INSTALLATION INFORMATION
Accessories
Find the following when unpacking the Antenna Reader:
XTT901 to XTT904 and XTT907
Either an ImproX MMA Antenna Reader (XTT901-1-0-GB-XX) housed in a Dark
Grey, ABS Plastic housing. The ImproX MMA consists of a Front Cover and a
Backing Plate. The Front Cover (including the potted electronic components)
assembly includes 8 m (26 ft) of 4-core, 0.5 mm solid strand Communications
Cable.
Or an ImproX MA Antenna Reader (XTT902-1-0-GB-XX) housed in a Dark Grey,
ABS Plastic housing. The ImproX MA consists of a Front Cover and a Backing
Plate (the Backing Plate is attached with a Self-tapping Screw (M2 x 6 mm)).
Or an ImproX MHA Antenna Reader (XTT903-1-0-GB-XX) housed in a Zinc alloy
die-cast housing. The ImproX MHA consists of a Front Cover and a Backing Plate
(the Backing Plate is attached with a Hexagonal Screw (M3 x 8 mm)).
Or an ImproX KHA Antenna Reader (XTT904-1-0-GB-XX) housed in a Zinc alloy
die-cast housing. The ImproX KHA consists of a Front Cover and a Backing Plate
(the Backing Plate is attached with a Hexagonal Screw (M3 x 8 mm)).
Or an ImproX KA Antenna Reader XTT907-1-0-GB-XX) housed in a Dark Grey,
ABS Plastic housing. The ImproX KA consists of a Front Cover and a Backing
Plate (the Backing Plate is attached with a Self-tapping Screw (M3 x 8 mm)).
An Allen Key (2 mm) (XTT903-1-0-GB-XX and XTT904-1-0-GB-XX models only).
An extra Hexagonal Screw (M3 x 8 mm) (XTT903-1-0-GB-XX and
XTT904-1-0-GB-XX models only).
An extra Serial Number Label.
XTT905
An ImproX KMA Antenna Reader housed in a Black, ABS Plastic housing. The
ImproX KMA consists of a Front Cover and a Mounting Bracket (the Mounting
Bracket is attached with a Self-tapping Screw (M2 x 6 mm)).
Four Counter-sunk Self-tapping Screws (M2 x 6 mm).
An extra Serial Number Label.
XTT906 and XTT908
Either an ImproX RA Antenna Reader (XTT906-1-0-GB-XX) housed in PVC
sheathing. The ImproX RA includes 8 m (26 ft) of 4-core cable.
Or an ImproX DPA Antenna Reader (XTT908-1-0-GB-XX) housed in a Black, ABS
Plastic housing. The ImproX DPA includes 8 m (26 ft) of 4-core, 0.5 mm Solid
Strand Communications Cable.
A Piezo-electric, External Drive Buzzer.
A bi-colour Red or Green, White Diffused Lens, Hi-bright, 5 mm, 2-Terminal LED
(XTT906-1-0-GB-XX model only).
An extra Serial Number Label.
