S7P-DK
Quick Start Guide
Saga 7" Super High Bright 3G-SDI/HDMI Touchscreen Monitor
with 3D LUTs and Scopes Deluxe Kit
What’s Included
1 x S7P Monitor
1 x Power Adapter
1 x Shoe Mount
1 x Soft Carry Case
1 x Slim HDMI Cable (Mini to Standard)
1 x Slim HDMI Cable (Micro to Standard)
1 x Slim SDI Cable
2 x IBS-550 Battery
1 x Battery Charger
Getting Started
1. Menu Button - Scroll Wheel
Used to enter and navigate the menu
2. Exit / Back
Used to exit or go back
3. Mute
Toggle sound on and off
4. Source
Switch between SDI and HDMI inputs
1
2 3 4 5 6
10
14 14
5
11
12
13
7
8
9
1920 x 1200
7 in.
2000 NITS
5. 1/4”-20 Threaded Mounting Points
6. Power Button
Hold 3 seconds to turn on/off
7. DC 7-24V Power Terminal
8. SDI Input Terminal
9. SDI Output Terminal
10. SD Card Slot
Used to load LUTs
11. 3.5mm Headphone Output
12. HDMI Input Terminal
13. HDMI Output Terminal
14. L Series Battery Slots
Option to use 1 or 2 DV batteries
Assist Menu Dropdown
Configuration of Menu Settings
Assist
Monochrome
False Color
Peak Color
Timecode
Zebra
Mute
Nine Grid
Mark
Image Setting
Color Setting
Signal Analysis
System
Monochrome — Toggle between off, gray, red, green, and blue
Peak Color — Activate peaking in select color
Zebra — Use 75IRE or 100IRE to check exposure
Mute — Toggle sound on/off
Nine Grid — Zoom in on one of the 9 sections
Timecode — Toggle timecode on/off
False Color — Two types of visual exposure image overlay
off
off
off
off
blue
gray
red
75IRE
type 1
red
green
100IRE
type 2
green
blue
Mark Menu Dropdown
Configuration of Menu Settings
Assist
Mark
Center Mark
Safety Marker
Guide
Guide Back
Marker Color
Grid Line
Image Setting
Color Setting
Signal Analysis
System
Center Mark — Toggle center crosshair on/off
Guide — Apply aspect ratio frame guides
Marker Color — Pick marker line color
Grid — Apply grid lines to assist with composure
Guide Back — Option black out or half tone the areas outside of frame guides
Safety Marker — Select action area and title safe areas displayed
off
gray
off
off
off
16:9
blue
16:9
black
1.85:1
1.85:1
2.35:1
2.35:1
70%
yellow
small
16:10
white
16:10
half tone
80%
red
middle
4:3
black
4:3
90%
green
large
5:4
Image Setting Menu Dropdown
Configuration of Menu Settings
Assist
Mark
Image Setting
Video Aspect
Pixel to Pixel
Zoom
Zoom Times
Flip
Freeze
Battery Level
HDR
Lut
Color Setting
Signal Analysis
System
Video Aspect — Adjust video aspect ratio
Zoom — Select amount to punch in and check focus
Zoom Times — Adjust zoom by percentage
Freeze — Freeze frame
Battery Level — Toggle Battery Level icon on/off
HDR — Preview HLG 2020, HLG 709, or HLG P3
LUT — Toggle 3D LUTs on/off; import 3D LUTs from SD Card
Flip — Flip image
Pixel to Pixel — Toggle on/off
auto
off
off
SLOG2
SLOG3
LOGC
off
5:4
4X
8X
on
16:9
1.4X
HLG 2020
1.85:1 2.35:1 Stretch
5X
9X
auto
16:10
2X
HLG 709
6X
10X
4:3
3X
HLG P3
Import
7X
user
100
Color Setting Menu Dropdown
Configuration of Menu Settings
Assist
Mark
Image Setting
Color Setting
Brightness
Contrast
Saturation
Sharpness
Colortemp
Signal Analysis
System
Brightness
Saturation
Colortemp
Sharpness
Contrast
USER
6500K
9300K
50
50
50
0
Signl Analysis Menu Dropdown
Assist
Mark
Image Setting
Color Setting
Signal Analysis
Wave Display
Wave Full Screen
Audio Meter
H/V Delay
System
Wave Display — Select scopes to display
Audio Meter — Toggle on/off
H/V Delay — Toggle H/V Delay
Wave Full Screen — Toggle full screen waveform
off
off
Y Histogram
Y Parade
H Delay
RGB Histogram
YUV Parade
V Delay
Vector
RGB Parade
H/V Delay
Wave All
Specifications
Supported Video Signals Specifications
Optional Accessories
Some other products that work well with this item available from Ikan include:
MA207
MA211
MA211-R
IBS-750
IBS-970
7 in. Articulating Arm
11 in. Articulating Arm
11 in. Articulating Arm w/ Single Rod Mount
IBS Sony L-Series NP-F750 Compatible Battery
IBS Sony L-Series NP-F970 Compatible Battery
Aspect Ratio 16:10
Battery L Series Battery
Brightness 2000 nits
Contrast Ratio 1100:1
Inputs 1 x HDMI
1 x 3G-SDI
1 x 3.5mm Audio
Outputs 1 x HDMI
1 x 3G-SDI
Resolution 1920 x 1200
UPC Code 847983030736
Viewing Angle 178° (89°/89°)
HDMI 720x480i & 720x480p @ 59.94, 60 Hz
720x576i & 720x576p @ 50 Hz
1280x720p @ 50, 59.94, 60 Hz
1920x1080i @ 50, 59.94, 60 Hz
1920x1080psf @ 24, 25, 29.97, 30 Hz
1920x1080p @ 23.97, 24, 25, 29.94, 30, 50, 59.94, 60 Hz
3840x2160p @ 24, 25, 30 Hz
4096x2160p @ 24 Hz
3G-SDI 720x480i @ 59.94, 60 Hz
720x576i & 720*576p @ 50 Hz
1280x720p @ 50, 60 Hz
1920x1080i @ 50, 59.94, 60 Hz
1920x1080psf @ 24, 25, 29.97, 30 Hz
1920x1080p @ 23.93, 24, 25, 29.97, 30, 50, 59.94, 60 Hz
Learn More
More dynamic information at official website: www.ikancorp.com
Support
CONDITIONS OF WARRANTY SERVICE
• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.
• The components and maintenance service fee will be charged if the warranty period is expired.
Free Service will not be provided in the following situations: (*Even if the product is still within the warranty period.)
• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.
• Damage caused by natural disaster, abnormal voltage, and environmental factors, etc.
©2019 Ikan International. All rights reserved.
