IGM EMI-SSD-1M Guide de démarrage rapide

CO Ltd. I G M -D e te c to r

Address: 27 Engels Prospect,

building 5, litera A

Saint-Petersburg

194156, Russia,

Tel: 8 (800) 234-66-90

Website: www.igm-pribor.ru

E-mail: support@igm-pribor.ru

EMI-SSD-1M

TUNING GUIDE

MRBP.424321.001G2

Saint-Petersburg

2020

CO NT EN TS

MRBP.424321.001G2 Version 1.0 15/06/2020

1 POWER ON/OFF/REBOOT............................................................................................................ 5

1.1 FIRST START/SET-UP............................................................................................................................5

1.2 RECLOSINGS/REPEATED SET-UPS........................................................................................................6

1.3 CHANNLES REBOOT.............................................................................................................................6

1.4 CONTROLLER REBOOT.........................................................................................................................7

1.5 POWER OFF.........................................................................................................................................7

2 MAIN OPERATION MODE/MENU................................................................................................. 9

2.1 MAIN OPERATION MODE....................................................................................................................9

2.2 MENU ................................................................................................................................................10

3 CONTINGENCIES ARCHIVE DISPLAY............................................................................................ 11

4 SETTINGS................................................................................................................................... 13

4.1 DATE AND TIME SELECTION..............................................................................................................13

4.2 COMMUNICATION SETTINGS............................................................................................................14

4.3 DISPLAY SETTINGS.............................................................................................................................15

4.4 ACCESS SETTINGS..............................................................................................................................16

4.5 CONTINGENCIES ARCHIVE CLEARING ...............................................................................................18

4.6 DEFAULT SETTINGS ...........................................................................................................................18

5 INTERNAL CHANNELS SETTINGS................................................................................................. 19

5.1 CHANNEL MAINTENANCE MODE TURNING ON/OFF........................................................................19

5.2 CHANNEL CONFIGURATION CHANGE ...............................................................................................20

5.3 CHANNEL INPUT CALIBRATION.........................................................................................................24

5.4 CHANNEL FACTORY DEFAULT SETTINGS...........................................................................................25

6 EXTERNAL CHANNELS SETTINGS................................................................................................. 27

7 CHANNELS FACTORY SETTINGS .................................................................................................. 28

7.1 INTERNAL CHANNELS FACTORY SETTINGS........................................................................................28

7.2 EXTERNAL CHANNELS FACTORY SETTINGS.......................................................................................29

8 ARCHIVING MODE SETTINGS ..................................................................................................... 30

9 DEVICE INFORMATION .............................................................................................................. 32

10 LOADER................................................................................................................................... 33

10.1 SOFTWARE UPDATE ........................................................................................................................33

10.2 CHANNELS AND CONTROLLER SETTINGS DEFAULT ........................................................................34

10.3 WORK WITH LOADER COMPLETION ...............................................................................................35

CO NT EN TS

MRBP.424321.001G2 Version 1.0 15/06/2020

Appendix A EMI-SSD-1M menu structure......................................................................................36

Appendix B Factory default parameters........................................................................................40

Appendix C Gases configuration factory settings parameters ........................................................41

Appendix D Operation modes, contingencies, signaling and relay actuation description................44

Appendix E Blanking zone, thresholds and hysteresis detailed description ....................................48

CO NT EN TS

MRBP.424321.001G2 Version 1.0 15/06/2020

This guide is intended for qualified personnel performing control unit EMI-SSD-1M

mounting, tuning and service maintenance.

This guide contains description of the arrangements for controller and separate fi channels

operation and tuning.

The guide is not a replacement for control unit EMI-SSD-1M and connected detectors User

Manuals.

Only persons with at least the third electrical safety access qualification level, having the cer-

tificate for work on electrical installations up to 1000 V and trained in workplace safety are allowed to

control unit EMI-SSD-1M mounting, tuning and maintenance service.

Control unit EMI-SSD-1M menu structure is shown in Appendix A.

There is a keypad on the front panel for operation and menu navigation.

Keypad assignment:

- power on/off/reboot;

- up;

- down;

- left;

- right;

- confirmation (main mode –cannel information request);

- cancel/back (main mode –menu request);

- emergency mute (handshaking).

P O WE R O N /O FF / RE B OO T

MRBP.424321.001G2 Version 1.0 15/06/2020

1POWER ON/OFF/REBOOT

1.1 FIRST START/SET-UP

To power EMI-SSD-1M control on, after on-site mounting and/or new detectors connection

according to this UM, it is necessary to push the button on the control unit keypad, the loading

window appears on the display:

After the loading, the following message appears on the display:

↑

NO CHANNELS ENGAGED!

12:50↓

This message means it is necessary to perform channels tuning and connection.

EMI-SSD-1M control unit settings complete list can be found in the guide sections:

- «SETTINGS»;

- «INTERNAL CHANNELS SETTINGS»;

- «EXTERNAL CHANNELS SETTINGS»;

- «ARCHIVING MODE SETTINGS».

At the first start default settings and methane channels configuration factory settings are

set, factory default settings and gas configurations are shown Appendix B and C.

Minimal settings array essential for internal channel connection:

- date and time selection;

- current loop connection diagram selection;

- target gas selection.

Minimal settings array essential for external channel connection:

- date and time selection;

- device model selection;

- enter network address;

- interface RS-485 port settings.

After successful channels connection, «MAIN OPERATION MODE»appears on the display.

P O WE R O N /O FF / RE B OO T

MRBP.424321.001G2 Version 1.0 15/06/2020

1.2 RECLOSINGS/REPEATED SET-UPS

In case when the work with EMI SSD-1M control unit was previously carried out, the detec-

tors and channels settings didn’t change, it is necessary to press the button on the keypad to

turn the device on, loading window is displayed. After loading the following message is displayed:

01:SN09501668

↑

CHANNAL INITIALIZATION

CxHy % LFL 12:50

↓

This message means that the channel is preparing for work. Channel initialization mean time

is no longer than 130 seconds, after that «main operation mode»is displayed.

1.3 CHANNELS REBOOT

To reboot internal channels or one of internal channels it is necessary to enter «MENU»→

«CHANNEL REBOOT». The menu «INTERNAL CHANNELS REBOOT»is displayed.

INTERNAL CHANNELS REBOOT

Channel 1 Sn09501668

Channel 2 ----

Channel 3 ----

Channel 4 ----

Channel 5 ----

Channel 6 ----

Channel 7 ----

Channel 8 ----

REBOOT ALL

Then it is necessary to select a channel on the list, that is to be rebooted, or, if it is necessary

to reboot all the channels, select the menu option «REBOOT ALL». Menu «REBOOT»is displayed.

Using buttons and it is possible to review the channel brief information: position,

channel state.

P O WE R O N /O FF / RE B OO T

MRBP.424321.001G2 Version 1.0 15/06/2020

The following messages are displayed during the reboot confirmation:

These messages mean reboot is successful.

1.4 CONTROLLER REBOOT

To reboot EMI-SSD-1M control unit, it is necessary to push the button on the keypad,

the menu «WORK COMPLETION»is displayed.

WORK COMPLETION

REBOOT

POWER OFF

After menu «REBOOT»selection, the following message is displayed:

WORK COMPLETION

CONTROLLER REBOOT…

This message means reboot is in. Reboot mean time is 3-5 s, after which the load window

and then the initialization window is displayed. After the successful control unit reboot, «main opera-

tion mode»is displayed.

1.5 POWER OFF

To power EMI-SSD-1M control unit off it is necessary to push the button on the keypad,

menu «WORK COMPLETION»is displayed.

WORK COMPLETION

REBOOT

POWER OFF

P O WE R O N /O FF / RE B OO T

MRBP.424321.001G2 Version 1.0 15/06/2020

After menu «POWER OFF»selection, turning off window is displayed:

Power off mean time is 3-5 s, after which the control unit display blinks off and sensors pow-

er supply turns off.

M A IN O P ER AT IO N M O DE /M EN U

MRBP.424321.001G2 Version 1.0 15/06/2020

2MAIN OPERATION MODE/MENU

2.1 MAIN OPERATION MODE

«Main operation mode»- EMI-SSD-1M control unit operation mode displaying the following

information:

•Current concentration value of the channel;

•Set target gas and its measurement units;

•Current channel number;

•Sensor position (set in channel settings);

•Current time;

•New contingency icon (disappears after new record review in the contingencies

menu);

•Data exchange with the control unit via RS-485 icon (disappears in 5 seconds after

data exchange with the control unit completion)

•Archiving on SD-card mode on icon:

- SD card is not found, LED «ALARM»flashes 3 times every 2 s);

- SD card record error;

- SD card record protection enabled;

Sensor position

Channel number

Current concentra-

tion value

Contingency

Data archiving on SD-card

mode

Data exchange via RS-485

Current time

Measure-

ment unit

Gas type

M A IN O P ER AT IO N M O D E/ M EN U

MRBP.424321.001G2 Version 1.0 15/06/2020

- data archiving on SD card mode. Data is recorded correctly.

By using buttons and channel is changed.

To review measured channel current information, it is necessary to push the button .

01:SN09501668

GAS: C3H8

VALUE, %LFL: 0.0

BLANKING ZONE: 0.0

THRESHOLD 1: 10.0

THRESHOLD 2: 20.0

MAX.VALUE: 100.0

MIN.VALUE: 0.0

THRESHOLD 1 HYSTERESIS: 0.0

THRESHOLD 2 HYSTERESIS: 0.0

THRESHOLD 1 RESET: AUTO

THRESHOLD 2 RESET: AUTO

CL CONNECTION: PASS.2wires

CURRENT, mA: 4,000

In the top left corner is the channel number and sensor item tag; hereunder is the present

channel information.

To return to the «main operation mode» press button or .

2.2 MENU

To change control unit or channels settings, it is necessary to enter the device’s «MENU»,

that requires pressing the button in the «main operation mode».

CONTINGENCIES

CHANNELS REBOOT

SETTINGS

CHANNELS SETTINGS

ARCHIVING SETTINGS

DEVICE INFO

For menu navigation use buttons and .

Necessary section selection –.

Quit the menu - .

Operation modes, signaling and relay actuations are described in the Appendix D.
