Operating instructions EN
Routing
- Place the router on the template ensuring that the router bit does not touch the workpiece.
- Switch on.
- Rout carefully from left to right following the fingers of the template with the template guide.
- Switch off the router and carefully remove from jig.
- Check that all slots are routed clean. If not, rout again.
- Remove the workpiece from the jig.
- Test joint.
ATTENTION !
Scrap stock must be 6 mm (¼”) thicker than workpieces. Without this extra thickness severe damage may occur
to your jig and router bit.
If joint is not perfect :
Joint too shallow= increase cutting depth of routerbit.
Joint too deep= decrease cutting depth of routerbit.
Adjust the template assembly according to this table and
rout new joint again.
SAFETY
• Before changing router bit or making any kind of adjustment, always turn off and unplug your router.
• Use protective glasses during routing.
• Use hearing protectors.
• Always use a dust-protection mask or respirator.
• Use dust collection.
• Do not wear loose clothes. Make sure that your sleeves are either rolled up or fastened and that you are not
wearing a tie.
• Before starting your router remove all tools, nuts and other loose object from the work area.
• Avoid an inadvertent start of your router. Before you plug it in, verify the switch is in“off“ position.
• Before you make any adjustments, wait till your router cutter completely stops.
FD3130 & 6130 SPARE PARTS LIST v.5
Pos. # Description quantity code
10 Screw M4 x 16 2 FS200126
13 Template brackets FD300 – not included , from FD300 2 FD6001-22
Template brackets FD600 – not included , from FD600 2 FD6001-21
14 Screw M4 x 8 4 FS200128
22 Screw M5 x 8 2 FS200143
23 Hex key 2,5 1 F9900620
29 Template comb 12,7 mm ( ½“) Box Comb FD300 1 FD3130-04
Template comb 12,7 mm ( ½“) Box Comb FD600 1 FD6130-04
35 Guide bush D15,8 mm x 4 – not included, from FD300 & 600 1 FGB158-04
43 Edge guide D17,3 mm x 31 mm red FD3130 2 FD3130-03
Edge guide D10 mm x 31 mm red FD6130 2 FD6130-03
44 Edge guide D19,7 mm x 6 mm red FD3130 2 FD3130-02
Edge guide D11,3 mm x 8 mm red FD6130 2 FD6130-02
69 Screw M4 x 40 2 FS200141
