Inaxsys IN-DO2MIRVSLL Manuel utilisateur

Outdoor Dome

Flat Surfaced Ceiling Mounted

Exterior Dome (Face Down)

Installation Guide

For Models:

IN-DO2MIRVSLL, IN-DO4MF, IN-DO4M36A, IN-DO1MIRF, IN-DO2MIRF,

IN-DO3MIRF, IN-DO5MIRF, IN-DO1MIRV, IN-DO2MIRV, IN-DO3MIRV &

IN-DO5MIRV

Installation Guide

8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com

Table of Contents

Installation Procedures .....................................................3

Step 1: Drill the Holes................................................................................ 3

Step 2: Open the Dome Cover.................................................................. 4

Step 3: Prepare for Waterproof Installation............................................. 5

Waterproof Solution with Naked Cable................................................... 6

Waterproof Solution with Conduit............................................................ 8

Step 4: Install the Camera to the Ceiling ............................................... 12

Step 5: Connect the Cable(s).................................................................. 13

Step 6: Access the Camera Live View.................................................... 14

Step 7: Adjust the Viewing Angle and Focus ........................................ 14

Step 8: Close the Dome Cover................................................................ 15

Appendices.......................................................................16

Accessing the Camera Live View........................................................... 16

Focus and Viewing Angle Adjustments................................................. 24

Safety Information............................................................30

Installation Guide

8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com

Installation Procedures

Step 1: Drill the Holes

1. Using the supplied drill template, mark the screw holes location on the ceiling, then drill the holes

and insert the plastic plugs.

2. Determine how the cables will be routed: pass through the ceiling or along the ceiling.

If the cables will pass through the ceiling:

a. Mark and drill the conduit hole location on the ceiling as shown on the drill template.

b. Remove the metal cap covering the bottom conduit hole of the camera, and attach

the cap to the side conduit hole to close it. Route the network cable to pass this hole

from the ceiling.

If the cables will be routed along the ceiling, skip to the next step.

Installation Guide

8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com

Step 2: Open the Dome Cover

1. Remove the plastic covering the camera.

2. Loosen the three (3) screws securing the dome cover.

3. Carefully lift to open the dome cover and place it on the side of the camera.

NOTE: Do not abruptly lift the dome cover; it is attached to the camera with a spring wire.

Installation Guide

8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com

Step 3: Prepare for Waterproof Installation

The camera comes with two (2) glands used for waterproof installation:

Cable Gland: For use with an Exterior-grade Ethernet cable. Exterior-grade Ethernet

cables are already waterproof. Waterproof Solution with Naked Cable on page 6.

Conduit Gland: For use with a flexible conduit. This solution is recommended when an

exterior-grade Ethernet cable is not available or when other input/output devices or external

power adapter will be connected to the camera (select models only). See Waterproof

Solution with Conduit on page 8.

Determine the type of waterproof solution that is applicable to your installation requirements and

prepare the necessary accessories or purchase extra materials.

Cable Gland

Conduit Gland

For use with an Exterior-grade Ethernet

cable (not included in the package).

For use with a 3/8” flexible conduit (not

included in the package).

For use with 1/2” flexible conduit (not

included in the package)

NOTE: The bundled conduit gland may vary.

Check the conduit gland that came with your

package to determine if 3/8” or 1/2" is the

suitable flexible conduit size.

Installation Guide

8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com

Waterproof Solution with Naked Cable

This section describes the procedures in using the bundled cable gland and an exterior-grade

Ethernet cable.

1. Disassemble the cable gland as shown below:

2. Insert the clamping nut into the Ethernet cable.

3. Insert the sealing insert with claw.

Body

(with Washer)

Sealing Insert

with Claw

Clamping

Nut

Installation Guide

8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com

4. Attach the cable gland body to the hole of the camera.

Attach to Camera Side Hole Attach to Camera Bottom Hole

5. If the cable will be routed along the surface, skip this step.

If the cable will pass through the surface, do the following:

a. Pull the network cable through the bottom conduit hole.

b. Insert the sealing insert with claw into the cable gland body and then attach the clamping nut

to complete the cable solution.

NOTE: Make sure the clamping nut is tightly attached to the cable gland body and the sealing

insert is squeezed tightly.

6. Proceed with Step 4: Install the Camera to the Ceiling on page 12.

Installation Guide

8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com

Waterproof Solution with Conduit

This section describes the procedures to waterproof the cabling connections using the bundled

conduit gland and flexible conduit. This is the recommended when an exterior-grade Ethernet cable

is not available or if other input/output devices or an external power adapter will be connected to the

camera (select models only).

1. Prepare the following materials for waterproof installation:

Conduit Gland

(included in the camera package)

For use with 3/8” flexible conduit

For use with 1/2” flexible conduit

Flexible Conduit

3/8” or 1/2" Trade size

(not included in the package)

Network Cable

CAT 5 or CAT 6

(not included in the package)

NOTE: The bundled conduit gland may vary.

Check the conduit gland that came with your

package to determine if 3/8” or 1/2" is the

suitable flexible conduit size.

2. Disassemble the bundled conduit gland as shown below:

Installation Guide

8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com

NOTE: In this installation, the conduit gland body can be securely attached to the camera; therefore

the use of lock nut is not necessary. Please set the lock nut aside.

3. Pull the network cable through the flex conduit.

NOTE: For camera models that support external power adaptor, audio in/out, or digital

input/output (DI/DO) functions, route the cables without connectors through the flex conduit

together with the network cable. The connectors will be attached later after the cables pass

through the conduit hole of the camera.

4. Insert the clamping nut through the flex conduit.

Lock Nut

Body

Sealing Insert

Clamping Nut

Installation Guide

8272 Pascal Gagnon Saint-Leonard, Quebec, Canada H1P 1Y4 www.inaxsys.com

5. Insert the sealing inside and attach it at the end of the flex conduit.

6. Screw the conduit gland body to the conduit hole of the camera.

Attach to Side Conduit Hole Attach to Bottom Conduit Hole

7. If the cable will be routed along the ceiling, skip to step 8.

If the cable will pass through the ceiling, do the following:

a. Pull the network cable and other cables (if any) through the bottom conduit hole.
