01-INFP2010Classia-OM_EN.qxp:Primus II OM 14/02/08 17:39 Side 3

Figure 5.This example shows how to connect bare wires to the terminals.

Figure 6. Wiring diagram shows polarity connections for one

channel of a stereo or home theater system.

WIRING THE SYSTEM

IMPORTANT: Make sure all equipment is turned off before making any

connections.

For speaker connections, use a minimum #16-gauge speaker wire with

polarity coding.The side of the wire with a ridge or other coding is

usually considered positive polarity (i.e., +).

NOTE: If desired, consult your local Infinity dealer about speaker wire and

connection options.

The speakers have coded terminals that accept a variety of wire connec-

tors. The most common connection is shown in Figure 5.

To ensure proper polarity, connect each +terminal on the back of the

amplifier or receiver to the respective +(red) terminal on each speaker,

as shown in Figure 6. Connect the –(black) terminals in a similar way.

See the owner’s guides that were included with your amplifier, receiver

and television to confirm connection procedures.

IMPORTANT: Do not reverse polarities (i.e., + to –, or –to +) when

making connections. Doing so will cause poor imaging and diminished

bass response.

BI-WIRING

C336

The outer connection panel and internal dividing network of the C336 is

designed so that separate sets of speaker cables can be attached to the low-

frequency transducer and midrange/high-frequency transducer portions of this

dividing network.This is called bi-wiring. Bi-wiring can provide several sonic

advantages and considerably more flexibility in power amplifier selection.

Figure 7.

Single-Stereo Amplifier

Figure 8.

Dual-Stereo Amplifier

Figure 9.

4 INFINITY CLASSIA

01-INFP2010Classia-OM_EN.qxp:Primus II OM 14/02/08 17:39 Side 4

FINAL ADJUSTMENTS

Check the speakers for playback, first by setting the system volume con-

trol to a minimum level, and then by applying power to your audio system.

Play a favorite music or video segment and increase the system volume

control to a comfortable level.

NOTE: You should hear balanced audio reproduction across the entire

frequency spectrum. If not, check all wiring connections or consult

the authorized Infinity dealer from whom you purchased the system

for more help.

The amount of bass you hear and the stereo-image quality will be affected

by a number of different factors, including the room’s size and shape,

the construction materials used to build the room, the listener’s position

relative to the speakers, and the position of the speakers in the room.

Listen to a variety of music selections and note the bass level. If there is

too much bass, move the speakers away from nearby walls. Conversely, if

you place the speakers closer to the walls, there will be more bass output.

Nearby reflecting surfaces can adversely affect stereo-imaging quality. If

this happens, try angling the speakers slightly inward toward the listening

position until the optimal effect is achieved.

CARE OF YOUR SPEAKER SYSTEM

Each Infinity Classia cabinet has a finish that does not require any routine

maintenance.When needed, use a soft cloth to remove any fingerprints or

dust. Clean the grille by gentle vacuuming.

NOTE: Do not use any cleaning products or polishes on the cabinet

or grille.

In the event that your Infinity speaker needs service, contact your Infinity

dealer or distributor, or visit www.infinitysystems.com for the location of

the nearest service center.

INFINITY CLASSIA 5

ENGLISH

01-INFP2010Classia-OM_EN.qxp:Primus II OM 14/02/08 17:39 Side 5

6 INFINITY CLASSIA

SPECIFICATIONS

C205 C336 CC225

Frequency Ranges: 60Hz – 30kHz (–3dB) 40Hz – 30kHz (–3dB) 55Hz – 30kHz (–3dB)

55Hz – 40kHz (–6dB) 35Hz – 40kHz (–6dB) 50Hz – 40kHz (–6dB)

Recommended

Amplifier Power Range: 10 – 125 Watts 10 – 250 Watts 10 – 150 Watts

Sensitivity (2.83V @1 meter): 88dB 91dB 90dB

Nominal Impedance: 8 Ohms 8 Ohms 8 Ohms

Crossover Frequencies: 2.0kHz; 24dB/octave 500Hz, 2.8kHz; 24dB/octave 2.0kHz; 24dB/octave

Low-Frequency Driver(s): 5-1/4" (133mm) CMMD,

®Triple 6-1/2" (165mm) CMMD,

®Dual 5-1/4" (133mm) CMMD,

magnetically shielded magnetically shielded magnetically shielded

Mid-Frequency Driver: N/A 4" (100mm) CMMD, N/A

magnetically shielded

High-Frequency Driver: 1" (25mm) CMMD, 1" (25mm) CMMD, 1" (25mm) CMMD,

magnetically shielded magnetically shielded magnetically shielded

Dimensions (H x W x D): 15-1/8" x 7-1/2" x 9-1/4" 48-3/4" x 8-1/2" x 10-1/2" 6-7/8" x 31-3/4" x 5"

(384mm x 190mm x 235mm) (1238mm x 216mm x 267mm) (175mm x 806mm x 127mm)

Weight: 10.8 lb (4.9kg) 56.1 lb (25.4kg) 16 lb (7.3kg)

Features, specifications and appearance are subject to change without notice.

Declaration of Conformity

We, Harman Consumer Group, Inc.

2, route de Tours

72500 Château du Loir

France

declare in own responsibility that the products described

in this owner’s manual are in compliance with technical

standards:

EN 61000-6-3:2001

EN 61000-6-1:2001

Laurent Rault

Harman Consumer Group, Inc.

Château du Loir, France 02/08

01-INFP2010Classia-OM_EN.qxp:Primus II OM 14/02/08 17:39 Side 6

INFINITY CLASSIA 7

NOTES

ENGLISH

01-INFP2010Classia-OM_EN.qxp:Primus II OM 14/02/08 17:39 Side 7

Infinity Systems, 250 Crossways Park Drive, Woodbury, NY 11797 USA 516.674.4463 (USA only) www.infinitysystems.com

Infinity and CMMD (patent nos. 6,327,372 and 6,404,897) are trademarks of Harman International Industries, Incorporated,

registered in the United States and/or other countries. Infinity Classia is a trademark of Harman International Industries, Incorporated.

Part No. BO-13333-01

01-INFP2010Classia-OM_EN.qxp:Primus II OM 14/02/08 17:39 Side 8

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Infinity Intervenants

Infinity

Infinity Kappa Series 32.9cf Manuel utilisateur

Infinity

Infinity ERS 110 Manuel utilisateur

Infinity

Infinity Kappa 10926 Manuel utilisateur

Infinity

Infinity L-MPS Manuel utilisateur

Infinity

Infinity Renaissance 90 Manuel utilisateur

Infinity

Infinity Intermezzo 2.6p Manuel utilisateur

Infinity

Infinity Reference 2000.6 Manuel utilisateur

Infinity

Infinity Intermezzo 3.5c Manuel utilisateur

Infinity

Infinity TOTAL SPEAKER SOLUTIONS TSS-STAND4000 Manuel utilisateur

Infinity

Infinity QPS1 Manuel utilisateur

Infinity

Infinity DPF-8000 Manuel utilisateur

Infinity

Infinity KAPPA 62ix Manuel utilisateur

Infinity

Infinity Total Solutions TSS-SAT4000 Manuel utilisateur

Infinity

Infinity Kappa Video II Series Manuel utilisateur

Infinity

Infinity INTERLUDE IL10 Manuel utilisateur

Infinity

Infinity Total Solutions TSS-CENTER4000 Manuel utilisateur

Infinity

Infinity BassLink Manuel utilisateur

Infinity

Infinity Outrigger Manuel utilisateur

Infinity

Infinity SONY KP-57XBR10W Manuel utilisateur

Infinity

Infinity PRELUDE FORTY Manuel utilisateur

Infinity

Infinity Classia C205 Manuel utilisateur

Infinity

Infinity TSS-Sub1200 Manuel utilisateur

Infinity

Infinity INTERMEZZO 2.6 Manuel utilisateur

Infinity

Infinity Primus P252 Instructions de montage

Manuels Intervenants populaires d'autres marques

argon audio

argon audio IE20 Manuel utilisateur

Denon

Denon SC-N7 Manuel utilisateur

Gemline

Gemline Ace 3952 Manuel utilisateur

Focal

Focal ON WALL 300 Mode d’emploi

HEADRUSH

HEADRUSH Maximus HRSP 5024 Manuel utilisateur

SoundLogic

SoundLogic BCCS-6/6395 Manuel utilisateur

Peavey

Peavey DTH 218 Manuel utilisateur

Avantree

Avantree Pluto Air Manuel utilisateur

Morel

Morel Integra Series INTEGRA OVATION 4 Manuel utilisateur

Oppo

Oppo SONICA Manuel utilisateur

Bose

Bose SoundLink Wireless Music System Manuel utilisateur

Rocksteady

Rocksteady Stadium Manuel utilisateur

Bowers & Wilkins

Bowers & Wilkins 4 Manuel utilisateur

Sonance

Sonance SONOS OUTDOOR Series Manuel utilisateur

Electro-Voice

Electro-Voice EVID FM4.2 Manuel utilisateur

Pioneer

Pioneer XW-HTD630 Manuel utilisateur

Onn

Onn BWA16AA002 Manuel utilisateur

HP GL313AA - USB Speakers PC Multimedia Manuel utilisateur
