IME-DC IDia Manuel utilisateur

TABLE OF CONTENTS

NO CODING

USER GUIDE

BLOOD GLUCOSE MONITORING SYSTEM

TABLE OF CONTENTS

INTRODUCTION��5

DESCRIPTION OF SYSTEM COMPONENTS ��7

■User interface

■Light button and data port

■Battery compartment

■Test strip

CONFIGURATION ��11

■ Conguration

■Date and time

■Test reminder

SYMBOL DEFINITIONS��17

■‘Insert test strip’ notication

■Blood sampling notication

■Measurement period

■Test result

■Measurement unit

■‘HI’ notication

■‘LO’ notication

■Memory display

■Test reminder

■Ketone notication

ERROR DEFINITIONS AND RECTIFICATION ��22

AVERAGE MEASUREMENT CALCULATION��24

CONTROL SOLUTION ��26

■Using the control solution

■Testing with the control solution

TABLE OF CONTENTS

4 5

INTRODUCTION

Thank you for your trust!

You have chosen the iDia blood glucose monitoring system, which

can be used together with iDia test strips and related accessories

to easily and conveniently measure your blood glucose levels.

The measurement range of the iDia blood glucose monitoring sys-

tem is between 10 –600 mg/dL or 0.6 –33.3 mmol/L.

Please ask your specialist physician which unit of measurement

you should use for your therapy.

In order to obtain an accurate blood glucose measurement, you

must follow certain important guidelines.

Therefore, please read this user guide carefully before using the

device for the rst time.

You will be amazed at how easy it is to take measurements!

TABLE OF CONTENTS

LANCING DEVICE��30

BLOOD LANCET ��31

USING THE LANCING DEVICE��32

ALTERNATIVE BODY AREAS SUITABLE FOR BLOOD SAMPLING ��34

DETERMINATION OF BLOOD GLUCOSE LEVEL��37

BLOOD GLUCOSE VALUES FOR ADULTS ��39

SYMPTOMS OF LOW BLOOD SUGAR��40

SYMPTOMS OF HIGH BLOOD SUGAR��41

POTENTIAL INFLUENCES ON THE MEASUREMENT READINGS��42

TECHNICAL SPECIFICATIONS – BLOOD GLUCOSE MONITORING

SYSTEM ��45

TECHNICAL SPECIFICATIONS – TEST STRIPS ��46

DATA TRANSFER ��47

LIST OF ITEMS | QUALITY STANDARDS��48

CLEANING AND MAINTENANCE ��49

BATTERY REPLACEMENT��50

WARRANTY ��52

EXPLANATION OF SYMBOLS��53

SAFETY AND DISPOSAL ��54

■Blood glucose monitoring system

■Used test strips, lancets and alcohol swabs

■Battery

6 7

INTRODUCTION

Before taking your rst measurement, please take note of the

following important information.

■The iDia blood glucose monitoring system is an in vitro diagnos-

tic tool that is suitable for self-testing. It enables people with

diabetes and specialist medical sta to determine blood glucose

values.

■The iDia blood glucose monitoring system is suitable for analys-

ing fresh capillary blood, venous blood, arterial blood or neonatal

blood.

■Only use iDia test strips and iDia control solutions. Using other

test strips can lead to incorrect readings.

■Close the storage container immediately aer removing the test

strip(s).

■Check the expiry dates of the test strips and control solution.

■Use a new lancet for each blood sample.

■Always store the measuring device or test strips according to the

storage requirements, and protect both from moisture, direct sun-

light and other heat sources.

■Keep the measuring device and all accessories away from chil-

dren.

■Clean your iDia blood glucose monitoring system regularly.

■The functioning of the iDia blood glucose monitoring system

can only be guaranteed if it is used correctly and for its intended

purpose.

■Blood glucose monitoring systems must not be used for diabetes

diagnosis.

Test strip slot

Main button

Display

DESCRIPTION OF SYSTEM COMPONENTS

USER INTERFACE

8 9

Data port

Light button

Pressing the light button when the blood glucose monitoring

system is switched on will activate the display's blue background

lighting. This makes it possible to take and read measurements

correctly even in low light conditions.

Battery

Set button

DESCRIPTION OF SYSTEM COMPONENTS DESCRIPTION OF SYSTEM COMPONENTS

LIGHT BUTTON AND DATA PORT BATTERY COMPARTMENT

10 11

TEST STRIPS CONFIGURATION

Application area

Touch the drop of blood with the appli-

cation area. The blood will be absorbed

automatically.

Measurement contacts

Insert the test strip into the test strip slot,

with the measurement contacts rst.

Test area

This area must be completely lled with

the blood sample.

MEASUREMENT FIELD

NOTE

You can touch the measurement eld of the iDia test strips freely

with clean, dry hands. The test result will not be aected.

Set button

First remove the battery cover and check that the required 3 V lith-

ium batteries (type CR 2032) have been inserted. If this is not the

case, you will need new batteries (see page 50).

Then set the current date and correct time. To do this, press the set

button (using a pen, for example), and then press the main button

(this changes the ashing value on the display).

NOTE

Please be prepared for necessary battery changes by keeping two

spare batteries with you (Type CR 2032).

CONFIGURATIONDESCRIPTION OF SYSTEM COMPONENTS

12 13

DATE AND TIME

NOTE

The gures needing adjustment ash on and o (shown in white in

the illustrations).

1Set button pressed once: The blood glucose meter switches

itself on. ‘Year’ setting

2Set button pressed second time: ‘Month’ setting

3Set button pressed third time: ‘Day’ setting

4Set button pressed fourth time: ‘Hour’ setting

5Set button pressed h time: ‘Minute’ setting

123

TEST REMINDER

6–10 Set button pressed sixth to tenth times:

‘Test reminder’ setting: up to ve dierent test reminder times

can be set (see page 14).

11 Set button pressed eleventh time: The blood glucose meter

switches itself o.

Finally, place the battery cover on the device.

NOTE

If you change settings using the set button and main button, you

will need to go through all of the settings until the blood glucose

678

910

CONFIGURATION CONFIGURATION

14 15

CONFIGURATION CONFIGURATION

meter switches itself o (aer pressing the set button for the last

time).

Your changes will only be saved aer this step.

Your iDia blood glucose monitoring system can issue an alarm tone

ve times a day to remind you to check your blood glucose level.

Aer pressing the set button six times (see page 13) you can set ve

dierent times for test reminders.

The main button can be used to turn the test reminder function

on (12) or o (13).

1312

When the test reminder function is activated, you will be prompted

to enter the rst of your preferred times. Press the set button and

then use the main button to set the desired hour (14) and minute (15),

and conrm by pressing the set button again.

Aer setting the rst test reminder, it is possible to set four further

test reminders.

NOTE

You will be reminded to take your measurement by an alarm tone.

To complete the process, press the main button for 1 second.

1514

16 17

‘INSERT TEST STRIP’ NOTIFICATION

16 Aer the iDia blood glucose monitoring system has been

switched on with the main button, the test strip symbol will

appear in the display. You should now insert the test strip into

the device’s test strip slot. Correct insertion of the test strip will

be conrmed by an audio signal.

BLOOD SAMPLING NOTIFICATION

17 Once the test strip has been inserted into the test strip slot, the

blood intake symbol appears in the display. You now have three

minutes to perform a blood glucose measurement. If no blood

sampling takes place within this time, the iDia blood glucose

meter will switch itself o automatically.

SYMBOL DEFINITIONS SYMBOL DEFINITIONS

16 17 18

MEASUREMENT PERIOD

18 Measurement begins once the test area of the test strip is

suiciently lled with blood, and lasts only 7 seconds. During

the measurement, an hourglass animation is visible on the

display.

18 19

TEST RESULT

7 seconds aer the start of the measurement, the blood glucose

value will be displayed and automatically saved, together with the

date and time (19 and 20).

MEASUREMENT UNIT

This will be displayed together with the measurement reading

(21 and 22).

19 20

21 22

‘HI’ NOTIFICATION

This will appear if the measured blood glucose value exceeds

600 mg/dL or 33.3 mmol/L (23 and 24).

‘LO’ NOTIFICATION

This will appear if the measured blood glucose value is below

10 mg/dL or 0.6 mmol/L (25 and 26).

NOTE

If you receive a ‘HI‘ or ‘LO‘ notication, repeat the measurement

procedure. If the notication appears again, perform a measure-

ment using the control solution (see page 27 onwards) or contact

your specialist physician.

23 24

25 26

SYMBOL DEFINITIONS SYMBOL DEFINITIONS
