Contents

Introduction.................................................................................................................................................... 6

Serial Number Location ............................................................................................................................................................... 6

Instrument Description................................................................................................................................................................ 6

Document Conventions .............................................................................................................................................................. 6

Unpacking and Inspecting ......................................................................................................................................................... 6

Obtaining Repair Service............................................................................................................................................................. 7

Guidelines for Cleaning Returned Equipment .................................................................................................................... 8

Safety .............................................................................................................................................................. 9

Intended Use ................................................................................................................................................................................... 9

Instrument Specications............................................................................................................................ 10

External Power Source Requirements ..................................................................................................................................11

Sensor Specications ................................................................................................................................... 13

Sensor Summary ..........................................................................................................................................................................13

Solutions .........................................................................................................................................................................................14

Potential Interferents..................................................................................................................................................................15

RDO Cap Chemical Incompatibility.......................................................................................................................................15

Conductivity/Temperature Sensor .......................................................................................................................................15

Ammonium, Chloride, and Nitrate Interferent Concentrations..................................................................................16

Required Accessories ................................................................................................................................... 25

Communication Device.............................................................................................................................................................25

Cable.................................................................................................................................................................................................25

Sensors.............................................................................................................................................................................................25

Wireless TROLL Com....................................................................................................................................................................25

Rugged Twist-Lock Cable..........................................................................................................................................................25

Software ..........................................................................................................................................................................................26

Telemetry ........................................................................................................................................................................................26

System Components..................................................................................................................................... 27

Base Unit Components ..............................................................................................................................................................27

Getting Started............................................................................................................................................. 31

Handling pH and Ion-Selective Electrode Sensors (ISEs) .......................................................................... 34

Using the RDO Sensor and RDO Fast Cap ................................................................................................... 34

Ion-Selective Electrode Sensor (ISE) Requirements .................................................................................. 35

Ammonium Sensor Requirements ........................................................................................................................................35

Chloride, Nitrate, and pH/ORP Sensor Requirements.....................................................................................................35

21-970-498-1500 www.in-situ.com

LCD Screen .................................................................................................................................................... 36

Accessing the LCD Menu...........................................................................................................................................................36

Possible Power Statuses.............................................................................................................................................................36

Possible Connected Statuses...................................................................................................................................................36

Possible Port Statuses.................................................................................................................................................................36

Possible Log Statuses..................................................................................................................................................................36

Error Messages..............................................................................................................................................................................37

Starting a Log with the LCD Menu.........................................................................................................................................37

Stopping a Log..............................................................................................................................................................................37

Stopping a Log .............................................................................................................................................................................38

Adjusting the LCD Menu Contrast.........................................................................................................................................38

Setting or Changing Menu Language..................................................................................................................................39

Micro SD Card................................................................................................................................................................................39

Replacing Desiccant ..................................................................................................................................... 40

Calibrating Sensors ...................................................................................................................................... 40

Solution-Based Calibration.......................................................................................................................................................40

RDO 100% Saturation Calibration: Water Saturated Air.................................................................................................41

RDO 100% Saturation Calibration: Saturation Bubbler..................................................................................................41

RDO Salinity Setting....................................................................................................................................................................42

Turbidity Sensor Calibration ....................................................................................................................................................42

Zeroing the Depth Sensor ........................................................................................................................................................43

Calibration Frequency Recommendations.........................................................................................................................45

Batch Calibrating Sensors in VuSitu............................................................................................................ 47

Dierent Sensor Types (Quick Cal Solution).......................................................................................................................47

Multiple Sensors of the Same Type .......................................................................................................................................48

Navigating VuSitu......................................................................................................................................... 49

VuSitu Mobile App.......................................................................................................................................................................49

Connected Instrument Screen................................................................................................................................................49

VuSitu Menu Options .................................................................................................................................................................50

Selecting with Long-press and Swipe ..................................................................................................................................50

HydroVu...........................................................................................................................................................................................51

Live Readings in VuSitu................................................................................................................................ 52

Snapshot Mode.............................................................................................................................................................................52

Live Readings Mode....................................................................................................................................................................52

VuSitu Data ................................................................................................................................................... 53

Downloading Your Data ............................................................................................................................................................53

Sharing Data ..................................................................................................................................................................................53

Viewing Data on a Mac or PC...................................................................................................................................................53

31-970-498-1500 www.in-situ.com

VuSitu Locations........................................................................................................................................... 54

About VuSitu Locations .............................................................................................................................................................54

How to Create a Location..........................................................................................................................................................54

How to Select a Location...........................................................................................................................................................55

How to Edit or Delete a Location............................................................................................................................................55

Logging ......................................................................................................................................................... 56

How to Create a Log with VuSitu............................................................................................................................................56

Remote-Monitoring Conguration (Telemetry) ........................................................................................ 57

Connecting to Win-Situ on a PC................................................................................................................... 59

Connecting to Win-Situ via USB..............................................................................................................................................59

Navigating the Win-Situ Interface............................................................................................................... 60

Home Tab........................................................................................................................................................................................60

Sensor Tab.......................................................................................................................................................................................60

Device Setup Tab..........................................................................................................................................................................61

Logging Tab....................................................................................................................................................................................61

BaroMerge ......................................................................................................................................................................................62

Connecting the Aqua TROLL 600 to a PLC or Data Logger ........................................................................ 66

Conguring SDI-12 Settings........................................................................................................................ 69

About SDI-12 .................................................................................................................................................................................69

Congure SDI-12 Settings in VuSitu......................................................................................................................................69

Modbus PLC Interface .................................................................................................................................. 69

Overview.........................................................................................................................................................................................69

Setting Up Instrument ...............................................................................................................................................................70

Programming the PLC ................................................................................................................................................................70

Reading Parameters....................................................................................................................................................................71

Care and Maintenance ................................................................................................................................. 72

Maintenance Schedule ..............................................................................................................................................................72

User-Serviceable Parts................................................................................................................................................................72

Storage.............................................................................................................................................................................................72

Cleaning the Sonde.....................................................................................................................................................................73

Cleaning and Storing the pH/ORP Sensor ..........................................................................................................................73

Cleaning and Storing the RDO Sensor .................................................................................................................................75

Cleaning and Storing the Conductivity Sensor.................................................................................................................76

Cleaning and Storing the Turbidity Sensor.........................................................................................................................77

More Information ......................................................................................................................................... 78

Declaration of Conformity ........................................................................................................................... 79

Appendix ...................................................................................................................................................... 81

Appendix A: Parameter Discovery .........................................................................................................................................81

41-970-498-1500 www.in-situ.com

Appendix B: Parameter Numbers and Locations..............................................................................................................82

Appendix C: Unit IDs...................................................................................................................................................................85

Appendix D: Register Data Formats ......................................................................................................................................88

51-970-498-1500 www.in-situ.com

Introduction

The instrument serial number is on the product label axed to the instrument body. Serial numbers for

individual sensors are engraved on the sensor body.

Your equipment was carefully inspected before shipping. Check the equipment for any physical damage

sustained during shipment. Notify In-Situ and le a claim with the carrier if there is any such damage; do not

attempt to deploy or operate the instrument.

Throughout this document you will see the following symbols:

Accessories may be shipped separately and should be inspected for physical damage and order fulllment.

A checkmark highlights a tip or feature.

Save packing materials for future storage and shipping of your equipment.

The exclamation point calls your attention to a requirement, safety issue, or important action

that should not be overlooked.

The Aqua TROLL 600 uses the latest sensor and electronics technology to provide laboratory-quality

measurements for eld use. Parameters include water level, pH, dissolved oxygen, and more. The instrument

ts inside wells as small as 2”in diameter. The water level/pressure sensor and barometric pressure sensor

are integrated into the sonde. Additional sensors may be selected and replaced to suit your project’s needs.

An optional motorized sensor wiper may also be included on the instrument.

Use the Aqua TROLL 600 for long-term monitoring in freshwater and marine environments. It’s also ideal for

the following applications:

• Groundwater sampling

• Low-ow testing

• Mine water monitoring

• Stormwater management

The built-in LCD screen displays battery status, connectivity info, and other vital information. Setup is easy

with the VuSitu app and a Bluetooth-enabled mobile device. The Aqua TROLL 600 can record data to an

internal micro SD card and works with telemetry devices for remote monitoring.

Serial Number Location

Instrument Description

Document Conventions

Unpacking and Inspecting

1-970-498-1500 www.in-situ.com

Obtaining Repair Service

If you suspect your system is malfunctioning and repair is needed, you can help assure ecient servicing by

following these guidelines:

1. Call or email In-Situ Technical Support. Have the product model and serial number available.

2. Be prepared to describe the problem, including how the product was used and the conditions

noted at the time of the malfunction.

3. If Technical Support determines that service is needed, they will ask your company to ll out the

RMA form and pre-approve a specied monetary amount for repair charges. When the form and

pre-approval is received, Technical Support will assign an RMA (Return Material Authorization)

number.

4. Clean the product as described in the manual.

5. If the product contains a removable battery, remove and retain it unless you are returning the

system for a refund or Technical Support states otherwise.

6. Carefully pack your product in its original shipping box, if possible.

7. Mark the RMA number clearly on the outside of the box.

8. Send the package, shipping prepaid, to:

In-Situ:

ATTN: Repairs

221 East Lincoln Avenue

Fort Collins, CO 80524

The warranty does not cover damage during transit. In-Situ recommends insurance for all shipments.

Warranty repairs will be shipped back prepaid.

Outside the U.S.

Contact your international In-Situ distributor for repair and service information.

1-970-498-1500 www.in-situ.com

Guidelines for Cleaning Returned Equipment

Please help us protect the health and safety of our employees by cleaning and decontaminating

equipment that has been subjected to potential biological or health hazards, and labeling such equipment.

Unfortunately, we cannot service your equipment without such notication. Please complete and sign the

form (or a similar statement certifying that the equipment has been cleaned and decontaminated) and send

it to us with each instrument.

If an instrument is returned to our Service Center for repair or recalibration without a

statement that it has been cleaned and decontaminated, or if it is the opinion of our Service

Representatives that the equipment presents a potential health or biological hazard, we

reserve the right to withhold service until proper certication is obtained.

1. We recommend cleaning with only mild soaps that are compatible with the product materials.

Wetted materials lists are provided on the product specication sheets. Clean all cables and

remove all foreign matter.

2. Clean the cable connectors with a clean, dry cloth. Do not submerge the connectors.

3. Clean the instrument including the nosecone, cable head, and protective caps.

Decontamination & Cleaning Statement

Company Name Phone

Address

City State

Instrument Type Serial Number

Contaminant(s) if known)

Decontamination procedure(s) used

Cleaning veried by Title

Date



1-970-498-1500 www.in-situ.com

Safety

• Use D-cell alkaline batteries.

• Do not use the Aqua TROLL 600 in any manner not specied by the manufacturer.

• Do not use batteries of dierent ages or types.

• Do not submerge the Twist-Lock connector ends of the cable or instrument when they are not connected.

• Do not submerge the Wireless TROLLCom or your mobile device in liquid.

• Ensure that sensors or sensor plugs, are completely inserted into the ports, so that no liquid can enter the

instrument.

• Ensure that the RDO Sensor Cap is pressed rmly over the sensor lens and is ush with the instrument

before submerging in liquid.

• Replace the cable if insulation or connectors are damaged.

• Make sure the probe and sensor O-rings are clean and free of damage.

Read the safety information on this page before deploying or conguring your Aqua TROLL

600. If you have questions, contact In-Situ Technical Support for assistance.

If the equipment is used in a manner not specied by the manufacturer, the protection

provided by the equipment may be impaired.

Intended Use

The Aqua TROLL 600 multiparameter sonde is designed to be safe:

• during indoor or outdoor use;

• at altitudes above or below 2000m;

• in ambient temperatures from -5 to 50C;

• in any relative humidity levels;

1-970-498-1500 www.in-situ.com

Instrument Specications

Operating temperature

-5 to 50° C (23 to 122° F)

Nitrate and Ammonium Sensors: 0 to 40° C (32 to 104° F)

Chloride Sensors: 0 to 50° C (32 to 122° F)

Storage temperature

Components without uid: -40 to 65° C (-40 to 149° F)

pH/ORP sensors: -5 to 65° C (23 to 149° F)

Nitrate and Ammonium Sensors: 0 to 40° C (32 to 104° F)

Chloride Sensors: 0 to 50° C (32 to 122° F)

Dimensions

4.7 cm (1.85 in.) OD x 60.2 cm (23.7 in.) with restrictor installed

(including connector)

With bail: 73.9 cm (29.1 in.)

Weight 1.45 kg (3.2 lbs) - includes all sensors, batteries, bail

Wetted materials

(sonde and sensors)

Polycarbonate, Acetal, EPDM/Polypropylene TPV, FKM

Fluoroelastomer, Titanium, Flourocarbon Coating, Ceramic, Inconel,

Acrylic Adhesive Film, Nylon, Polyurethane Adhesive, Graphite, PC/

PMMA Blend, Acrylic, Sapphire, PVC, Platinum, Glass

Environment rating IP68 with all sensors and cable attached. IP67 with sensors removed or

cable detached

Max pressure rating Up to 350 PSI

Communication RS485/MODBUS, SDI-12, Bluetooth®

Reading rate 1 reading every 2 seconds for one parameter, no wipe

Internal memory 16 MB

Additional memory, micro SD

card216+ GB included, any size micro SD up to 32 GB accepted

Logging rate 1 minute to 99 hours

Logging modes Linear, Linear Average, Event

Data logging 50 logs (dened, scheduled to run, or stored)

LCD screen Integrated display shows status of sonde, sensor ports, data log,

battery, and connectivity

Internal power

Battery life3

(2) user-replaceable D-cell alkaline batteries

> 6 months typical with wiping

> 9 months typical without wiping

External power voltage4

External power current4

8-36 VDC (required for normal operation)

Sleep:< 0.2 mA typical

Measurement:40 mA typical, 75 mA Max

Cable Vented or non-vented polyurethane or vented Tefzel®

Hex screw driver 0.050 in. (1.3 mm)

1-970-498-1500 www.in-situ.com

Autres manuels pour Aqua TROLL 600

Table des matières

Manuels Moteur populaires d'autres marques

Rotax

Rotax 125 senior MAX evo Manuel utilisateur

Kohler

Kohler K361 Manuel utilisateur

MTD

MTD OHV Series Manuel utilisateur

Kohler

Kohler COMMAND CH18-745 Manuel utilisateur

Mercury

Mercury D4.2L D-Tronic Manuel utilisateur

Selve

Selve SE Plus-RC Series Manuel utilisateur

Perkins

Perkins 1206E-E66TA Manuel utilisateur

Skov

Skov DA 174 Manuel

Rossi

Rossi TX11 Series Manuel utilisateur

Siemens

Siemens SIMOTICS T-1FW3 Feuille d'instructions

AL-KO

AL-KO PRO 350 Manuel utilisateur

MTU

MTU 12 V 4000 Lx4 Manuel utilisateur

Nanni

Nanni N3.30 Manuel d'instructions

Nanni

Nanni N5.160 CR2 Manuel utilisateur

KSB

KSB SuPreme Series Instructions d'installation

Hiwin

Hiwin EM1 Series Manuel utilisateur

Rotax

Rotax 912 i series Mode d'emploi

Siemens

Siemens SIMOTICS XP 1MB1 Manuel utilisateur
