ABOUT YOUR INFINEA® BLUEPAD CHARGING STATION (1-Unit)
ASSEMBLY
Infinea®BluePad
Charging Station
(1-Unit)
QUICK START GUIDE
CHARGE STATUS TROUBLESHOOTING
Cooler Vent
Charging Contacts
Attachment
Mini USB Connector
1. Place the Infinea BluePad Charging
Station on a sturdy, clean and dry surface
in an open, well-ventilated area away
from direct sunlight.
2. Gently insert the USB plug into the USB
port on the charger.
3. Connect the other end of the USB cable
to a PC USB port or USB 5V power
adapter.
4. Insert the Infinea BluePad unit into
a charging bay ensuring the battery
contacts are aligned with the bay’s
contacts. The LED lights up with the
charging status.
LED status indicate the charge status:
STATUS INDICATOR LEDS
Green Inserted device is fully charged.
Orange Inserted device is charging.
No LED No device in charging bay or no
power supply is attached the
charger.
The LED does not light up when the Infinea
BluePad is inserted into the charging station.
• Ensure USB cable is securely inserted into
the USB port on the charging station and
connected to the PC USB or USB 5V power
adapter
• Ensure the unit is seated properly in the
charging bay
It takes an excessive amount of time to fully
charge the battery.
• Verify ambient temperature meets the
operating temperature requirements:
Operating: 0°C – 40°C (32°F – 104°F)
Mini USB Port
Please visit our website at ipcmobile.com,
or contact your Infinite Peripherals account
representative, for additional information about
current and future product accessory oerings.
ACCESSORIES
Mobility Sales/Technical Center
Infinite Peripherals, Inc.
17681 Mitchell N
Irvine, CA 92614
Toll-Free: (866) 278-7860
Oce: (949) 222-0300
Headquarters/Main Warehouse
Innite Peripherals, Inc.
2312 Touhy Ave.
Elk Grove Village, IL 60004
Toll-Free: (800) 278-7860
Oce: (847) 818-1260
Fax: (847) 818-1287
Specications subject to change without notice. Innite Peripherals,
Mobilize Your Enterprise, Linea Pro, Innea, Innea Tab and Innea Omni
are trademarks of Innite Peripherals, Inc. All other trademarks are the
property of their respective owners.
Technical Support
Innite Peripherals, Inc.
17681 Mitchell N
Irvine, CA 92614
Toll-Free: (866) 278-7860
Oce: (949) 222-0300
Email
Website
ipcmobile.com
•
Note: Box contents and part numbers may vary
based on order configuration.
Infinite Peripherals does not warrant, and is
not responsible for, any damage to the Infinea
BluePad Charging Station (“Product”) as a
result of liquid or solid particle intrusion into
the Product or damage caused by dropping
the Product. If a material or workmanship
defect arises with regard to any Infinite
Peripherals product, and a valid claim is
received within the Warranty Period, Infinite
Peripherals at our sole discretion will (1)
repair the Product using new or refurbished
parts or (2) replace the Product with a new
or refurbished Product. For purposes of
this limited warranty, “refurbished” means a
product or part that has been substantially
returned to its original specifications. In the
event of a defect, these are your exclusive
remedies.
QSG-10026 Rev B
WARNINGS & CAUTIONS
Please observe the following precautions:
• Do not immerse the charger in water.
• When not in use, store the charger in a
cool dry place.
• Do not store or operate the charger near a
heat source.
• The charger is information technology
equipment and for oce use only, and
should only be used for its intended
purpose.
ADDITIONAL INFORMATION
Please contact your Infinite Peripherals sales
representative for technical specifications and
additional product documentation.
WARRANTY
PRODUCT RETURNS
Use the link provided to create an account and
gain access to our Knowledge Base and online
support services. Through our online support
center, you’ll be able to download files, open a
Support Ticket, manage your RMAs, view your
account Profile and subscribe to Alerts.
To Request a RMA:
1. Create a user account in the RMA
Support Portal at https://ipcmobile.com/
support/rma/
2. Login to your user account and click
Create RMA Request.
3. Read the instructions provided and
complete the online request form.
4. Note the assigned RMA number and
write it clearly on your shipping carton.
5. Ship your equipment back to us at the
address provided.
