user manual
2
You have made an excellent choice with your
iConnect™media keyboard & wireless laser mouse.
This product comes with a limited one-year warranty.
Before using, please read and follow these
instructions. If you still need help, see the back page
for other support options.
For more about our products, visit
www.life-works.com.
Model IH-K235LB
system requirements
Windows• ®XP or Windows Vista®
USB port•
contents
features 3
get started 3
your new keyboard 4
your new mouse 5
dock your iPod or iPhone 6
using your keyboard 7
using your mouse 9
product operating tips 10
troubleshooting 11
3
features
keyboard
charge-n-sync iPod• ®or iPhone®with iTunes®
illuminated touch-sensitive media keys•
2 rotating USB 2.0 ports•
rubberized wrist rest•
mouse
plug-n-play, no syncing needed•
2.4 GHz up to 30 feet•
high-resolution laser sensor•
horizontal & vertical scrolling•
low battery indicator•
stowable nano USB receiver•
get started
If you have not done so already, follow the steps
in the get started guide to connect your new
hardware.
4
your new keyboard
iPod or
iPhone
dock
cover
play/
pause
numeric
keypad
special function keys illuminated touch-sensitive
media keys USB 2.0 ports
USB connector
power connector
rubberized
wrist rest
5
laser sensor
power on/off
switch
bottom view
your new mouse
Please see your get started guide for
instructions on how to connect your
new hardware to your computer.
USB ports on
keyboard rotate
for easier use
scroll wheel
battery indicator
light is green
when mouse is
rst turned on
ashing red
indicates
low battery
top view
6
dock your iPod or iPhone
Keyboard must be connected to ACWARNINGf
adapter at all times when in use.
Your keyboard is designed to sync and charge your
iPod or iPhone when docked.
gently slide the dock cover forward
1.
insert your iPod or iPhone
2.
For a snug t, use one of the three inserts before
docking your iPod or IPhone.
See the table on next page for which insert to use.
(Look for the number on the back of the insert.)
7
device use insert
iPod nano (1st, 2nd, 3rd and 4th
generation) 1
iPod classic (80GB, 120GB)
iPod 5G (30 GB)
iPod touch, 1st and 2nd
generation
(8GB, 16GB, 32GB)
2
iPhone 3G
iPod classic (160GB)
iPod 5G (60GB, 80GB) 3
using your keyboard
adjust the volume from the keyboard
Slide nger across volume control to adjust volume—
left to lower, right to increase.
To go from minimum to maximum volume ornotef
back again, swipe four times.
Press the key + the special function key for the
desired action.
8
special function keys
function key function
F2 My Computer
F3 My Favorites
F4 home
F5 search
F11 wake
F12 sleep
media keys
media key function
shufe
repeat
previous track
next track
mute
for use in iTunes only: if iPod or
iPhone selected, ejects docked
iPod or iPhone; otherwise opens
CD-ROM drive
9
using your mouse
horizontal and vertical scroll
Roll the wheel up and down to scroll vertically.
Tilt the wheel left or right to scroll horizontally.
install software for horizontal scrolling
You only need to install the software if younotef
want to use the horizontal scroll with your
mouse.
Download mouse driver from
1.
www.life-works.com/drivers
Double-click downloaded le
2.
Follow on-screen instructions to install3.
auto scroll
The scroll wheel is also a button. Press the scroll
wheel (without rolling it) and the mouse pointer
on the screen will change to . Move your mouse
up/down or left/right to set the scroll speed
(the more you move the mouse the faster the page
will scroll the document or web page).
Click the wheel button again to turn off auto scroll.
10
product operating tips
WARNING:• Always connect the supplied AC
adapter when using the keyboard.
Use one of the included inserts to make your iPod•
or iPhone t securely in the dock. (See “dock your
iPod or iPhone” on page 6.)
Your mouse will operate from as far away as•
30 ft. (10 m) from your computer.
To save battery power, turn off the mouse when•
not in use.
Store the nano USB receiver under the battery•
cover for travel or when not in use.
