Closed combustion system
When located in highly insulated houses, the combustion air is supplied through the bottom
rear of the stove, which is connected to a Ø100mm ventilation pipe
The installation must have a maximum length of 6m and a consist of maximum 3 bends as
well as a single inlet grate, the total counter pressure must not exceed 2 Pa , at a minimum
chimney draught of 18 Pa, measured at the stoves connection piece
Special weather and geographical conditions mean that the installation must always be
carried out and approved by a ventilation specialist
It is recommended to mount valves, so it is possible to close for the ventilations system If
the stove is not in use in a longer period, these valves can be closed to prevent draft
Chimney & flue connection piece
The chimney must have a minimum draught of 16 Pa measured at the stove´s connection
piece If you are not sure of the stove´s draught a chimney sweep can measure it
The chimney sweep will also ensure that the chimney is airtight, safe and equipped with a
cleanout door If there are any other connections to the chimney, the chimney sweep
should also be asked for advice before installation
Upon delivery, the flue pipe connection piece, which is used to fit the indoor flue pipe, is
located inside the stove, in for transport The connection piece can immediately be
connected to the stove´s top outlet
If a rear connection is required, move the cover plate to the top outlet and the connection
piece from the top to the rear outlet You will find more on this under installation
The local building and housing authorities must always approve the installation
The connection pipe must be manufactured in accordance with EN 1856-2
Remember to always ensure that the seal between the stove and flue connection piece is
intact and airtight
Do not place more than 30 kg on top of the stove/connection piece This can damage the
stove
It is important that the stove, connection pipe and the chimney are situated with enough
space for cleaning sweeping and emptying
