Ignition Pico IR / Wireless Manuel utilisateur

M ANUAL

Pico IR / Wireless

2 / 9

PIC O IR/ WIRELESS

Table of contents

1. Safety instructions ........................................................................................................................... 3

1.1. FOR SAFE AND EFFICIENT OPERATION............................................................................ 3

2. Commissioning................................................................................................................................ 4

2.1. Charging.................................................................................................................................. 4

3. Remote control ................................................................................................................................ 5

4. Wireless DMX.................................................................................................................................. 6

4.1. Setting the DMX address......................................................................................................... 6

5. Troubleshooting Pico....................................................................................................................... 7

6. Troubleshooting Flightcase ............................................................................................................. 7

7. Maintenance.................................................................................................................................... 8

8. Technical Data................................................................................................................................. 8

3 / 9

PIC O IR/ WIRELESS

1. Safety instructions

This device is suitable for indoor use only.

All modifications to the device will void the warranty.

Repairs are to carry out by skilled personnel only.

Use only fuses of the same type and original parts as spare parts.

Protect the unit from rain and humidity to avoid fire and electric shocks.

Make sure to unplug the power supply before opening the housing.

1.1. FOR SAFE AND EFFICIENT OPERATION

Be careful with heat and extreme temperature

Avoid exposing it to direct rays of the sun or near a heating appliance.

Not put it in a temperature bellow 32°F /0°C, or exceeding 104°F /40°C.

Keep away from humidity, water and dust

Do not place the set in a location with high humidity or lots of dust.

Containers with water should not be placed on the set.

Keep away from sources of hum and noise

Such as transformer motor, tuner, TV set and amplifier.

To avoid placing on un-stable location

Select a level and stable location to avoid vibration.

Do not use chemicals or volatile liquids for cleaning

Use a clean dry cloth to wipe off the dust, or a wet soft cloth for stubborn dirt.

If out of work, contact sales agency immediately

Any troubles arose, remove the power plug soon, and contact with an engineer for repairing, do not

open the cabinet by yourself, it might result a danger of electric shock.

Take care with the power cable

Never pull the power cable to remove the plug from the receptacle, be sure

to hold the plug. When not using the device for an extended period of time, be sure to disconnect the

plug from the receptacle.

4 / 9

PIC O IR/ WIRELESS

Important: Damages caused by the disregard of this user manual are not subject to

warranty. The dealer will not accept liability for any resulting defects or

problems. Make sure the electrical connection is carried out by qualified

personnel. All electrical and mechanical connections have to be carried out

according to the European safety standards.

- Before using: Make sure that there are no external damages.

- The minimum distance to flammable objects is 0,2m

- For vertical operation, the equipment complies with IP63 standard.

- There can be a maximum housing-temperature of tc=45°C.

- Don´t plug an audio or DMX device to the XLR plug. It can cause permanent damages of the

devices.

- Because of is lead gel battery you are not allowed to dispose it of in household waste.

- This battery is a high-quality product with approval of medical devices.

- The „Amptown“-Flightcase (optional) corresponds to the IP20 standard.

Important:

Every 3 weeks should be a regeneration charging to take place to avoid damaging the

battery.

2. Commissioning

Push the ON button on the IR remote control. The unit turns on and is ready for operation.

2.1. Charging

Connect the LED headlamp with the included power supplyIn the event you have bought a “Tourpack”

you can connect the device with pre-installed XLR connectors.

While charging the LED headlamp should be turned off, otherwise there can be no sufficient charge.

The loading process can take up to 10 hours, depending on the remaining charge of the battery.

If you turn the switch on the charging rail you can see the state of charge for every battery (only

possible with the “Tourpack”).

5 / 9

PIC O IR/ WIRELESS

3. Remote control

increase brightness

lower the brightness

red permanently

green permanently

orange permanently

lime permanently

dark yellow permanently

blue-green permanently

yellow permanently

light blue permanently

light yellow permanently

sky-blue permanently

red intensify

green intensify

red reduce

green reduce

custom setting 1

custom setting 2

custom setting 4

custom setting 5

color change with flash ( 3 colors)

color-change with flash (7 colors)

On/Off

Start/Pause

white permanently

blue permanently

beige permanently

dark blue permanently

white pink permanently

ultramarine permanently

green white permanently

purple permanently

blue white permanently

blackberry permanently

faster

blue intensify

slower

blue reduce

automatic change

custom setting 3

flash on/off

custom setting 6

smooth color change (7 colors)

smooth color change (3 colors)

6 / 9

PIC O IR/ WIRELESS

4. Wireless DMX

Only available if you bought the version “Pico IR Wireless“, otherwise you only can control the device

with the remote control.

LED display and its meaning

Permanently off = not connected to the transmitter

Permanently on = connected with the transmitter / DMX is transmitted

900ms on/ 100ms off = connected with the transmitter / No DMX signal

100ms on/ 100ms off = loose connection / Connection is perpared

4.1. Setting the DMX address

You can set the DMX address with the help of a binary system on the “Dipswitch“.In this cause the

“Dip” 10 is the set function. Switch the “Dip” 10 to on to release the connection to the wireless solution

transmitter. Switch the “Dip” then again to off.

7 / 9

PIC O IR/ WIRELESS

5. Troubleshooting Pico

The unit does not turn on.

Error

Failure of one color

Failure of the projection.

Light yield reduced

Possible causes

Check and reaction

No power supply.

Check the battery voltage

Defect LED.

Change the defect LED.

Empty battery of remote control.

Change the battery.

Defect optics.

Contact qualified personnel.

Dust or dirt.

Clean the device.

Defect remote control.

Change the defect remote control.

Fault in the electronics.

Contact qualified personnel.

Defect battery.

Contact qualified personnel.

6. Troubleshooting Flightcase

There is no charge

Error

No charge status indicator.

State of charge indicator does not reach max.

Possible causes

Check and reaction

No power supply.

Check the voltage

Defect power supply

Contact qualified personnel.

Fault in the electronics.

Contact qualified personnel.

Contact error of the XLR connectors.

Plug the XLR connector again.

Contact error.

Contact qualified personnel.

Defect battery.

Contact qualified personnel.

Switched on headlight.

Switch the headlight off.

8 / 9

PIC O IR/ WIRELESS

7. Maintenance

Opening the device may only be performed by technical personnel only!

- Remove the caps which are on the handle with a flat screwdriver.

- Among them are two screws, unscrew them and remove the handle.

- Now you can pull out the whole inner part down.

- .

8. Technical Data

Measures: 120 x 120 x 181mm

Weight: 3,5kg

Voltage: 100 –240V 50/60Hz via power supply

Lamp: LED (3x3W green, 3x3W blue, 4x3W red)

Radiation: 10°

Operating time: White 6h, single color 20h

Battery: 7,5A Lead-acid battery

Control: via IR remote control

Pico IR wireless Via Wireless Solution DMX

Housing: 4mm aluminum

Connections: XLR 3-pol for power supply

9 / 9

PIC O IR/ WIRELESS

Importeur:

B&K Braun GmbH

Industriestraße 2

D-76307 Karlsbad-Ittersbach

www.bkbraun.com

[email protected]
