ENGLISH
Thank you very much for choosing the iiyama
LCD display for signage.
We recommend that you take a few minutes
to read this comprehensive manual carefully
before installing and switching on the display.
Please keep this manual in a safe place for
your future reference.
USER MANUAL
ENGLISH
ENGLISH
We reserve the right to change specifi cations without notice.
All trademarks used in this user manual are the property of their respective owners.
We recommend recycling of used product. Please contact your dealer or iiyama
service center. Recycle information is obtained via the Internet, using the
address: http://www.iiyama.com
You can access the Web page of diff erent countries from there.
CE MARKING DECLARATION OF CONFORMITY
This LCD display complies with the requirements of the EC/EU Directive 2014/30/EU “EMC
Directive”, 2014/35/EU “Low Voltage Directive” and 2011/65/EU “RoHS Directive”.
Warning
This is a class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
IIYAMA CORPORATION: Wijkermeerstraat 8, 2131 HA Hoofddorp, The Netherlands
Model No. : PL7540UH, PL8640UH
ENGLISH
TABLE OF CONTENTS
FOR YOUR SAFETY ............................................................................1
SAFETY PRECAUTIONS................................................................1
SPECIAL NOTES ON LCD MONITORS .........................................3
CUSTOMER SERVICE ...................................................................5
CLEANING ......................................................................................5
BEFORE YOU OPERATE THE DISPLAY ............................................6
FEATURES......................................................................................6
CHECKING THE CONTENTS OF THE PACKAGE ........................6
UNPACKING ...................................................................................7
CONTROLS AND CONNECTORS : DISPLAY ................................8
INSTALLATION ............................................................................. 11
CONTROLS AND CONNECTORS : REMOTE CONTROL ...........12
PREPARING THE REMOTE CONTROL.......................................13
ID REMOTE CONTROL ................................................................14
BASIC OPERATION ......................................................................15
CONNECTING YOUR THE DISPLAY : ProLite LE7540UHS ......18
CONNECTING YOUR THE DISPLAY : ProLite LE8640UHS ......19
COMPUTER SETTING .................................................................22
OPERATING THE DISPLAY ...............................................................23
ADJUSTMENT MENU CONTENTS ..............................................25
SCREEN ADJUSTMENTS ............................................................42
POWER MANAGEMENT FEATURE .............................................45
TROUBLE SHOOTING ......................................................................46
RECYCLING INFORMATION .............................................................47
APPENDIX ........................................................................................48
SPECIFICATIONS : ProLite LE7540UHS .....................................48
SPECIFICATIONS : ProLite LE8640UHS .....................................49
DIMENSIONS : ProLite LE7540UHS ............................................50
DIMENSIONS : ProLite LE8640UHS ............................................50
COMPLIANT TIMING ....................................................................51
ENGLISH
FOR YOUR SAFETY 1
FOR YOUR SAFETY
WARNING
STOP OPERATING THE DISPLAY WHEN YOU SENSE TROUBLE
If you notice any abnormal phenomena such as smoke, strange sounds or fumes, unplug the display
and contact your dealer or iiyama service center immediately. Further use may be dangerous and
can cause fi re or electric shock.
NEVER REMOVE THE CABINET
High voltage circuits are inside the display. Removing the cabinet may expose you to the danger of
fi re or electric shock.
DO NOT PUT ANY OBJECT INTO THE DISPLAY
Do not put any solid objects or liquids such as water into the display. In case of an accident, unplug
your display immediately and contact your dealer or iiyama service center. Using the display with
any object inside may cause fi re, electric shock or damage.
INSTALL THE DISPLAY ON A FLAT, STABLE SURFACE
The display may cause an injury if it falls or is dropped.
DO NOT USE THE DISPLAY NEAR WATER
Do not use where water may be splashed or spilt onto the display as it may cause fi re or electric
shock.
OPERATE UNDER THE SPECIFIED POWER SUPPLY
Be sure to operate the display only with the specifi ed power supply. Use of an incorrect voltage will
cause malfunction and may cause fi re or electric shock.
PROTECT THE CABLES
Do not pull or bend the power cable and signal cable. Do not place the display or any other heavy
objects on the cables. If damaged, the cables may cause fi re or electric shock.
ADVERSE WEATHER CONDITIONS
It is advisable not to operate the display during a heavy thunder storm as the continual breaks in
power may cause malfunction. It is also advised not to touch the plug in these circumstances as it
may cause electric shock.
SAFETY PRECAUTIONS
ENGLISH
2 FOR YOUR SAFETY
CAUTION
INSTALLATION LOCATION
Do not install the display where sudden temperature changes may occur, or in humid, dusty or
smoky areas as it may cause fi re, electric shock or damage. You should also avoid areas where the
sun shines directly on the display.
DO NOT PLACE THE DISPLAY IN A HAZARDOUS POSITION
The display may topple and cause injury if not suitably located. Please also ensure that you do not
place any heavy objects on the display, and that all cables are routed such that children may not pull
the cables and possibly cause injury.
MAINTAIN GOOD VENTILATION
Ventilation slots are provided to keep the display from overheating. Covering the slots may cause
fi re. To allow adequate air circulation, place the display at least 10 cm (or 4 inches) from any walls.
Operating the display on its back, side, upside down or on a carpet or any other soft material may
also cause damage.
DISCONNECT THE CABLES WHEN YOU MOVE THE DISPLAY
When you move the display, turn off the power switch, unplug the display and be sure the signal
cable is disconnected. If you do not disconnect them, it may cause fi re or electric shock.
UNPLUG THE DISPLAY
If the display is not in use for a long period of time it is recommended that it is left unplugged to
avoid accidents.
HOLD THE PLUG WHEN DISCONNECTING
To disconnect the power cable or signal cable, always pull it by the plug. Never pull on the cable
itself as this may cause fi re or electric shock.
DO NOT TOUCH THE PLUG WITH WET HANDS
Pulling or inserting the plug with wet hands may cause electric shock.
WHEN YOU INSTALL THE DISPLAY ON YOUR COMPUTER
Be sure the computer is strong enough to hold the weight of the display, otherwise, you may
damage your computer.
REMARK FOR 24/7 USAGE
This product is not specifi cally designed for 24/7 usage. (Recommended operating time is 18 hours/
Day.)
ERGONOMIC RECOMMENDATIONS
To eliminate eye fatigue, do not operate the display against a bright background or in a dark room.
For optimal viewing comfort, the display should be just below eye level and 40-60 cm (16-24 inches)
away from your eyes. When using the display over a prolonged time, a ten minute break every hour
is recommended as looking at the screen continuously can cause eye strain.
OTHERS
ENGLISH
FOR YOUR SAFETY 3
The following symptoms are normal with LCD monitors and do not indicate a problem.
NOTE - When you fi rst turn on the LCD monitor, the picture may not fi t in the display area
because of the type of computer that is used. In this case, adjust the picture position to
the correct position.
- You may fi nd slightly uneven brightness on the screen depending on the desktop
pattern you use.
- Due to the nature of the LCD screen, an afterimage of the previous screen may remain
after switching the image, when the same image is displayed for hours. In this case, the
screen is recovered slowly by changing the image or turning off the Power Switch for
hours.
SPECIAL NOTES ON LCD MONITORS
This LCD cannot be used outdoors.
This LCD cannot be used with the screen facing upwards.
If you use a cable longer than the supplied one, the picture quality is not guaranteed.
ENGLISH
4 FOR YOUR SAFETY
USAGE CONFIRMATION
This product is designed for optimum usage at 18hours per day.
The display is compatible for usage in Landscape applications.
IMAGE PERSISTENCE / IMAGE STICKING
Please be aware that all LCD screens can experience Image Persistence or Image Sticking. This
occurs when a residual image remains visible on a screen when static images are displayed for long
periods of time. LCD Image Persistence is not permanent but constant images being displayed for a
long period of time should be avoided.
To counteract Image Persistence, turn off the monitor for as long as the previous image was
displayed, so if an image was on the monitor for 1 hour and there is evidence of a residual or “ghost”
image, you should turn off the monitor for 1 hour in order to clear the residual image.
For all LFD products, iiyama recommends displaying moving images and utilising a moving screen
saver at regular intervals whenever the screen is idle. You could also turn off the monitor when not
in use to assist the prevention.
Other ways to reduce the risk of Image Persistence will be to utilise the FAN-on function (if
available), Low Backlight and Low Brightness settings.
FOR EXTENDED USE AS A PUBLIC DISPLAY
Image Sticking on LCD Panel
When a static image is displayed for hours, an electric charge trace remains near the electrode
inside the LCD producing a “ghost” image. (Image Persistence).
Image Persistence is not a permanent feature.
Recommendations
To prevent Image Sticking and promote longer life expectancy of display, we recommend the
following:
1. Avoid static images displayed for long periods – change static images on continuous loop.
2. Turn off monitor when not in use, either by remote control or use Power Management or Schedule
functions.
3. When monitor is installed in high ambient temperature environment(s) or in an enclosed position,
utilise the Cooling Fan, Screen Saver and Low Brightness functions.
4. Suitable ventilation for any monitor is an expectation of any installation – climate control systems
may need to be employed.
5. We strongly recommend utilisation of active cooling with fans for long operation times or high
ambient temperature environments.
ENGLISH
FOR YOUR SAFETY 5
NOTE
If you have to return your unit for service and the original packaging has been
discarded, please contact your dealer or iiyama service center for advice or
replacement packaging.
WARNING
If you drop any materials or liquids such as water into the
display
when cleaning,
unplug the power cable immediately and contact your dealer or iiyama service center.
CAUTION
For safety reasons, turn off the power switch and unplug the display before you
clean it.
NOTE
To protect the LCD panel, do not scratch or rub the screen with a hard object.
Never use any of the following strong solvents. These will damage the cabinet and
the LCD screen.
Touching the cabinet with any product made from rubber or plastic for a long time
may cause degeneration or loss of paint on the cabinet.
Thinner Benzine Abrasive cleaner
Spray-type cleaner Wax Acid or Alkaline solvent
CABINET Stains can be removed with a cloth lightly moistened with a mild detergent solvent.
Then wipe the cabinet with a soft dry cloth.
LCD
SCREEN
Periodic cleaning with a soft dry cloth is recommended.
Don't use tissue paper etc. because these will damage the LCD screen.
CUSTOMER SERVICE
CLEANING
ENGLISH
6 BEFORE YOU OPERATE THE DISPLAY
The following accessories are included in your package. Check to see if they are enclosed with
the display. If anything is missing or damaged, please contact your local iiyama dealer or regional
iiyama offi ce.
* The rating of the Power Cable enclosed in 120V area is 10A/125V. If you are using
a power supply higher than this rating, then a power cable with a rating of 10A/
250V must be used. However, all guarantees and warranties are void for any
problems or damage caused by a power cable not supplied by iiyama.
An approved power cord greater or equal to H05VVF, 3G, 0.75mm2 must be used.
Power Cable*
HDMI Cable mDP-DP Cable
DisplayPort Cable RS-232C Cable Remote Control
Battery (2pcs) POP Label iiyama Logo Sticker
EU Energy Label Safety Guide Quick Start Guide
BEFORE YOU OPERATE THE DISPLAY
CHECKING THE CONTENTS OF THE PACKAGE
CAUTION
FEATURES
Supports Resolutions up to 3840 × 2160
High Contrast 1200:1 (Typical) / Brightness 410cd/m
2
(Typical)
Digital Character Smoothing
Automatic Set-up
Stereo Speakers
2 × 10W Stereo Speakers
Power Management (VESA DPMS Compliant)
VESA Mounting Standard (600mm×400mm) Compliant
Ce manuel convient aux modèles suivants
3
Table des matières
Autres manuels Iiyama Moniteur
Iiyama
Iiyama ProLite X3272UHS Manuel utilisateur
Iiyama
Iiyama ProLite L460W Manuel utilisateur
Iiyama
Iiyama ProLite B2480HS-W2 Manuel utilisateur
Iiyama
Iiyama Prolite E4835 Manuel utilisateur
Iiyama
Iiyama ProLite TF1015MC Manuel utilisateur
Iiyama
Iiyama ProLite T2253MTS Manuel utilisateur
Iiyama
Iiyama ProLite TF3222MC-B2 Manuel utilisateur
Iiyama
Iiyama ProLite XU2495WSU Manuel utilisateur
Iiyama
Iiyama ProLite XB2779QS-S1 Manuel utilisateur
Iiyama
Iiyama Vision Master Pro 452 Manuel utilisateur
Iiyama
Iiyama ProLite XUB3490WQSU-B1 Manuel utilisateur
Iiyama
Iiyama G-MASTER OB276OQSU Manuel utilisateur
Iiyama
Iiyama ProLite E2607WSD Manuel utilisateur
Iiyama
Iiyama ProLite B2008HDS-1 Manuel utilisateur
Iiyama
Iiyama Prolite xub3490wqsu Manuel utilisateur
Iiyama
Iiyama Pro Lite E2201W-2 Manuel utilisateur
Iiyama
Iiyama ProLite T2454MSC Manuel utilisateur
Iiyama
Iiyama ProLite E2273HDS Manuel utilisateur
Iiyama
Iiyama ProLite XB2776QS Manuel utilisateur
Iiyama
Iiyama ProLite GB2773HS Manuel utilisateur
