iHome iP11 Manuel utilisateur
Model iP11
Alarm Clock for
your iPhone and iPod ®
Questions? Visit www.ihomeaudio.com
Model:iP11
InstructionManual
Date:Dec15,09
Printcolor:Blacktextonwhitepaper
Size:178Wx140Hmm
1
2
3
3
4
5
5
5
6
7
7
8
9
10
11
Quick Start
Controls and Indicators
iP11 Display
Install Clock Backup Battery
Setting the Clock
Charging your iPhone/iPod
Listening to your iPhone/iPod
Listening to other portable audio devices
Alarm Operation
Sleep Operation
Snooze/Dimmer Operation
A Consumer Guide to Product Safety
Trouble Shooting
Solución De Problemas
Warranty Information
Table of Contents
• Place the unit on a level surface away from sources of direct sunlight or excessive heat.
• Protect your furniture when placing your unit on a natural wood and lacquered finish. A cloth or other protective material
should be placed between it and the furniture.
• Clean your unit with a soft cloth moistened only with mild soap and water. Stronger cleaning agents, such as Benzine, thinner
or similar materials can damage the surface of the unit.
Maintenance
FCC Information
This equipment complies with the limits for a Class B digital device as specified in Part 15 of FCC Rules. These
limits provide reasonable protection against radio and TV interference in a residential area.
However, your equipment might cause TV or radio interference even when it is operating properly. To eliminate
interference you can try one or more of the following corrective measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and the radio or TV.
• Use outlets on different electrical circuits for the equipment and the radio or TV.
• Consult your dealer or an experienced radio/television technician if the problem still exists.
Modifying or tampering with your system’s internal components can cause a malfunction and might invalidate
the system’s warranty and void your FCC authorization to operate it.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
This device complies with Part 15 of the FCC Rules, operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Battery Warning
For models that use Lithium batteries
• Lithium batteries can explode or cause burns if
disassembled, shorted, recharged, exposed to water,
fire, or high temperatures. & not handled appropriately
• Do not place loose batteries in a pocket, purse, or other
container containing metal objects, mix with used or
other battery types, or store with hazardous or
combustible materials.
• Store in cool, dry, ventilated area.
• Follow applicable laws and regulations for transport
and disposal.
For models that require more than one battery
• Do not mix with used or other battery types/brands
• Replace all cells at the same time
• Do not open batteries
• Do not dispose of in fire
• Do not heat above 75C (167F)
• Do not expose contents to water
• Do not charge or recharge
• Do not install backwards
1
iP11 Quick Start
2:inserts
Select the dock insert for your
iPhone or iPod model from the table
below and place insert in dock.
Never dock an iPhone or iPod
without an insert in place.
3:iPhone/iPod
Insert iPhone/iPod into dock with proper
insert (iPhone/iPod must not be in a skin or
case). iPhone/iPod will charge while docked.
Press iPhone/iPod Button on iP11 to play
iPhone/iPod.
4:time sync • Make sure your iPhone/iPod is docked properly (see above).
• Press the Time sync/set button located on the back of the unit.
A cursor will cycle across the display, indicating sync mode.
• Two beeps will confirm successful syncing and the time will update.
• See “Setting the Clock” on page 5 to set clock manually.
1:power
Attach AC adaptor cable to jack on
back of the iP11 and plug the other
end into a wall socket.
DC 10Vline in
dst
-1 +1 on o
NOTE: If you do not have an insert for your iPhone/iPod,
please visit www.ihomeaudio.com or call iHome
toll free at 800-288-2792 to purchase one
iPod Touch 2G
iPhone 3G
Insert 15
nano 5G
insert 18
nano 5G
iPhone 3G/ 3GS
iiPod touch 2G
insert 16
For this
iPhone/iPod
Use this insert
For models that require more than one battery
• Do not mix with used or other battery types/brands
• Replace all cells at the same time
• Do not open batteries
• Do not dispose of in fire
• Do not heat above 75C (167F)
• Do not expose contents to water
• Do not charge or recharge
• Do not install backwards
Controls and Indicators
Front Panel
Power Off /
Alarm Reset Button
Volume + Button
Dock
iPhone/iPod Play/Pause Button
Volume - Button
DST Switch
Snooze/Dimmer Button
Back Panel
2
DC Jack
Alarm Set /
Alarm On/Off Button
Time sync/set Button
Hour Set Button
Sleep/Minute Set Button
EXB Expanded Bass Switch
Line-in Jack
DC 10Vline in
dst
-1 +1 on o
Installing Backup Battery
3
iP11 Display
Install Clock Backup Battery
PM Indicator
Battery Low Indicator
Daylight Saving Time
Indicator
iPhone/iPod Indicator
Sleep Indicator
Alarm Indicator
Time Display
The iP11 uses a CR2032 button cell backup battery system to provide
continuous alarm operation and clock settings in the event of a power
failure. If the Backup Battery has been installed and a power failure
occurs or the AC adaptor is accidentally disconnected, the display backlight
will not remain lit, but current time and alarm time settings will be temporarily
maintained. Otherwise, you must reset the time and alarm settings.
1. Please make sure the AC adaptor is connected. Otherwise all settings may
be lost during battery replacement.
2. Open backup battery compartment door located on the backside of the unit.
3. Insert one CR2032 button cell battery, checking that the polarity (+ and
– sides of the battery) matches the drawing in the battery compartment.
Close the compartment door.
Note: Make sure you dispose of batteries properly (see your local regulations).
Setting the Clock Time
1. Press and hold the Time sync/set Button for 2 seconds until the display flashes. Press the Hour Set Button until
the current hour is displayed. Next, press the Sleep/Minute Set Button to set the current minute.
2. Press the Time sync/set Button again to confirm the clock setting. You should hear 2 beeps indicating the clock time
is set.
3. For 12 hour or 24 hour time format setting: Press the Alarm Set Button during time setting to set 12-hour or 24-hour
display format. Remember to set the correct AM or PM time (an icon to the right of the time display is the PM indicator;
there is no AM indicator).
4. During daylight saving time, set the DST Switch located on the backside of the unit to +1 to advance the time one
hour. The DST Icon will appear next to the time display to indicate DST is on. Set the switch to -1 to quickly set the time
back one hour at the end of daylight saving time.
Using the Time Sync Feature
The iP11 Time Sync feature allows you to sync the time setting on the iP11 to the time from your iPhone or recent model iPod
(iPod Touch, iPod Nano and iPod Classic; older iPod models such as iPod mini do not support this feature).
1. Dock your iPhone using the proper insert.
2. Press the Time sync/set Button to sync the iP11 clock to the time on your iPhone/iPod. The display will show a moving
cursor, indicating the unit is syncing. When successfully completed, two beeps will confirm the time has been synced. Retry
if sync is not successful.
Note: iPhone time is automatically updated to the correct time via cell phone towers. The time on your iPod is accurate only
to the time on the computer the last time the iPod was synced to it. An iPhone or iPod cannot sync to exact seconds; it’s
possible to have up to 59 seconds difference between the iP11 and synced iPhone or iPod.
4
Setting the Clock
1. Dock the already playing iPhone/iPod. The iP11 will automatically turn on and you will hear the music playing from your
iPhone/iPod.
The iPhone/iPod Icon will appear at the right lower corner the display, indicating iPhone/iPod playing mode.
For enhanced bass, slide the EXB Expanded Bass Switch located on the back of the unit to the ON position.
Note: If the playing song/music loudness is too low on the iPhone/iPod itself, the iP11 may not detect that the iPhone/iPod
is in play mode. Press the iPhone/iPod Play/Pause Button on the iP11 twice to play it.
2.
When the iPhone/iPod is docked and in standby mode, press the
iPhone/iPod Play/Pause Button on the iP11 to play
it. The iPhone/iPod Icon will appear at the right lower corner the display, indicating iPhone/iPod playing mode.
3. Press the iPhone/iPod Play/Pause Button again to pause play; press again to resume it.
4. Press the Volume + and Volume – Button on the iP11 to adjust the system volume.
5. To turn the iP11 OFF, press the Alarm Reset/Power Off Button. Your iPhone/iPod will continue charging while in the
dock.
5
Listening to your iPhone/iPod
If you are using an iPod without a docking port or other MP3 player or portable audio device, you can still play it through
the iP11 via the Line-in Jack.
1. Plug one end of an audio patch cord (available at www.ihomeaudio.com) into the headphone or line-out jack on
your device and the other end of the patch cord into the iP11 Line-in Jack, located on the back of the unit.
2. Press the iPhone/iPod Play/Pause Button on the iP11 to turn the unit on. The iPhone/iPod Icon will appear at
the lower right corner the display, indicating Line-in playing mode.
3. Turn on and play your device.
4. Press the Volume + and Volume – Button on the iP11 to adjust the system volume. You may need to adjust
your device volume, too.
5. To turn othe iP11 OFF, press the Alarm Reset/Power Off Button on the iP11. Please remember to turn off your
device, too.
Listening to other portable audio devices
Note: Please make sure you are using the correct insert for your iPhone/iPod (see page 1) and that it is properly docked into
the iP11. Failure to do so may damage your iPhone/iPod.
1. While your iPhone/iPod is docked in the unit and the unit is connected to AC power, it recharges (until fully charged). The
iP11 will not overcharge your iPhone/iPod. Note that non-docking iPods will NOT charge.
Charging your iPhone/iPod
The iP11 Home System for iPhone/iPod features “Sure Alarm”. If a power failure occurs or the AC adaptor is accidentally
disconnected, the unit will change to buzzer alarm to wake you up (provided you have installed backup battery).
This unit also features Gentle Waking, which gradually increases the volume of whatever alarm you set.
NOTE: TO WAKE TO iPhone/iPod, YOUR iPhone/iPod MUST BE PROPERLY DOCKED AND OFF (NOT IN PLAY
MODE) OR NO ALARM WILL SOUND. You CANNOT wake to Line in audio devices.
Setting the Alarm Time
1. Press and hold the Alarm Set Button for 2 seconds until the display flashes. Press the Hour Set Button until the
desired alarm hour is displayed. Next, press the Sleep/Minute Set Button to set the desired alarm minute.
Remember to set the correct AM or PM if you are using 12 hour clock format.
2. Press the Alarm Set Button again to exit the setting mode. You should hear 2 beeps indicating the alarm is set.
Note: Once you set the alarm time, the alarm will be automatically armed, indicated by the Alarm Icon. To disarm the alarm,
press the Alarm Set Button. The Alarm Icon will disappear and the alarm will not sound at the set time.
Note: Make sure to adjust volume level for comfortable wake up volume
4. When the alarm is sounding, the Alarm Icon will flash.
• To snooze during the alarm, press the Snooze/Dimmer Button. The alarm will be silenced for 9 minutes, then come
on again.
• To turn the alarm off, press the Alarm Reset/Power Off Button. The alarm will come on again the next day at the
same time.
5. If the alarm is not turned off after it sounds, it will play for approximately one hour then turn off automatically. This cycle
will repeat every 24 hours unless the controls are changed.
Note: Please make sure your iPhone/iPod has enough songs to play for one hour, otherwise please set the iPhone/iPod
repeat mode to ON.
Note: If there is no iPhone/iPod present or there is no music detected on the iPhone/iPod at alarm time, the iP11 will
automatically switch to buzzer alarm.
6
Alarm Operation
1. When the iP11 is off or while listening to your iPhone/iPod, press the Sleep/Minute Set Button to enter sleep mode.
The Sleep Icon will appear on the display to indicate it is in sleep mode. Sleep mode has a Gentle Sleep feature which
gradually lowers the volume before it shuts off.
2. You can adjust the sleep timer from 90, 60, 30 or 15 minutes by pressing the Sleep/Minute Set Button again.The
unit will automatically turn off after the selected time.
3. When the display changes back to show the real time, pressing the Sleep/Minute Set Button once will show the
sleep time remaining. Pressing it again will change the sleep time to the next lowest increment.
4. The iP11 has an independent volume setting for sleep mode so you can adjust the sleeping volume without affecting the
alarm volume. Press the Volume + and Volume – Button on the iP11 to adjust the sleep volume. The sleep volume
will remain at that level the next time you enter sleep mode until controls are changed.
5. To stop listening at any time, press the Alarm Reset/Power Off Button on the iP11 to turn it off.
1. Press the Snooze/Dimmer Button on the iP11 after the alarm sounds. The alarm will go off and will come on again
in approx. 9 minutes. You may repeat this cycle several times during the one hour alarm cycle.
2. During normal operation, press the Snooze/Dimmer Button to control the brightness (high, medium, low and off) of
the LCD display and side accent lights.
7
Sleep Operation
Snooze/Dimmer Operation
Table des matières
Autres manuels iHome Réveil
iHome
iHome HBH88 Manuel utilisateur
iHome
iHome iBTW23 Manuel utilisateur
iHome
iHome iH120 Manuel utilisateur
iHome
iHome IM14 Manuel utilisateur
iHome
iHome iP40 Manuel utilisateur
iHome
iHome iPL10 Manuel utilisateur
iHome
iHome iKN95 Manuel utilisateur
iHome
iHome iHM46 Manuel utilisateur
iHome
iHome HWL83 Manuel utilisateur
iHome
iHome iBN18 Manuel utilisateur
iHome
iHome iKN105 Manuel utilisateur
iHome
iHome iH11 Manuel utilisateur
iHome
iHome iBT290 Manuel utilisateur
iHome
iHome iH11 Manuel utilisateur
iHome
iHome IP21 Manuel utilisateur
iHome
iHome IA17 Manuel utilisateur
iHome
iHome IP38 Manuel utilisateur
iHome
iHome iPL10 Manuel utilisateur
iHome
iHome iKT50 Manuel utilisateur
iHome
iHome IP23 Manuel utilisateur
