Please read these instructions carefully before use and retain for future reference

Before switching on your appliance

Always check for any damage which may have been caused in transit

IG9021

2kW Oscillating Fan Heater

USER MANUAL

Batch code:

IMPORTANT: THIS PRODUCT IS ONLY SUITABLE

FOR WELL INSULATED SPACES OR OCCASIONAL USE

CONTENTS

Important Safety Instructions...............................................2-4

Appliance Overview...................................................................4

Technical Specication ...............................................................5

Operating Instructions...............................................................6

Cleaning and Maintenance ........................................................6

Fuse Replacement.......................................................................7

Trouble Shooting Guide.............................................................7

Terms and Conditions and Warranty Information...........8-9

Disposal Information............................................................... 12

SAFETY INSTRUCTIONS

Important: Read and follow all of the instructions even if you

feel you are familiar with the product and nd a place to keep this

manual handy for future reference.

• Make sure the unit is connected to an earthed power supply

of the correct rating (refer to the rating label located on the

unit). Ensure that the electricity supply in your home is rated at

220-240 volts before operating the appliance.

• This appliance should only be used by adults.

• Cleaning and user maintenance shall not be made by children.

• Keep the appliance and its cord out of reach of children.

• Children shall not play with the appliance.

• The appliances cannot be used by persons with reduced

physical, sensory or mental capabilities.

• This product is intended for domestic use only.

• The heater is not designed for use as the main form of heating.

• This product has been designed for household and indoor use

only. Do not use the heater outdoors.

• If the mains lead of this appliance becomes damaged then it

must be replaced by the manufacturer’s service agent or a

suitably qualied person using the same rated cable in order to

avoid a hazard.

• Keep the mains lead away from the hot body of the appliance

and always unroll lead completely to avoid dangerous

overheating.

• Always turn off the appliance and unplug when not in use or

before carrying out cleaning, maintenance or moving locations.

• Ensure the appliance is used on a at, even surface, positioned

away from curtains and furniture which could cause a re hazard.

• There are no user serviceable parts inside this heater.

• Do not remove plug from power socket until and appliance is

switched off and never remove by pulling the supply cord.

Always grip the plug.

• Do not cover or obstruct any of the heat outlet grilles or air

intake openings of the heater.

• Do not insert any objects through the heat outlet of air

intakes grilles.

• Do not place the heater directly below a socket outlet.

• Ensure that the heater is not positioned close to curtains or

furniture as this may create a re hazard.

• Do not use the heater in areas where ammable liquids are

stored or ammable fumes may be present.

• Do not twist, kink or wrap the cord around the appliance as this

may cause the insulation to weaken and split.

• Do not place the heater on carpets with a deep pile. Do not

run the cord under carpeting, rugs or runners.Arrange cord

away from trafc so that it will not be tripped over. Keep the

cord a safe distance from the inlet and outlet grilles.

• Use of an extension cord is not recommended with this

appliance.

• Do not use the appliance to dry clothes.

• Do not store the appliance while it is still hot.

• Do not operate with the cord coiled as a build-up of heat could

be sufcient to become a hazard.

• Attention: the front grille gets hot during use.

• The most common cause of overheating is deposits of dust or

uff in the appliance. Ensure these deposits are removed

regularly by unplugging the appliance and vacuum cleaning the

grilles.

• Do not reach for an appliance that has fallen into water. Switch

off at supply and unplug immediately

• Never place the heater where it may fall into water, or stand on

a damp oor.

• Do not use the unit in a wet room, such as a bathroom or

laundry room or in areas where the unit is likely to get splashed.

• To protect against re, electric shock or injury do not immerse

the heater, power cord or plug in water or any other liquid.

• Do not operate appliance with wet hands.

• Use this appliance only as describe in the manual.Any other use

is not recommended by the manufacturer and may case re,

electric shock or injury.

APPLIANCE OVERVIEW

1. Temperature Control

2. Mode Selector Control

3. Power Indicator Light

4. Oscillation Switch

5. Tip Over Switch (underneath)

Fig. 1

Fig. 2 Fig. 3

Technical specication

Item Symbol Value Unit Item Unit

Heat output

Nominal heat output Pnom 2 kW

Minimum heat output Pmin 1 kW

(indicative)

Minimum continuous Pmax,c 2 kW

heat output

Auxiliary electricity consumption

At nominal heat output elmax 0 kW

At minimum heat output elmin 0 kW

In standby mode elsb 0 kW

Type of heat input, for electric storage local

space heaters only (select one)

manual heat charge control, with N/A

integrated thermostat

manual heat charge control with N/A

room and/or outdoor temperature

feedback

electronic heat charge control with N/A

room and/or outdoor temperature

feedback

fan assisted heat output N/A

Type of heat output/room temperature

control (select one)

single stage heat output and no room [no]

temperature control

Two or more manual stages, no room [no]

temperature control

with mechanic thermostat room [yes]

temperature control

with electronic room temperature [no]

control

electronic room temperature control [no]

plus day timer

electronic room temperature control [no]

plus week timer

Other control options (multiple selections

possible)

room temperature control, with [no]

presence detection

room temperature control, with open [no]

window detection

with distance control option [no]

with adaptive start control [no]

with working time limitation [no]

with black bulb sensor [no]

OPERATING INSTRUCTIONS

Choose a suitable location for the heater ensuring you have taken account of the safety instructions

NOTE: It is normal that when the heater is turned on for the rst time or after not being used for a

long period of time that it may emit a slight smell and fumes.These will disappear when the heater has

been on a short while.

• Take out the heater from its box carefully. Please save the box to store

the heater when not in use.

• Plug the unit into a power socket. Do not to use the same electrical socket

as another high wattage electrical appliance in order to avoid overloading

the circuit.

Selecting Mode:

• Use the Mode Selector Control (Fig 3) to choose the required mode.

• Setting (Fig 3) indicates the fan function only, this will produce no heat.

• l Setting (Fig 3) indicates the low heating function 1kW power.

• II Setting (Fig 3) indicates the high heating function 2kW power.

• 0 Setting (Fig 3) indicates off.

Selecting temperature:

• Gradually turn the Temperature Control (Fig 2) in a clockwise direction until the

required temperature is reached.

• The Temperature Control can then be turned in either direction to decrease or increase

the temperature.

• The thermostat can be adjusted between 0 - 40°C.

Oscillation Function

• The unit is supplied with an oscillation function; this will allow air to be distributed over a larger area.

• To switch the oscillation function on, press the Oscillation Switch (Fig 1 [4]) to the ‘on’ position, to

switch off repeat this function.

Overheat Protection

• The unit is tted with a safeguard that will automatically shut the power off should any part of the

heater begin to overheat. Once the unit has cooled down it will automatically switch back on.

Check that there is nothing surrounding the unit that may have caused it to overheat.

Tip Over Switch

• The unit is tted with a tip over switch, this will automatically shut the power off should the unit

fall or be knocked over. To reset unit, stand upright on a at even surface.

Cleaning and Maintenance

• Ensure the heater is switched off and unplugged from the mains socket and allowed to cool down.

Once cool wipe the exterior of the unit with a damp (not wet) clean cloth. It is not recommended to

use detergents or abrasive materials as this may damage the housing. Important: Do not allow water

to enter the heater.

• To remove dust and debris for the grilles it is recommended that you use a vacuum cleaner.

• Ensure that the heater and plug are dry before plugging back into the mains socket.

Storing

• When the unit is not in use for long periods of time it is recommended that the unit be placed back

in the original box and stored out of reach of children.

MAINS PLUG FUSE REPLACEMENT

(Class II)

Remove the central screw on the plug and open the shell.

Take out the fuse and replace with a new fuse of the same

Amp. Install the shell again and tighten the screws.

TROUBLE SHOOTING

Please refer to the trouble shooting guide when experiencing an issue with your heater. If you still cannot

determine the fault then please call our Customer Services number 01473 271272

Problem Possible Cause Solution

The heater does

not work.

1. Not properly plugged into the

mains wall socket.

Push plug rmly in.

2. Not switched on.

The heater is

getting too hot.

Conrm the unit is switched on.

3. Power cut.

Adjust the temperature control.

The heater is

not heating up.

1.Temperature control set too low.

Check the fuse or breaker.

1. Inadequate air ow.

2.Temperature control set to high.

3. Power cut.

Make sure there is air circulating

in the room.

Make sure that nothing is blocking

the air ow.

Adjust the temperature control

to a higher setting.

2.The Mode selector is on

the wrong mode.

Turn the Mode selector to

ll high mode.

lgenix Warranty Terms & Conditions

This product is guaranteed for a period of 12 months as standard from the date of purchase

against mechanical and electrical defects.You can extend your warranty for a further 12 months by

registering your product.

Upon registration we will cover your product for a period of 24 months from the original purchase

date against any mechanical or electrical defects.

To qualify for the warranty, the product must be used for domestic household use only and in

accordance with the instructions in the user manual.Any misuse of the product will result in the

warranty being void.

The warranty does not cover accidental damage, misuse, neglect, tampering or incorrect adjustment

or installation.

The warranty will be rendered invalid if the product is resold, has had its serial number removed

(or has an invalid serial number), or if an unauthorised person has carried out any repairs or

alterations.

The warranty does not cover accessories or consumable parts that require replacement under

normal use. This includes shelving, dials, lters, belts and trays etc.

In the unlikely event of a breakdown please refer to the Troubleshooting guide in your user manual

and check all plugs, fuses and the electricity supply.

If you still require assistance please contact our Customer Service department on

01473 271 272 or write to us at the following address:

Customer Service Department

38 Bluestem Road, Ransomes Europark

Ipswich, IP3 9RR

Please quote the Product Code which begins ‘IG’ or ‘DF’ and the Batch Coder beginning ‘5’ and give

details of the exact fault.We will then decide whether to repair or replace the item.

Before we arrange the repair or replacement you will be required to return a copy of your proof

of purchase. Please retain your original.

If an item is replaced within the agreed warranty period, the warranty for the replacement item will

be calculated from the purchase date of the original.

In the event that the product is inspected and no fault is found or the product is not within the

warranty period you will be charged for the repair and any carriage costs.

Thank you for choosing lgenix

As a valued customer we would like to offer you a FREE 2 year warranty to cover your product

against any electrical or mechanical defects.

This means that in the unlikely event you develop a fault or problem with your product we will

happily repair or replace the item free of charge.

To qualify for the 2 year warranty you must register your product within 30 days of purchase.The

full Terms & Conditions of our warranty policy are shown on the opposite page.They are also

available on our website. www.igenix.co.uk

To register your product, please complete all sections of the form below and return to us at the

following address: lgenix, 38 Bluestem Road, Ransomes Europark, Ipswich, IP3 9RR.

Alternatively you can visit the lgenix website and complete the form online.

Customer Details:

Title: First Name Surname:

Address:

Post Code:

Email:

Telephone:

Product Information:

Product Code (Beginning IG or DF): Product Description:

Batch Number (Beginning 5): Serial Number (If applicable):

Date of Purchase:

Retailer Name:

Retailer Location:

Please tick here to conrm you have read and accept our Terms & Conditions

Please tick here if you DO NOT wish to receive marketing information from us

Customer Signature: Date:

Table des matières

Autres manuels iGenix Chauffage

iGenix

iGenix IG9515WIFI Manuel utilisateur

iGenix

iGenix IG9030 Manuel utilisateur

iGenix

iGenix IG9508 Manuel utilisateur

iGenix

iGenix IG2611 Manuel utilisateur

iGenix

iGenix IG5250 Manuel utilisateur

iGenix

iGenix IG2600 Manuel utilisateur

iGenix

iGenix IG9301 Manuel utilisateur

iGenix

iGenix IG1670 Manuel utilisateur

iGenix

iGenix IG5005 Manuel utilisateur

iGenix

iGenix IG9041 Manuel utilisateur

iGenix

iGenix IG9042 Manuel utilisateur

iGenix

iGenix IG5005 Manuel utilisateur

iGenix

iGenix IG9101 Manuel utilisateur

iGenix

iGenix IG9020 Manuel utilisateur

iGenix

iGenix IG9514 Manuel utilisateur

iGenix

iGenix IG9022 Manuel utilisateur

iGenix

iGenix IG1601 Manuel utilisateur

iGenix

iGenix IG0500 Manuel utilisateur

iGenix

iGenix IG9010 Manuel utilisateur

iGenix

iGenix IG9302 Manuel utilisateur

iGenix

iGenix IG9509 Manuel utilisateur

iGenix

iGenix IG5300 Manuel utilisateur

iGenix

iGenix IG9520WIFI Manuel utilisateur

iGenix

iGenix IG9516 Manuel utilisateur

Manuels Chauffage populaires d'autres marques

oventrop

oventrop Regucor Series Manuel utilisateur

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manuel utilisateur

ELMEKO

ELMEKO ML 150 Manuel utilisateur

BN Thermic

BN Thermic 830T Manuel utilisateur

KING

KING K Series Mode d’emploi

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guide de démarrage rapide

Well Straler

Well Straler RC-16B Manuel utilisateur

EUROM

EUROM 333299 Manuel utilisateur

Heylo

Heylo K 170 Manuel utilisateur

Eterna

Eterna TR70W Manuel utilisateur

Clarke

Clarke GRH15 Mode d’emploi

IRSAP

IRSAP The Radiator Company Ovali Manuel utilisateur

Empire Heating Systems

Empire Heating Systems WCC65 Manuel utilisateur

Wetekom

Wetekom 92 86 43 Manuel utilisateur

Desa

Desa SPC170-F Manuel utilisateur

Watlow

Watlow Watrod Electric Tubular Heaters Manuel utilisateur

Haverland

Haverland ECO-DRY GPS Series Manuel de la liste des pièces

Stelpro

Stelpro ASILVC2060 Series Manuel utilisateur

iGenix IG9021 Manuel utilisateur

Manuels Chauffage populaires d'autres marques
