A. Loosening Corroded, Rusted and “Frozen” Nuts and Bolts ≤3/4”
Step 1 Perform the “Preparation for Use” instructions.
Step 2 Push the activation switch to activate the Mini-Ductor® Venom™.
Step 3 Bring the Preformed Coil™ around the frozen nut, initially for only
two seconds, back it away, and try to remove the nut with a wrench or socket.
If it is still frozen, apply the Preformed Coil™ for another two seconds, and
then try the wrench again. There is usually no reason to heat a nut to a red-hot
condition in order to free it from the corrosion holding it to the bolt.
VI. USING THE U-FORM COIL™
Function: The U-Form Coil (7) can be shaped to perform any of the previous coils jobs, custom part removal, and
Hail/Soft dent removal.
A. Loosening Corroded, Rusted and “Frozen” Nuts and Bolts >3/4”
Step 1 Perform the “Preparation for Use” instructions.
Step 2 Configure the coil to the size nut by wrapping it around a socket piece for that nut.
Tip: The more coil winds you can get the faster it will heat.
Step 3 Insert both ends of the U-Form coil into the electrodes and tighten Twist-Lock™.
Step 4 Bring the U-form™ Coil around the frozen nut, initially for only two seconds, back
it away, and try to remove the nut with a wrench or socket. If it is still frozen, apply the U-
Form Coil™ for another two seconds, and then try the wrench again. There is usually no
reason to heat a nut to a red-hot condition in order to free it from the corrosion holding it to
the bolt.
B. Heat Shrinking Hail / Soft Dents in Sheet Metal
Step 1 Perform the “Preparation for Use” instructions.
Step 2 Configure the Coil to look like the diagram on the right.
Step 3 Holding the U-form coil ½to 1 inch above a dent, move it in a
small circular motion and gradually bring it closer to the dent, but
keeping it around the outside of the crown of the dent. As soon as the dent
shrinks, back the U-Form Coil away quickly and cool the treated dent
with a damp rag. If the dent sucks in you are heating the crown or not
far enough around the outside of the crown. Repeat the procedure until removed
completely.
Tip: Once a puff of smoke releases from the dent
immediately remove the U-Form Coil from the
area. This is the point at which the paint will start to
bubble. Also be careful on white and light
colored finishes, these lighter paints tend to yellow
sooner than darker colors.
