SFB150

Quick Start Guide

Stryder Fanless Bi-Color 150 Watt Fresnel LED

What’s Included

1 x 4” Fresnel Light Fixture

1 x Controller Box w/ V-Mount Plate

1 x Barn Door

1 x Yolk w/ Baby 5/8” Adapter

1 x Power Adapter

www.ikancorp.com | 1.713.272.8822 | [email protected] because we’re ﬁlmmakers too

Getting Started

Thank you for buying the HF150 Fresnel Light from ikan. Please carefully read the instructions and guide before operating the products. The guide includes

product usage and maintenance. When you operate the product, please make sure that you have read the instructions carefully.

All the content of the manual is based on up-to-date information; technical data subject to change without notice.

Structure

Overview

Absolute lighting control is right at your ﬁngertips with this Stryder Fanless 150 watt LED Fresnel Light with DMX. The impressive daylight LED features a

4” Fresnel lens with a spot to ﬂood beam range of 15 to 65°. Toss in the ability to accurately shape light with removable barn doors, dimming capabilities

between 0-100% (controlled in increments 5), and its ability to use traditional gel rings, mean that this workhorse of a light will undoubtedly become a

staple in your kit.

A. LCD Display

B. Color Temperature/

Conﬁrmation Knob

C. DMX Channel Adjustment

D. Brightness Knob

E. DMX Input

F. DMX Output

G. XLR Power Port

H. Yoke Adjustment Knob

J. Barn Door Locking Pin

K. Power Input (from control panel)

L. Focusing Knob

M. Power Switch

N. Power Out (to light ﬁxture)

P. V-Mount Battery Plate

Color Temperature Battery

Brightness

Color : 5600K B:

100%

Bright: 100%

B C D

H J

www.ikancorp.com | 1.713.272.8822 | [email protected] because we’re ﬁlmmakers too

Notice & Maintenance

- Products must be placed on a stable, dry, ﬂat surface. Avoid exposure to sunlight and operating in an environment with high humidity or explosive gas.

- Don’t cover the fan vent. It will shorten the working life of the ﬁxture.

- Don’t knock or shake the lighting equipment during the operation.

- If the SFB150 isn’t working normally, please contact the Ikan repair department. Please don’t disassemble/re-assemble by yourself.

- Please place the SFB150 in a cool and dry place when you don’t use it for an extended period of time.

Speciﬁcations

Beam Angle 15 - 65 degrees

Build Material Aluminum

Control Local Knob Control and DMX In/Out

Cooling System Fanless Passive Cooling

Dimming Flicker Free Dimming, Onboard Dimming

Knob 10%-100% (minimal color shift)

Focusing Push Focus from 15 - 65

Head Type 3200K - 5600K

Lens 4” Acrylic Fresnel

Light Source 1 x 150 watt LED Bi-Color

Power Consumption 98W

Power Supply 110-240VAC; Output: [email protected]

Yoke Baby 5/8”

Optional Accessories

Some other products that work well with the Stryder SFB150 available from Ikan include:

HD-STND-V2

KCP-703

SW-04

Heavy Duty Light Stand

Stage Clamp w/ 16mm Stud

Safety Wire

www.ikancorp.com | 1.713.272.8822 | [email protected] because we’re ﬁlmmakers too

Learn More

More dynamic information at ofﬁcial website: www.ikancorp.com

Support

Contact email: [email protected]

CONDITIONS OF WARRANTY SERVICE

• Free service for one year from the day of purchase if the problem is caused by manufacturing errors.

• The components and maintenance service fee will be charged if the warranty period is expired.

Free Service will not be Provided in the Following Situations:

(Even if the product is still within the warranty period.)

• Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company.

• Damage caused by natural disaster, abnormal voltage, and environmental factors, etc.
