Please read this instruction manual carefully before operating this equipment

Waffle Baker

Instruction Manual

Safety Tips

This instruction manual contains information about the installation, operation and

maintenance of the device and should be consulted as an important source of information

and reference guide.

Awareness of the safety instructions and instructions for use in this manual will ensure the

safe and correct use of the device.

In addition to the information given here, you should comply with any local Health and

safety Controls and generally applicable safety regulations. The instruction manual forms

part of the product and should be kept near the device and easily accessible for anyone

carrying out the installation, servicing, maintenance or cleaning.

Please keep these instructions and give them to future owners of the device.

Safety

This device is designed in accordance with the presently applicable technological

standards. However, the device can pose a danger if handled improperly and

inappropriately.

All persons using the device must follow the recommendations and instructions in this

instruction manual.

Safety instructions

• The device is not intended for use by individuals (including children) with physical or

mental disabilities, insufficient experience, and/or insufficient knowledge unless such

persons are under the care of a person responsible for their safety or have received

instructions regarding appropriate use of the device.

• Children should be observed to ensure that they are not playing with the device.

• Never leave the device unattended when in use. • Only use the device indoors.

• The device is not adapted for use with an external timer or remote control.

• This device may only be operated in technically proper and safe condition.

• Prevent access of children to the package materials like plastic bags and foamed

polystyrene elements. Suffocation hazard!

Read this instruction manual before using and keep them

available at all times!

• Only a qualified technician and using original spare parts and accessories should carry

out repairs and maintenance of the device. Do not attempt to repair the device yourself.

• Do not use any accessory or spare parts that have not been recommended by the

manufacturer. These can be dangerous for the user or lead to damages of the device or

personal injury, and further, the warranty expires.

• To prevent hazards and to ensure optimum efficiency, no modifications or alterations to

the device that are not explicitly approved by the manufacturer may be undertaken.

HOT SURFACE! Burn hazard!

Follow the safety instructions listed in order to avoid the hazard:

• The housing and the grill plates of the appliance become very hot. during operation. Do

not touch them with bare hands. Use always the operating handle in order to open the

device. Use appropriate kitchen utensils for laying and taking of food.

•Also after switching off, the device remains hot for some time. Before cleaning or moving it

to another place wait until the device cools down first.

• Never move this appliance during operation.

WARNING!

Fire or explosion hazard! Follow the safety instructions listed in order to avoid the hazard:

• In order to avoid risk of fire and damage to the device, never place kitchen utensils, towels,

paper and the like on the grill plate during operation.

• Never operate the device near combustible, easily flammable materials (e.g. petrol, spirit,

alcohol etc.). They evaporate through heating and in case of contact with ignition sources

deflagrations can occur which can lead to serious personal injuries and property damages.

• When a fire arises disconnect it from the power supply before you initiate appropriate

measures for fire-fighting. Provide sufficient supply of fresh air.

Caution: Never extinguish the fire with water when the power plug is connected to the

socket. Electric shock hazard!

Warning

Any self-modification, wrong installation, adjustment or maintenance can lead to

property loss or casualty. Please contact the manufacturer for any adjustment or

maintenance, and have the work done by a trained & qualified person.

For your safety sake, please keep the machine away from any liquid, gas or other

object, which is flammable or explosive.

This appliance should not be operated by those who have physiological, perceptual or

mental disabilities or those who have insufficient experience or knowledge (including

children). Only in conditions of being given sufficient supervise & guarantee of personal

safety, as well as proper instructions & guidance, those who were mentioned above

can make some particular operation of this device.

Keep children away from the device.

Preserve this manual safely. When passing on/selling the device to a third party, the

manuals must be handed over along with the device. All users must operate the device

complying with the user’s manual and related safety guidelines.

Keep the mounting position away from flammable and explosive gas, liquid or object.

If the appliance is placed near walls, partitions or kitchen furniture and the like, it is

advisable to make these facilities with non-combustible material, otherwise cover them

with non-combustible heat-resistant material, and pay attention to fire prevention

regulations.

1. Functional Introduction

This product is manufactured by our company, which is combined with advantages from home and

abroad. It is novel in design, reasonable in structure, easy in operation, stainless steel in making,

durable in using and convenient in maintenance. The thermostatic control makes the temperature

adjustable freely in a certain range according to food requirement. Therefore, it is the ideal equipment for

hotel, supermarket, western restaurant, fast-food restaurant and food industry.

2. Structure Schematic Diagram & Working Principle

Structure Schematic Diagram:

2.1Structural & Functional Features

1. Smooth surface treatment, easy to clean, clear and sanitary.

2. Desired temperature can be set according to food requirement.

3. Stainless steel, elegant in appearance.

4. Fast in heating, easy in operation and convenient in maintenance.

Electrical Diagram:

3. Basic Features & Parameters

Name

Model

Voltage

Power

Dimension

1-Plate Waffle Baker

WB-S

220V-240V

1500W

320×325×225mm

4. Precautions & Recommendations

4.1 Transportation and Storage

During transportation, the machine should be carefully handled and do not put it upside

down to prevent from damaging to the shell and inside. The packaged machine should

be stored in a ventilated warehouse without corrosive gas. If it needs to be stored in

open air temporarily, measurement against raining is needed.

4.2 Notice for Installment

1. The supply voltage should correspond with the working voltage of the appliance.

2. There is an earth stud at rear of the furnace body, which should be connected with a

copper wire that no less than 1.5mm2 and ground wire that complying with safety

regulations reliably.

3. Check the connection, voltage and safety grounding after installation.

4. The appliance should be placed in a smooth area and kept a minimum clearance of

10cm away from the incombustible object on both sides and 20cm at the back (e.g.

walls, windows etc.).

5. The fixed arrangement of wire should be equipped with a all-poles disconnecting switch

whose poles have a contact separation at a minimum clearance of 3mm. Grounding

leakage protection switch is recommended. Do not put any sundries in front of the

switch for convenient operation sake.

6. The mounting position should keep away from the flammable and explosive objects.

The ambient temperature should below 45℃and the relative humidity should below

85％.

7. Installation should be operated by professional technician.

4.3 Special Notice

1. This appliance is not applicable for home use.

2. This product is a commercial machine that needs to be operated by trained cook.

3. Do not sway or tilt the machine during operation.

4. Do not dismantle or self-modify the machine.

5. Dismantlement and self-modification may cause casualty.

6. Do not open the casing of the machine.

7. This product contains high-voltage circuit. Casing dismantlement may cause electric

shock.

8. Unplug and cut the power supply off before cleaning.

9. Do not spray water directly onto the product during cleaning.

10.Water may conduct electricity, which may cause electric shock.

11.Do not pat the product or put any heavy objects onto it.

12.Abnormal operation may cause damage and danger.

13.High temperature may cause scald.

14.Do not touch the appliance with hands directly due to high temperature during or after

operation.

15.To prevent from damages, turn the electric switch off as soon as possible when near the

thunder zone.

16.Do not destroy the control panel with hard or sharp objects.

17.Turn the electric switch off when finish working.

18.Maintenance should be operated by qualified technicians.

19.If the power cord is damaged, in case of danger, replacement should be done by

manufacturer or other maintenance departments or professional technicians.

5. Working Instructions & Operation Flow

1. Before using, check that whether the power supply installation is normal and make sure

the power supply voltage corresponds to the working voltage of the appliance.

2. Plug in the power outlet, rotate the temperature controlled knob to adjust the

temperature to reach the desired range the food needs. The indicator is on and the

appliance starts heating.

3. When the temperature reaches 250℃, coat the mould with edible vegetable oil, put the

paste into the mould and cover the lid. When the food is finished, the operator can

make another food. If all the food is finished, please cut off the power supply.

4. Users can set the time according to the difference of prescription of paste and luster of

food customer likes. Generally, the longer the time lasts, the darker the luster will be.

Otherwise, the lighter the luster will be. But the time cannot be too short, or the food will

not be hot and with no luster.

5. Cleaning: Clean the appliance with wet towel containing non-corrosive detergent when

finish working every day. Do not spray it with water directly or dip it in the water to clean,

which may damage electric property and cause electricity safety accident.

6. Routine Inspection

It is necessary to check the machine daily.

Check the machine regularly can avoid serious accident happens.

Stop using if user feels that there are some problems in the circuit or machine.

Check the situation of the machine before or after using every day.

Before using: Whether the machine is tilted?

Whether the control panel is damaged?

Whether the power line is aging, cracking or damaged?

During using: Whether there is strange smell or vibration noise?

Whether the temperature is out of control or any electric leakage?

Whether the power is normal?

7. Cleaning & Maintenance

1．In case of accident, please turn the power supply off before cleaning.

2．Clean the surface and power line with wet towel containing non-corrosive detergent

when finish working every day. Do not spray the appliance with water directly. Water

infiltration may damage electric property and cause electricity safety accident.

3．If not going to use the appliance, please turn off the thermostat and power switch.

4．If not going to use the appliance for a long time, please clean it completely and store it

in a well-ventilated warehouse without corrosive gas.

8. Failure Analysis &Trouble Shooting

Symptoms

Causes

Solutions

The power supply is connected and

the indicator is on, but it does not heat

up.

1．The temperature detect

switch is damaged.

2．One or two of the heating

elements burn out.

1．Replace the temperature

detect switch.

2．Replace the burnt-out

heating element.

The power supply is connected and

the indicator is on, but the temperature

keeps rising and out of control.

1. The temperature detect

switch is damaged.

1. Replace the temperature

detect switch.

The power supply is connected and

heating is normal, but the indicator is

off.

1. The indicator is

damaged.

1. Replace the indicator.

Connect the power supply, it does not

heat up and the indicator is off.

1. The power supply is

abnormal or

disconnected.

1. Check the power supply.

Aforementioned troubles are just for reference. If any failure occurs, please stop

using and inform professional technicians to check and repair.

9.Waste disposal

Discarding old devices

At the end of its service life the discarded device has to be disposed in accordance with the

national regulations. It is advisable to contact a company which is specialized in waste

disposal, or just contact the local disposal service in your community.

WARNING!

To exclude any abuse and the dangers involved make the waste device unfit for use before

disposal. For that purpose disconnect device from mains supply and remove mains

connection cable from the device.

CAUTION!

For the disposal of the device please consider and act according to the national and local

rules and regulations.

10.WARRANTY

iMettos warrants to the original purchaser of every new product, under normal and proper

use and maintenance service as specified by iMettos and upon proper installation and

start-up in accordance with the instruction packet supplied with each unit. iMettos’

obligation under this warranty is limited to a period of two (2) year from the date of original

installation.

WARRANTY CLAIMS

All claims for parts must be made directly through iMettos.All claims should include:

Personal Details: Products Details:

Your name: Model number:

Your company: Serial number of the product:

Address: Date of purchase:

Email: Proof of purchase :

Phone:

Pertinent information supporting the existence of the alleged defect.(Such as picture etc.)

Please send the above information to [email protected]

Our warranty departments will according to the actual situation and reply you within

24hours.

Table des matières

Autres manuels iMettos Gaufrier

iMettos

iMettos WB-03D Manuel utilisateur

Manuels Gaufrier populaires d'autres marques

Kenwood

Kenwood PG-2000 Manuel utilisateur

BRAYER

BRAYER BR2300 Manuel utilisateur

Ricardo

Ricardo Mini Waffle Maker Guide d'installation

KYOWA

KYOWA KW-2616 Manuel utilisateur

Herenthal

Herenthal EWM-1200 Manuel utilisateur

MPM

MPM MGO-30M Manuel utilisateur

Nostalgia

Nostalgia MyMini MWF5AQ Guide rapide

SEVERIN

SEVERIN WA 2101 - Guide de l'utilisateur

Trebs

Trebs Comfortbakery 99255 Manuel utilisateur

Black & Decker

Black & Decker WMB505C Manuel utilisateur

Wilfa

Wilfa WM-623BELL Manuel utilisateur

Cuisinart

Cuisinart WAF-350C Series Manuel d'exploitation

SEVERIN

SEVERIN WA 2110 Guide de l'utilisateur

Villaware

Villaware UNO 2000 Manuel

Unold

Unold 48266 Manuel utilisateur

Royal Catering

Royal Catering RCWM-1400-B Manuel utilisateur

Curtis Stone

Curtis Stone CSWB100 Manuel utilisateur

Trebs

Trebs Comfortbakery 99257 Manuel utilisateur

iMettos WB-S Manuel utilisateur

Manuels Gaufrier populaires d'autres marques
