In Light 2/PORT Manuel utilisateur
OFF ON
SET
2/PORT
In Light In Light
WE L LNE S S S YS T E M S
7
6
5
4
3
2
1
2/PORT
OWNERS INSTRUCTION MANUAL
Please read before using device
In Light In Light In Light
W E L L N E S S S Y S T E M S
Brilliant Light TherapyBrilliant Light Therapy
5601 Midway Park Place NE
Albuquerque, NM 87109
505.404.7130 office
info@ILWSystems.com
ILWSystems.com
Facebook.com/ILWSystems
Pinterest.com/ILWSystems
YouTube.com/ILWSystems
In Light In Light
W E L L N E S S S Y S T E M S
®
In Light Wellness Systems
2®
© 2015 ILWS . All rights reserved.
Micro 2/PORT System Manual 3
In Light
WELLNESS SYSTEMS
7
6
5
4
3
2
1
2/PORT
OFF
ON
SET
Table of Contents
4
5
6
7
9
10
11
12
14
15
16
19
Table of Contents
Welcome / Polychromatic Light Therapy
Pad Systems
Parts Checklist / Product Care
Indications for Use / Considerations
The Micro 2/PORT Controller
Choosing a Setting / Application Guidelines
Caring for your System
Important Notice / Warranty Information
A History with Light
Every step...One Location
Technical Description
Device Description
®
In Light Wellness Systems
4®
© 2015 ILWS . All rights reserved.
Welcome!
Polychromatic Light Therapy
®
Thank you for choosing this In Light Wellness Systems
®
LED light therapy device. ILWS products are engineered
for safe, non-invasive, and effective use in clinical and
home environments. Thousands of families are currently
enjoying the benefits of light therapy.
Medical health providers use light therapy in clinical
settings to increase circulation, reduce pain and, as
research evidence demonstrates, to promote wound
®
healing. In Light Wellness Systems devices produce a
gentle heat and do not require constant monitoring making
it safe for patient home use.
®
In Light Wellness Systems devices contain visible 440nm
blue diodes, 660nm red diodes, and infrared light diodes
that range from 830nm to 930nm, averaging 880nm,
thereby penetrating at various depths and stimulating
increased circulation through a broad range of tissue types.
ILWS devices are
FDA cleared to:
Increase Circulation
Reduce Pain
Relieve Stiffness
& Muscle Spasms
CLEARED
Polychromatic
Light Therapy
(PLT)
The use of two or
more LED light
wavelengths
(colors) to affect
biologic changes.
Def.
Def.
Pad Systems
®
In Light Wellness Systems
pads are impregnated with Irvisium
superflux diodes designed
specifically and exclusively for our
products. The circuitry architecture
embedded in the neoprene allows for
pliability and comfortable application
of the pads to any body part. This
contoured application increases the
skin absorption of the therapeutic
light and enhances the benefits of
each treatment session. The entire
®
range of In Light Wellness Systems
neoprene pads can be used
interchangeably with any
of our controller devices.
neoprene
LOCAL/132LOCAL/132
FACEMASK/104FACEMASK/104
SPORT/180SPORT/180
PAINBUSTER/180PAINBUSTER/180
SMALL/50SMALL/50
BOOT/122
(configuration 2)
BOOT/122
(configuration 2)
BOOT/122
(configuration 1)
BOOT/122
(configuration 1)
NOTE:
Controllers like
the 2/PORT
shown to the left
feature multiple
input ports for
up to 2 pads
working
simultaneously.
5
Micro 2/PORT System Manual
This Micro
2/PORT
controller
includes 1
automatic and
7 manual
settings.
Parts Checklist
Caring For Your Accessories
1 Control unit
1 or 2 Therapy pads (system dependent)
1 or 2 Securing straps (system dependent)
1 A/C power supply
1 Carrying case
1 Operator’s Manual, no special skills or training are required
for operation.
• DO NOT operate under water.
• DO NOT expose to moisture for a long period of time.
• DO NOT expose to heat and sub freezing temperatures.
• DO NOT crease or excessively bend cords.
• DO NOT wrap cords around therapy pads.
• When cleaning therapy pads and/or control unit, apply
cleaning solution such as a hospital grade disinfectant (1:10
bleach ratio) to a damp cloth and clean.
Adenosine
Triphosphate
(ATP)
A chemical
molecule produced
by the mitochondria
that supplies the
energy currency
of all life.
Low-level laser
therapy (LLLT)
Light delivered by
both lasers and
light emitting diodes
(LEDs) at low
densities.
Also known as
“cold laser”.
Durable Medical
Equipment (DME)
Medical devices
that act by physical,
mechanical or
thermal means.
6®
In Light Wellness Systems ®
© 2015 ILWS . All rights reserved.
Def.
Def.
Def.
Def.
Def.
Def.
OFF ON
SET
2/PORT
In Light
In Light
WE L LNESS S YSTE M S
7
6
5
4
3
2
1
2/PORT
OWNERS INSTRUCTION MANUAL
Please read before using device
In Light In Light In Light
W E L L N E S S S Y S T E M S
Brilliant Light TherapyBrilliant Light Therapy
OR OR
Indications For Use
Contraindications
Precautions
Electrical
Considerations
1) To provide LED (light-emitting diode) light-associated
gentle warmth (limited temperature elevation) therapy to
temporarily relieve minor pain, stiffness and muscle
spasms; and
2) To temporarily increase the local blood circulation of
body parts.
• Do not use this device directly over the abdominal area
while pregnant.
• Do not use this device directly over an area of known
cancer.
• Avoid use over topical creams/gels.
• Consult medical professional should skin irritation occur.
• Use only with a
building code
approved grounded
outlet.
7
Frequency
The rate at which
photon energy
(information) is
delivered. (e.g.
duty cycle, pulsed
rate). Cellular
and DNA
communication can
be measured in
frequencies.
Joules (j)
A measurement of
energy transfer
Laser Therapy
High-density light
devices used for
ablation, cutting
and thermal
coagulation of
tissue
Def.
Def.
Def.
Def.
Def.
Def.
Micro 2/PORT System Manual
• Do not use with an electric generator. Only use power
supply and cord sent by ILWS with any In Light Wellness
®
System product.
• Do not use pins or metallic materials to hold pads in
place.
• Do not use in water or while wet.
• When powering unit down, depress the “off” push button
so that power is no longer being applied to the LEDs. If
disconnecting the power cables, ensure the previous
steps have been followed. When disconnecting the
power connections, always pull plug from the connection.
• Do not apply therapy pads to skin with excessive
pressure. Light arrays should be in light contact with
clean skin surface.
• Do not apply treatment to an area for more than 20
minutes in a 5-hour period. Do not exceed 60 minutes of
treatment to an area in a 24-hour period.
Other Considerations
NOTE:
Please note every
other row of LEDs
are infrared and
cannot be seen
with the human
eye. If the red
LEDs are
illuminated, the
infrared LEDs will
also be powered
but you will not be
able to see them.
8®
In Light Wellness Systems ®
© 2015 ILWS . All rights reserved.
The MICRO 2/PORT Controller
Operation Modes
®
The ILWS MICRO
2/PORT Controller has
3 user buttons:
SET - changes
program settings
ON - turns unit on
OFF - turns unit off
OFFOFF
ONON
SETSET
9
Near infrared
light (NIR)
Refers to the use
of infrared light
applied directly to
living tissue
Nitric Oxide (NO)
A chemical
molecule released
from smooth
muscle when
triggered by
the body’s
parasympathetic
response and/or
polychromatic
light therapy
Wavelength
The length in
nanometers of
each color on the
visible and
invisible light
spectrum
Def.
Def.
Def.
Def.
Def.
Def.
2/PORT
Device Set-Up
& Operation
• Insert the power cable into
110-volt power outlet.
• Insert power supply jack
into the In Light Wellness
®
Systems controller power
jack (see picture below).
• Connect the pad(s) to the
controller at the top of the
unit using any or all DIN
sockets as pictured below.
• Place the pad(s) with the
LED side of light array on
the treatment area.
• Press the ON button to
initiate treatment.
Micro 2/PORT System Manual
Choose a Setting
Suggested Application Guidelines
(see ‘Caring For Your Accessories’)
To use a different automatic or manual mode, press the
SET button until the desired LED indicator is illuminated.
The unit will operate on that setting until it powers off. The
unit will switch off automatically after 20 minutes in any
mode.
The standard treatment protocol for In Light Wellness
®
System treatment is twice a day for 20 minutes per
session as follows:
Apply the neoprene pad directly to the skin near or on
the affected area.
Place the pad in a clear plastic bag if bodily fluids are
present.
Turn the device “ON” and allow the unit to commence in
the automated mode for 20 minutes.
Do not apply treatment to an area for more than 20-
minutes in a 5-hour period.
Do not exceed 60 minutes of treatment to an area in a
24-hour period.
NOTE:
Be aware lying
directly on the
pad(s) results in
the lack of airflow
and may result in
elevated warmth
in the area.
10 ®
In Light Wellness Systems ®
© 2015 ILWS . All rights reserved.
