Iluminar ILi3 Manuel utilisateur

USER

MANUAL

iLi3 MODEL 240W

1-877-540-5588

iluminarlighting.com

[email protected]

IL-i326FSG-120

CONTENTS

• Observe all safety precautions (see page 10), seek the services of a

qualified electrician, installation professional, or call ILUMINAR Lighting

technicians for assistance.

• DO NOT handle or touch the fixture while in use.

• Connect the fixture only to the power sources of the appropriate voltage

using the correct AC plug type. Protect power cables from being pinched,

walked on, or otherwise damaged. Be especially careful where the power

cable enters the power outlet to the unit. Only connect the fixture to an

electrical outlet or extension cord of comparable standard and level

rating. Connect the fixture ONLY to the power sources of the correct

voltage using the plug received.

• The fixture should only be cleaned as directed. Always seek service for

your system by qualified service personnel if any of the following occur:

1. The fixture shows a noticeable change in performance.

2. The power-supply cord or plug is damaged.

3. The fixture has been dropped, or the exterior is damaged.

Please read this manual thoroughly prior to

installing or operating the ILUMINAR iLi3.

Pre-Install Information ........................................

Technical & Physical Specications......................

Hardware & Accessories ....................................

Hanging Installation ...........................................

Wiring Diagram..................................................

Daisy Chain Instructions ......................................

PPFD Map..........................................................

Important Cautions & Warranty ...........................

8 -9

1-877-540-5588

iluminarlighting.com

[email protected]

Subject to change without notice.

TECHNICAL SPECS

iLi3 240W LED SPECTRUM

MOUNTING & COVERAGE

LED Lighting Solution

MODEL:

VOLTAGE:

SKU:

WATTS: 240W

2.6

100-277V

IL-i326FSG-120

PHYSICAL SPECIFICATIONS

VOLTAGE AND AMPERAGE

iluminarlighting.com

Toll Free: 1-877-540-5588

458mm / 18.04”

50mm / 1.97”

1193mm / 46.97”

0.6m / 2’

1.2m / 4’

Minimum

15-30cm /

6-12”

PPF 624 µmol/s

Efficacy 2.6 µmol/J

Min Power Factor 0.9

THD 15%

Crest Factor 0.99

BTU 816

Rated Voltage 120-277V AC

Frequency 50 / 60Hz

Dimmable 0-10V Controllable

Ambient Temperature 0 - 35°C / 32-95°F

Relative Humidity 98%

Color Temperature 4000k

Color Rendering Index 88

Minimum Mounting Height 6”-12” to top of Canopy

Emitter Cooling

Length

120V

Passive / Extruded Case

1193mm

2.11A

46.97”

251W

Light Distribution +/- 5%

Width

208V

120º

458mm

1.2A

18.04”

244W

Waterproof Rating

Height

240V

IP65 for Damp/Wet Conditions

50mm

1.09A

1.97”

241W

LED Lifespan (90% of Life)

Weight

277V

347V

480V

55,000+ hours

6.6kg

0.9A

0.71A

0.51A

14.6lb

240W

245W

239W

WAVELENGTH NM

HARDWARE AND ACCESSORIES

The iLi3 can be hung from rope

ratchets or can be mounted to a

rack.

Before you begin installation,

check that you have all the

necessary parts to begin.

1 iLi3 Fixture

IN THE BOX

Subject to change without notice.

4 Rope Ratchets

1-877-540-5588

iluminarlighting.com

[email protected]

HANGING INSTALLATION

To suspend mount, attach the 4 rope ratchets that come

packaged with this xture to the LED.

Once xture is hanging, connect the power cable (blue tip) from

the outlet to one side of the xture.

Lift the LED and attach the carabiners to pre-installed

hooks from ceiling or mounting beam. The Ratchets should

be installed closest to the LED (and not the ceiling).

A: Remove slack to raise xture.

B: Give slack to lower xture.

WIRING DIAGRAM

A/C INPUT

(to power outlet)

A/C Daisy

Chain Cable

Subject to change without notice.

1-877-540-5588

iluminarlighting.com

[email protected]

DAISY CHAIN CONNECTIONS

A/C INPUT

(to power outlet)

A/C Daisy

Chain Cable

Controller Cable

(to Controller)

Controller

Daisy Chain Cable

If you plan to utilize several LEDs in your room or facility, one of the many benets of

the ILUMINAR LED is that you can “daisy chain” one xture to another to save space

and use only one outlet to run several lamps, thus minimizing the amount of cords

used in your space.

If you plan to utilize the ILUMINAR HASH Controller, connect the connections from

the controller to the xture and then connect the Daisy Chain Controller Cable from

xture to xture. Please consult with our lighting layout designers to ensure proper

spacing of outlets for your unique setup.

1-877-540-5588

iluminarlighting.com

[email protected]

Clearance

Qty

Average PPFD

Max PPFD

Min PPFD

Median PPFD

Min/Average

Watts

Clearance

Qty

Average PPFD

Max PPFD

Min PPFD

Median PPFD

Min/Average

Watts

Clearance

Qty

Average PPFD

Max PPFD

Min PPFD

Median PPFD

Min/Average

Watts

0.5

378.69

934

265.5

6.34

253

315.45

641

268.5

22.82

253

1.5

255.44

446

237.5

37.19

253

μmol/m2/s

PPFD MAP iLi3 at 0.5ft

PPFD MAP iLi3 at 1ft

PPFD MAP iLi3 at 1.5ft

DAISY CHAIN SPECIFICATION

Subject to change without notice.

>=1000 762-1000 581-762 443-581 338-443 258-338 196-258 150-196 <150

Legend

Clearance

Qty

Average PPFD

Max PPFD

Min PPFD

Median PPFD

Min/Average

Watts

Clearance

Qty

Average PPFD

Max PPFD

Min PPFD

Median PPFD

Min/Average

Watts

Clearance

Qty

Average PPFD

Max PPFD

Min PPFD

Median PPFD

Min/Average

Watts

134.73

180

134.5

64.57

253

92.13

112

74.89

253

24.41

24.5

81.93

253

μmol/m2/s

PPFD MAP iLi3 at 3ft

PPFD MAP iLi3 at 4ft

PPFD MAP iLi3 at 5ft

CAUTION

1. Leave at least one inch of space between the xture and the mounting

area for maximum performance and lifespan.

2. ALWAYS wear protective eye wear when looking directly at the

diodes to prevent eye damage.

3. Only handle, clean or move xture when it’s unplugged and

completely cool.

4. Keep the xture free of dust, debris, deposits to ensure the maximum

potential of the xture.

5. NEVER use cloth to clean the diodes. This will scratch the diodes and

could potentially break or dislodge them.

6. DO NOT use chemicals to clean the xture. Use ONLY low pressure

air or low pressure water to remove dust and debris.

7. Do NOT use sulfur vaporizers.

At ILUMINAR, we stand behind our products and our

technology as well as our customers. All ILUMINAR xtures

are backed by our 5-Year Guarantee. Please visit our

website iluminarlighting.com/warranty for more information.

1-877-540-5588

iluminarlighting.com

[email protected]

GUARANTEE

Please read the following list carefully prior to beginning installation.
