DM9030SA/DM9031A SmartDome™ Dwell Detector

Programming and Installation Instructions

Overview

The DM9030SA/DM9031A SmartDome™ are part of Indyme’s Smart Sense

Solution Suite. Indyme smart devices use custom algorithms and

intelligent sensors to detect activity within the coverage area. The

SmartDome™ uses a Passive Infrared sensor to detect when someone is

dwelling in a coverage area beyond a defined threshold. Once detected,

SmartDome™ can be programmed to activate both local and/or remote

alerts through the Indyme infrastructure. As a member of the Indyme

Global Solutions Family, the DM9030SA/DM9031A can also communicate

with other GSF devices. GSF and Smart devices operate in the 800-900MHz

frequency spectrum. They are not compatible with legacy devices.

SmartDome™ Programming

Indyme Smart devices are programmed using our cloud based Smartportal

Service and the local Indyme infrastructure. Ensure the Indyme control

unit and access point(s) are installed and operational, with full access to

Smartportal before proceeding. Incomplete infrastructure will prevent

programming of any Smart devices.

The DM9030SA is preprogrammed to function directly out of the box. No additional programming is necessary. The

DM9031A device leaves the factory at default settings, these settings will NOT function in a customer environment.

All devices must be properly programmed using the Smartportal website. Smart devices use three primary

programming parameters; Location, Activity Profile and Alert Profile. These parameters will be provided with your

Work Order. Identify the locations and profiles before you begin programming.

•Location –department in the store where the device will be installed.

•Activity Profile –setting used to indicate timing algorithms for activation. (default activity

profile is “Cosmetic”)

•Alert Profile –settings used to activate the local device alert tone and

LED. (default alert profile is “On”)

Using your internet enabled device; cellphone, tablet or laptop, and the

credentials provided on your Work Order, login to the website,

https://smartportal.indyme.com .

Follow the on-screen instructions to configure each DM9031A, one at a time. It

is NOT advisable to have multiple users logged into the same Work Order.

Failure to follow these instructions will result in a failed installation of some or

all devices.

NOTE: The DM9031A devices should be programmed while in the

designated location OR after they are physically mounted.

Activation Button

Technical Document

430758-01

Rev. B

Indyme Solutions, Inc.⬧8295 Aero Place ⬧San Diego, CA 92123 USA +1.858.268.0717 ⬧+1.800.829.6141 Page 2of 6

1. On the Installer Registration screen, enter your name and contact information. This information will be used by

Indyme Support personnel throughout the install and to ensure you are at the correct job site.

2. On the Work Order screen, verify the listed details match your present job site and, the list of devices match your

inventory of products. Once all details are confirmed, select the “Start Work” button and begin your installation.

3. With the Devices screen showing, insert two size “C” Alkaline batteries into the DM9031A (should be included in

the DM9031A box). The device will power up and produce a VERY LOUD “chime” tone and the LEDs will flash. The

unit will associate with the local Indyme infrastructure, (access point and control unit), and its unique-id will

appear highlighted in green on the webpage. Verify the unique-id that appears matches the sticker inside the

DM9031A.

4. Select the highlighted device, (DM9031A). In the Device Details screen, select the Location where the device

will be installed. The Activity Profile and Alert Profile will automatically be filled in. Do not change these

values.

5. Select the “Add Picture” button and take a picture of the device properly mounted.

6. Select the “Save” button.

6a. (After the Save button), A “Sending Changes” pop up will appear. This will transfer the Device’s data to

the control unit.

6b. The “Ready for Activation” pop up appears directing the user to press the button to activate changes.

6c. Push the activation button as indicated. When the transaction is complete, another pop up will appear –

“Your changes have been saved. Return to devices list?”. Select Yes

6d. Repeat until all DM9031A devices are properly programmed.

7. Once all devices have been programmed, return to the Work Order screen. Verify the number of Completed

devices. Select the “Stop Work” button and close the work order.

8. Call Indyme to verify the devices are correctly configured and working.

NOTE: The DM9031A devices should be programmed while in the designated location OR after they are physically

mounted.

SmartDome™ Installation

The DM9030SA/DM9031A SmartDome™ are designed as ceiling mounted devices. They may be mounted directly

to a drop-tile ceiling grid, extended from the grid using a telescoping pole or extended from a ceiling truss.

Mounting hardware is available for all options. For ceiling heights of 11-feet or less, the should be direct mounted,

heights of 12-feet or greater should use the telescoping pole.

Required Tools

The following tools are recommended to complete the installation according to these instructions;

(1) 1/4” or 1/2” socket wrench handle, (1) 9/16” socket, (1) 7/16” deep socket, (1) 3/16” Allen wrench, (1) pair

pliers, (1) Philips screwdriver.

Technical Document

430758-01

Rev. B

Indyme Solutions, Inc.⬧8295 Aero Place ⬧San Diego, CA 92123 USA +1.858.268.0717 ⬧+1.800.829.6141 Page 3of 6

DM9030SA/DM9031A SmartDome Mounting

Direct Ceiling Mount

1. Identify all necessary mounting hardware.

•(A) Dome Assembly

•(B) Dome Mounting Plate

•(C) Grid Mounting Clip w/hardware

2. Attach the Grid Mounting Clip-(C), to the ceiling frame in the target area. Squeeze the clip to lock it in place.

(Fig-1)

3. Attach the Dome Mounting Plate-(B), to the Grid Mounting Clip-(C), and secure in place with the washer and

7/16” nut. Make sure groove in back of mounting plate (B) aligns with the ceiling grid. (Fig-2)

4. Attach the Dome Assembly-(A) to the Dome Mounting Plate -(B), gently turn clockwise to lock in-place. (Fig-3)

Fig-1

Fig-2

Fig-3

Technical Document

430758-01

Rev. B

Indyme Solutions, Inc.⬧8295 Aero Place ⬧San Diego, CA 92123 USA +1.858.268.0717 ⬧+1.800.829.6141 Page 4of 6

Telescoping Pole Mount

1. Identify additional necessary mounting hardware.

•(D) Pole Pendant Cap & Conduit Connector (white) w/hardware

•(E) Telescoping Pole

•(F) Elbow Joint

•Items (A), (B), (C) above are required.

2. Place the Dome Mounting Plate (B) on top of the Pole Pendant Cap (D). Align the screw holes and secure in

place with the provided screws. Screw the conduit connector to top of pole pendant cap. (Fig-5)

3. Attach the Dome assembly to the attached Pole Pendant and Dome Mounting Plate (B), press in and turn

clockwise to lock in-place. (Fig-6)

Fig-4

Fig-5

Fig-6

Technical Document

430758-01

Rev. B

Indyme Solutions, Inc.⬧8295 Aero Place ⬧San Diego, CA 92123 USA +1.858.268.0717 ⬧+1.800.829.6141 Page 5of 6

4. The Telescoping Pole comes with a 4-1/4” bolt attached at the Elbow Joint. Disassemble the Elbow Joint and

remove the bolt. (3/16” Allen Wrench, 7/16” Socket) (This bolt is ONLY used for mounting to an open ceiling

truss.)

5. Attach the Grid Mounting Clip (C), to the ceiling in the target area. Squeeze the clip to lock it in place. (Fig-1)

Attach the Elbow Joint (F) to the Grid Mounting Clip using the provided small washer and 7/16” nut. (Fig-7)

6. Re-attach the pole (E) to the Elbow Joint insuring the pole is straight up and down. Feed the Safety Cable

around the ceiling tile frame and attach to opposite end of bolt. (Fig-8)

7. Loosen the pole collar (E) and extend to the desired length.

8. Attach the complete Dome Assembly to the end of the Telescoping Pole (E) using the machine screw. DO NOT

align the screw with the hole in the side of the pole. Align the screw so it will tighten against the side of the

pole. (Fig-9)

Fig-7

Fig-8

Fig-9

Technical Document

430758-01

Rev. B

Indyme Solutions, Inc.⬧8295 Aero Place ⬧San Diego, CA 92123 USA +1.858.268.0717 ⬧+1.800.829.6141 Page 6of 6

FCC Notice of Compliance

FCC ID J69SD

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s

authority to operate the equipment.

The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all

persons and must not be co-located or operating in conjunction with any other antenna or transmitter.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of

the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

Industry Canada Notice of Compliance

IC: 1809A-SD

This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two

conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including

interference that may cause undesired operation of the device.

Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s

authority to operate the equipment.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radioexempts de licence.

L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2)

l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en

compromettre le fonctionnement.

Les changements ou modifications non approuvés expressément par la partie responsable de la conformité pourrait

annuler l'autorité de l'utilisateur à faire fonctionner l'équipement.

Innovation, Science and Economic Development Canada ICES 003 Compliance Label: CAN ICES-3 (B)/NMB-3(B)
