Iget Super HD SmartCam Plus Manuel utilisateur
Model: HGWBC-356
Quick Start Guide - EN
Super HD
SmartCam Plus
5 0 6 0 4 4 2 1 7 3 5 6 9
HGWBC-356
iGET HOMEGUARD 2022
21
USB cable
What’s included
Warning Stickers Bracket Fixings Wall Plug
Quick Start GuideBattery Camera Power Adapter
Parts & Description
Spotlight
Indicator Light
Lens
Microphone
Infrared Light
Micro USB Port
MicroSD Card Slot
Power Button
Reboot Hole
Speaker
Human Body
Infrared Sensor
Front view
Bottom view
3 4
Charge the Camera Battery
Battery Management
Battery life up to 6 months base on an average of
200 seconds of recording footage per day
Charger Standard: DC 5V 1.5A.
It takes 8hours to fully charge it. Please fully
charge the camera before first use.
The battery durability depends on how frequently
the camera is woken up. The more times the camera
is woken up, the faster the battery drains. It is
recommended to lower down the 'Motion Detection'
sensitivity or turn it off occasionally.
The battery of your camera may drain faster below
32°F(0°C). When you receive low-battery alert on
your app, it is suggested to take the camera down
and fully recharge it indoor, or you can connect it to
the power cable all the time.
Place the camera indoors. If you are using the camera
outdoors, bring it inside while charging the battery.
Connect the power adapter cable to the camera power
adapter. You must use the power adapter and cable that
came with the camera.
Connect the other end of the adapter cable to the camera
Plug the power adapter into an electrical outlet.
Indicator Light Status:
Working mode Blue
Off
Yellow
Green
Mode
Light Device Status
Sleep mode
Charging mode
Fully charged
* Battery life varies based on settings, usage & temperature.
* The rechargeable battery is 60% charged when it leaves the factory.
You can fully charge the battery before camera installation.
* The camera LED lights solid green when the camera battery is fully charged.
65
Get the App
Step 1
For the best experience, download the Homeguardsmart app for your smartphone by scanning the QR code below or searching for
“Homeguardsmart” in the app store.
Account Register
Step 2
Open Homeguardsmart App, then select
Sign up.
Create a password at least 8 characters
long.Your password must include three
of the following:
• At least one uppercase letter
• At least one lowercase letter
• At least one number
You will receive a verification code to your
registered mobile phone or e-mail.
Set up a password and write down as
record:
7 8
Add Device
Step 3
Hold 3~5
Seconds
Login your account and tap“Add camera
now”.
Press the power button until you hear
scanning sound and see the light on.
Choose your camera and Connect to
2.4GHz Wi-Fi.
* If you can't hear 'Ding Dong Ding Dong', please
double-click the power button to enter the network
configuration mode again.
Connect to Network
Step 4
Enter the correct Wi-Fi password.
Note: The camera is not support
5GHz Wi-Fi.
This App will generate a QR code, place
the QR code 6~12 inches(15-30cm) in
front of the camera lens. After scan the
QR code,the camera prompt''Wi-Fi
connected''.
Name the camera after the Pairing is
successful.
910
You are now free to position your camera anywhere in your home where you get a Wi-Fi
signal and view it remotely from anywhere in the world on your Smartphone or Tablet!
You’re Done!
Congratulations! Your HOMEGUARD Smart Camera is set up and ready to go.
Home Page
1
5
6
7
8
9
11
10
2
3
4
Select the camera
Check battery status
Do not disturb mode
Tap to access Split-screen view
Tap to add a new camera
Tap to access camera setting
Tap to go into history playback list
Share camera to family
Tap to access home page
Tap to go into history playback list
Tap to access account information page
Device name
Battery Status
Undisturb
Split-screen
Add Device
Setting
Replay
Share
Home
Library
User
1 5
4
3
6
7
8
91110
2
11 12
Live View
54
1
6
2 3
1
5
6
2
3
4
Saves video clip from a live video
Tap to change between video quality levels: SD, FHD
Tap to access camera setting, alarm & light setting
Tap to hear the camera or unmute
Saves images captured from a live video
Activate the microphone to enable 2-way talk
Record
Resolution
Setting
Mute / Unmute
Capture
2-way talk
Live
2021/07/21 12:00:11
60KB/s
PIR Motion Detection
Turn on 'Motion Detection' and adjust
sensitivity.
When you turn on 'Alarm Siren' (In Sound
Setting) or 'Alarm Flash' (In Lighting
Setting), the camera will sound an alarm
or keep flashing when motion detected.
13 14
Before turn on 'Notification', please first
turn on 'Motion Detection' to receive
alarm messages.
The AI Analysis can tell the difference between
people,vehicles,pets and packages.
You can set up notification base on Person,Pet,
Vehicle & Package.
AI Analysis & Notification Activity Zone
All videos will still be recorded after setting
activity zones, but you will only receive
notification of movements in your activity zone.
The principle of Activity Zone is to judge the
objects activity in pointed area with combining
intellegent analyse on cloud. Therefore it's a
cloud-based AI.
1615
Night Mode
'Infrared mode' is a black and white view under
night vision; 'White light mode' is a color view
under night vision.
'White light mode' will turn on the spotlight at
night and capture a colorful view. The spotlight
will be constantly on when there is a motion
detected or when living view.
Filter Video
Select videos by camera names, tags and others.
00:10
00:10
00:10
00:10
17 18
Share Camera
Click "Device sharing", and a QR code
will be generated for sharing.
Enters the 'Home' page and click 'Add
Friend’s Camera', then scan QR code.
After you accepts sharing,sharing
is complete!
Multi-Device Management
Click ' + ' to add more devices
Split screen setting can watch live broadcast
from multiple cameras at the same time
* Strong Wi-Fi Connection View Multiple Cameras at the Same time
