IMC Networks MiniMc Manuel utilisateur

MiniMc™is a 10/100 auto-negotiating, miniature

media converter. The fiber port always operates

at 100 Mbps FDX; the copper port auto-senses the

connected device’s speed and duplex mode:

10 Mbps or 100 Mbps and HDX or FDX (including

Flow Control).

feature which

automatically selects between a crossover work-

station or pass-through repeater hub connection

depending on the connected device. also

protects against Broadcast storms, and allows

jumbo packets of up to 1916 bytes.

AutoCross

MiniMc

MiniMc PowerTray/18installs in an IMC Networks

(refer to its hardware manual for installation instruc-

tions) or as a standalone converter. As a standalone,

uses either a universal, external switching

a USB connector to connect to

PC/laptops, self-powered hubs and high-powered

hubs.

MiniMc offers plug-and-play

operation, including the

MiniMc

power cube with 100 - 240 ±10% VAC input and

5V DC output, or

MiniMc

Installation Guide

+5V (±5%)

GRND ØV

The information in this document is subject to change without notice. IMC Networks

assumes no responsibility for any errors that may appear in this document. is a

trademark of IMC Networks. Other brands or product names may be trademarks and are

the property of their respective companies.

MiniMc

Document Number: 55-80632-00 A2 August 2005

NOTE: Use only the supplied IMC Networks power supply or

USB cable with this product. Using a non-IMC Networks

power source will void the warranty. For warranty details and

additional information please visit us online at:

www.imcnetworks.com/warranty.cfm

LED Operation

IMC Networks Technical Support

Specifications

Each includes two LEDs, located on the

RJ-45 connector. LED functions are as follows:

Glows green when a link is

established on the fiber port; blinks green

when activity is detected on the fiber port.

Glows Green when a link is

established on the copper port; blinks green

when activity is detected on the copper port.

Phone:

(949) 465-3000 or (800) 624-1070 (US/Canada)

+32-16-550880 (Europe)

Fax: (949) 465-3020

E-mail: [email protected]

Web: www.imcnetworks.com

MiniMc

FX LNK/ACT:

TX LNK/ACT:

Operating Temperature:

Storage Temperature:

Humidity:

Power Consumption (Typical):

Power:

32° to 122°F (0° to +50°C)

-13° to +158°F (-25° to +70°C)

5% to 90% (non-condensing), 0 – 10,000 ft. altitude

500mA

100/240 ±10% VAC input, 5VDC output
