Imi Heimeier Wireless Air Sensor Manuel utilisateur

Wireless Air Sensor

Funkbasierter

Lufttemperatursensor

Capteur de température

d’air sans ﬁl

Table of contents/Inhaltsverzeichnis/

Table des matières

Introduction .................................... 4

Installation ...................................... 6

Pairing ............................................ 8

Removing/reset .............................. 9

Replacing the battery...................... 9

Einführung.................................... 10

Installation .................................... 12

Gerät koppeln............................... 14

Entfernen/Zurücksetzen................ 15

Batteriewechsel ............................ 15

Introduction .................................. 16

Installation .................................... 18

Appairage..................................... 20

Suppression/réinitialisation............ 21

Remplacement de la pile .............. 21

Notes/Notizen/Notes .................... 22

Introduction

Various rooms in the home will reach a desired comfortable level more quickly

than others. In most homes a single thermostat senses the temperature in

one room but controls the entire property, leaving certain rooms either to

warm or not warm enough! By installing the ‘IMI Heimeier Wireless air sensors’

throughout the home, you can calculate and average temperature, thus allowing

for better control which can help to play an important part in reducing energy

consumption.

You can also use a ‘Wireless air sensor’ instead of utilising the on board

temperature sensor within the ‘IMI Heimeier thermostat’*. This is ideal when the

thermostat* is not installed in the desired area for measuring temperature.

* Note: The ‘Wireless air sensor’ will only operate with IMI Heimeier compatible

products. Visit www.imi-hydronic.com for more information.

Wireless air sensor

Installation

This sensor is designed to be surface mounted.

1. Using a small coin unscrew the battery cover anti-clockwise to release.

Remove the clear plastic tab and replace the battery cover.

2. Pair the sensor to a IMI Heimeier compatible thermostat by holding down on

the pairing button, (see pairing section for details).

3. Apply the double sided adhesive disc to the back of the sensor.

4. Carefully choose a location that is within signal range.

5. Peel o the second side of the adhesive disc and stick to the desired surface

area.

Recommendation

Locate on to a wall at a height of 1.5 meters, not adjacent or directly above the

heat source, e.g. radiators. Avoid direct sunlight and potential draft areas.

Speciﬁcations

Operating temperature: 0-35°C

Operating voltage: 3V

Pollution degree: Degree 2

1 2

3 4

Pairing

• On the ‘Wireless air sensor’, press and hold the pairing button for 5 seconds.

The LED will glow red to indicate pairing status.

If the sensor has successfully paired to your IMI Heimeier compatible device, the

LED indicator will go out after a few seconds.

If pairing is unsuccessful the LED will remain lit for 60 seconds before going o.

At this point, repeat the previous step and try again.

LED indicator Pair/Reset button

Removing/reset

Replacing the battery

• Press and hold down the pairing/reset button for 15 seconds on the ‘Sensor/

Switch’. LED indicator will ﬂash 3 times to conrm reset.

At this point the ‘Wireless air sensor’ will notify your IMI Heimeier compatible

device that it has left the system, and will automatically be removed from the

‘Accessory menu’.

• Using a small coin turn the battery cover anti-clockwise to release.

• Remove the battery gently, by releasing the top end rst opposite the

‘Retaining Tab’.

• Install new 3V CR2032 Lithium Cell battery positive side up, by inserting one

end behind the ‘Retaining’ Tab, then push down gently until battery clips into

place.

• Re-locate battery cover and turn clockwise to lock.

Retaining

tab

Release battery from the opening

at the top

CAUTION! RISK OF EXPLOSION IF BATTERY

IS REPLACED BY AN INCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING

TO THE INSTRUCTIONS.

Einführung

Manche Räume in der Wohnung erreichen schneller die eingestellte Temperatur

als andere. In vielen Häusern misst ein zentrales Gerät die Temperatur eines

Referenzraumes, und steuert auf dieser Basis das gesamte Haus. Dies kann

in manchen Räumen zur Unter- oder Überversorgung führen. Durch die

Installation der “IMI Heimeier Wireless Air Sensors” im ganzen Haus können

Sie die aktuelle Durchschnittstemperatur ermitteln und so eine genauere

Heizregelung ermöglichen. Das kann einen wichtigen Beitrag zur Senkung ihres

Energieverbrauchs leisten.

Des Weiteren kann ein funkbasierter Lufttemperatursensor zusätzlich zum

IMI Heimeier Thermostat* zur Temperaturermittlung verwenden werden. Dies

ist ideal, wenn der Thermostat* nicht in dem gewünschten Bereich für die

Temperaturmessung installiert ist.

* Hinweis: Der “ Wireless air sensor “ funktioniert nur mit IMI Heimeier

kompatiblen Produkten. Besuchen Sie www.imi-hydronic.com für weitere

Informationen.
